Summarization of Contents
Important Safety Information
Please Read and Save this Manual
Instructions for proper use and saving the manual for future reference.
Keep a Record for Quick Reference
Section to record important product information like purchase date and serial number.
Important Safety Information
Important Safety Instructions - Gas Dryer
Key safety instructions specific to gas dryer operation, including fire and explosion hazards.
Important Safety Information
Risk of Fire
Safety warnings and precautions related to fire hazards during installation and operation.
Important Safety Information
Safety Precautions
General safety precautions and definitions of hazard symbols like Danger, Warning, and Caution.
Prevent Fire
Detailed instructions to prevent fire hazards associated with laundry center operation.
Important Safety Information
Fire Hazard Warnings
Specific warnings about fire hazards related to lint buildup and improper installation.
Protect Children
Safety guidelines to protect children from hazards like suffocation and entrapment.
Important Safety Information
Before You Throw Away Your Old Laundry Center
Steps to take when disposing of an old laundry center to prevent hazards.
Prevent Injury
Instructions to prevent electrical shock, stability issues, and personal injury during operation.
Prevent Injury and Damage to the Laundry Center
Guidelines to prevent personal injury and damage to the appliance during use.
Important Safety Information
Harmful Vapor Hazard
Warning about mixing household chemicals and producing dangerous fumes.
Risk of Injury
Caution against washing water-resistant materials that can cause vibration issues.
Pre-Installation Requirements
Tools and Materials Needed for Installation
List of tools and materials required for the proper installation of the laundry center.
Accessories
Information on recommended accessories like conversion kits, hoses, and touch-up paint.
Pre-Installation Requirements
Electrical System Requirements for Electric Dryer
Detailed electrical requirements for electric dryers, including circuit and power supply specifications.
Pre-Installation Requirements
Electrical Requirements for Gas Dryer
Electrical specifications for gas dryers, including circuit, power supply, and grounding.
Gas Supply Requirements
Essential requirements for connecting the gas supply to the laundry center, including safety warnings.
Pre-Installation Requirements
Electrical System Requirements for Washer
Electrical requirements for the washer, including circuit, power supply, and grounding.
Grounding Requirements
Detailed instructions on proper grounding to prevent electrical shock hazards.
Water Supply Requirements
Specifications for water supply connections, including faucet type, threading, and water pressure.
Drain System Requirements
Requirements for the drain system, including standpipe height and capacity.
Pre-Installation Requirements
Exhaust System Requirements
Critical requirements for the exhaust system, including duct material and venting procedures.
Duct Work Requirements
Specific guidelines for exhaust ductwork to ensure safe and efficient dryer operation.
Pre-Installation Requirements
Exhaust System Requirements
Further requirements for exhaust systems, including maximum lengths and elbow usage.
Pre-Installation Requirements
Manufactured or Mobile Home Installation
Specific installation guidelines for manufactured or mobile homes, focusing on exhaust systems.
Pre-Installation Requirements
Clearance Requirements
Guidelines for proper clearances around the laundry center for ventilation and access.
Installation In a Recess or Closet
Instructions for installing the laundry center in a recess or closet, focusing on ventilation.
Pre-Installation Requirements
MIN. INSTALLATION CLEARANCES
Table detailing minimum clearances required for different installation types like alcoves and closets.
Pre-Installation Requirements
Laundry Center Dimensions
Key dimensions and measurements of the laundry center for installation planning.
Installation
Decoupling the Laundry Center (if Needed)
Procedure for separating the washer and dryer units for installation or moving purposes.
Installation
Disconnecting Components
Steps to disconnect wiring harnesses and brackets for separating the dryer from the washer.
Installation
Removing Shipping Hardware
Instructions for removing shipping hardware to prepare the unit for operation.
Installing Hole Plugs
Guidance on inserting hole plugs into the washer back panel.
Leveling the Laundry Center
Steps to properly level the laundry center to prevent noise and vibration.
Connecting the Water
Instructions for connecting the water supply hoses to the washer.
Installation
Connecting the Water
Detailed steps for connecting hot and cold water supply hoses to the laundry center.
Installation
Connecting the Drain
Procedure for connecting the drain hose, including anti-siphon and standpipe requirements.
Completing the Installation
Final steps to complete the installation, including plugging in and running a test cycle.
Connecting the Electrical System
Guidelines for safely connecting the electrical system to the laundry center.
Installation
Electrical Connection Requirements
Instructions for proper electrical connection, including grounding and cord requirements.
Installation
Electrical Connection (non-Canada) - 3 wire cord
Procedure for connecting a 3-wire power cord, including wiring and strain relief.
Grounding Requirements - Gas Dryer
Specific grounding requirements for gas dryers to ensure safety.
Installation
Electrical Connection (non-Canada) - 4 Wire Cord
Procedure for connecting a 4-wire power cord, including wiring and grounding.
Installation
Connecting the Gas
Instructions for connecting the gas supply, including safety warnings and conversion kit information.
Installation
Connecting the Water (steam models only)
Specific steps for connecting water supply hoses for steam models.
Installation
Completing the Installation
Final steps to complete installation, including connecting exhaust and power.
Installation
Reversing the Washer Door
Instructions for reversing the washer door for preferred opening direction.
Installation
Removing Washer Door Lock and Plastic Hole Cover
Steps to remove the washer door lock and plastic hole cover.
Reinstalling Washer Door Lock and Hole Cover
Instructions for reinstalling the washer door lock and plastic hole cover.
Installation
Reversing Washer Door Assembly
Detailed steps for reversing the washer door assembly.
Reinstalling Washer Door Assembly
Procedure for reinstalling the washer door assembly after reversal.
Installation
Verify Reversed Washer Door Operation
Steps to verify the correct operation of a reversed washer door.
Reversing the Dryer Door
Instructions for reversing the dryer door for preferred opening direction.
Installation
Removing Dryer Door Assembly
Steps for removing the dryer door assembly.
Reversing Dryer Door Assembly
Procedure for reversing the dryer door assembly.
Installation
Reversing Dryer Door Assembly
Continued steps for reversing the dryer door assembly, including ring orientation.
Installation
Reinstalling Latch and Hole Plugs
Instructions for reinstalling the dryer door latch and hole plugs.
Reinstalling Door Assembly
Steps for reinstalling the dryer door assembly after reversal.
Verify Reversed Dryer Door Operation
Steps to confirm correct operation of a reversed dryer door.
Washer Controls and Settings
Settings Chart - 7600 series
Details on washer controls and settings specific to the 7600 series models.
Washer Controls and Settings
Cycle Selection
Guide on how to select and change washer cycles for optimal results.
Washer Controls and Settings
Cycle Settings
Explanation of various cycle settings like washing temperature, sanitize, and allergen options.
Washer Controls and Settings
Cycle Options
Details on available cycle options and how to select them for different wash needs.
Washer Controls and Settings
Stain Treatment Options
Information on specific stain treatment options like StainTreat and StainSoak for tough stains.
Wash Cycle Options
Description of additional wash cycle options like extra rinse, pure rinse, and extended refresh.
Washer Controls and Settings
Control Options
Explanation of control options like control lock, delay time, and chime settings.
Other Features
Details on other features like LED display, Eco indicator, and Oversuds Protection.
Washer Controls and Settings
Reversed Hose Detection
Information on how the washer detects and alerts for reversed inlet hose connections.
Drum Light
Description of the drum light feature and its operation.
Reversible Door
Information on the reversible door feature for the washer.
Trapped Item Detection
How the washer detects items trapped in the door and the procedure to resolve.
Door Stand Ventilation
Explanation of the door stand ventilation feature to prevent odors.
Dryer Controls and Settings
Settings Chart - 7600 series
Details on dryer controls and settings specific to the 7600 series models.
Dryer Controls and Settings
Cycle Selection
Guide on selecting the right dryer cycle to save energy and optimize drying.
Dryer Controls and Settings
Cycles
Description of various dryer cycles and their intended load types and presets.
Cycle Settings
Explanation of how to set dryer temperature, dryness level, and time.
Dryer Controls and Settings
Dryness Level (dry level)
How to set the desired dryness level for loads, including options like damp and high.
Drying Time (dry time)
Instructions for manually setting the drying time for timed dry cycles.
Cycle Options
Details on available dryer cycle options like steam, dry boost, and wrinkle release.
Dryer Controls and Settings
Control Lock
How to lock and unlock dryer controls to prevent accidental operation.
Chime
Information on the dryer's chime notification for cycle end or options.
Other Features
Description of other dryer features like LED display, drum light, and reversible door.
Operating the Washer
Add wash products to dispenser
Instructions for adding detergents, bleach, and fabric softener to the dispenser.
Select the cycle and settings for the load
Guidance on selecting appropriate cycles and settings for different laundry loads.
Start the washer
Steps to start the washing machine cycle and add forgotten items.
Remove items from washer when cycle has ended
Instructions for removing laundry promptly after the cycle ends to prevent issues.
Washer Operating Instructions
Adding Laundry Products
Guide on adding laundry products to the dispenser, including types and amounts.
Washer Operating Instructions
Powder Detergent
Instructions for using powder detergent in the washer dispenser.
Detergent pack
Specific instructions for using detergent packs with the washer.
Dryer Operating Instructions
Select the appropriate cycle and settings for each load
How to select dryer cycles and settings for optimal drying results.
Close the dryer door and start the drying cycle
Steps to start the dryer cycle and add items during operation.
Remove items when done
Instructions for removing dried items promptly.
Clean the lint filter
Reminder and instruction to clean the dryer lint filter after each cycle.
Stain Removal Guide
Stain Removal Suggestions
Table listing specific stains and recommended treatments for their removal.
Care and Cleaning
Inside Routine Cleaning
Tips for maintaining the inside of the laundry center to prevent odors and humidity.
To Refresh or Clean inside of Laundry Center
Procedure for running the clean washer cycle to freshen the machine.
To Clean the dispenser drawer
Steps for cleaning the detergent and fabric softener dispenser drawer.
Care and Cleaning
Cleaning the Adaptive Dispenser™™ (7600 Series)
Detailed steps for cleaning the Adaptive Dispenser for 7600 series models.
Aggressive Inside Cleaning
Procedure for deep cleaning the washer drum and seals for severe odor or residue.
Care and Cleaning
Outside Routine Cleaning
Instructions for cleaning the exterior of the laundry center.
Winterizing Instructions
Steps to prepare the laundry center for winter storage to prevent freeze damage.
Care and Cleaning
Water Inlet Hose Inspection
Guidelines for inspecting and replacing water inlet hoses to prevent leaks.
Instructions for Limited Use, Vacation and Away from Home
Steps to take when the laundry center is not in use for extended periods.
Care and Cleaning
Cleaning the Filter
Instructions for cleaning the dryer's lint filter after each load.
Cleaning the LuxCare™™ Lint Shield Filter
Detailed steps for cleaning the LuxCare™™ Lint Shield filter.
Troubleshooting
Pilling
Troubleshooting common issues like pilling, residue, wrinkling, and yellow buildup.
Residue or powder on dark items
Solutions for residue or powder buildup on dark items, stiff fabrics, and wrinkling.
Yellow buildup of body soil on synthetic fabrics
Troubleshooting yellow buildup on synthetics and rust stains.
Troubleshooting
Residue stain buildup in gasket
Solutions for residue buildup in the gasket, dispenser drawer, and water in gasket folds.
Residue stain buildup in dispenser drawer or detergent pack not dissolved.
Troubleshooting residue buildup in the dispenser and undissolved detergent.
Water in fold of flexible gasket
Causes and solutions for water accumulating in the flexible gasket.
Odor
Causes and solutions for odor issues in the washer.
Troubleshooting
Before Calling
Guide on common issues and checks before contacting service personnel.
Noise Issues
Troubleshooting common noises like rattling, thumping, and vibrating.
Operating Issues
Troubleshooting operational issues like residue, demo mode, and load balance.
Troubleshooting
Washer Does Not Start
Troubleshooting steps when the washer does not start, including power and water supply issues.
Water Issues
Troubleshooting water-related issues like leaks, slow filling, and excess water.
Troubleshooting
Water Temperature Issues
Troubleshooting problems with warm or hot water not being hot enough.
Drainage Issues
Troubleshooting slow or no drainage issues.
Over-sudsing
Causes and solutions for excessive suds during washing.
Troubleshooting
Common Drying Inquiries
Common dryer problems like lint, pilling, shrinking, wrinkling, and wet spots.
Troubleshooting
Dryer Does Not Start
Troubleshooting steps when the dryer does not start, including power and settings.
Dryer Runs but Won't Heat
Diagnosis and solutions for dryers that run but do not produce heat.
Troubleshooting
Drying Cycle Takes Too Long
Causes for long drying cycles and solutions including lint filter and exhaust checks.
Excessive Wrinkling
Troubleshooting excessive wrinkling issues.
Scratching or chipping of the drum finish.
Causes and solutions for scratching or chipping of the dryer drum finish.
Need help?
Do you have a question about the ELTG7600AT and is the answer not in the manual?
Questions and answers
