BENDIX AR-2 ANTILOCK RELAY VALVE Manual

®
® ™
Bendix AR-2 AntiLock Relay Valve
DELIVERY
™
FIGURE 1 - AR-2 ANTILOCK RELAY VALVE ASSEMBLY
DESCRIPTION
™
The AR-2 antilock relay is a specialized air brake valve
developed for use on antilock equipped tractors only. It is
™
essentially a BP-R1 "bobtail" brake proportioning relay valve
(Bendix Service Data Sheet SD-03-1067) with a modified
cover that permits direct attachment of a Bendix
controller such as the EC-15
antilock controller the resulting assembly is referred to as a
antilock controller relay assembly. For example when the
™
AR-2 valve is combined with the EC-15
controller, the resulting assembly is referred to as a CR-16
controller relay assembly.
While it is intended for use on antilock equipped tractors,
the AR-2 ™ valve functions solely as an air brake relay and
contains no electronics of its own.
ANTILOCK CONTROLLER
MOUNTING HOLES(4)
MOUNTING
BRACKET
® antilock
™
. When combined with an
™
electronic
SUPPLY
™
The AR-2 valve replaces the standard relay valve used to
control the rear axle service brakes and performs the standard
relay function during tractor-trailer operation. During tractor
bobtail operation, the AR-2
pressure to the lighter rear axle(s) brakes to improve vehicle
controllability and minimize rear axle(s) wheel skid before
antilock is required. The AR-2
braking control and reduces the number of times antilock is
actually needed.
Like the standard relay valve it replaces, the AR-2
™
and its attached antilock controller is normally mounted near
the service brakes it serves. A mounting bracket, furnished
with the valve, permits either frame or cross member
mounting. All air connections on the AR-2
with cast, embossed letters for ease of identification and
installation. The letter identification and air line connections
are shown below for reference.
CONTROL
DELIVERY
™
valve reduces brake application
™ valve provides added vehicle
™
valve are identified
SERVICE
™
valve
1
