Front Panel Functions
INPUT
High impedance input for connecting your instrument to the amplifier.
TREBLE + Push/Pull BRIGHT
Adjusts high frequency response. Pulling the knob boosts highs for sparkle.
MIDDLE + Push/Pull Mid
Adjusts midrange response for tonal 'body'. Pulling boosts mids.
BASS + Push/Pull DEEP
Adjusts bass response. Pulling boosts lower bass frequencies.
GAIN
Adjusts overall gain, from clean to fatter/warmer tones.
MASTER
Adjusts overall output level. Pulling knob activates Lead channel.
LEAD GAIN
Adjusts the input level (gain) of the lead channel.
LEAD MASTER
Adjusts the output level of the lead channel.
REVERB
Mixes reverb effect signal with the dry signal.
STANDBY
Engages standby mode to mute output and prolong tube life.
INDICATOR LAMP
Illuminates when the unit is receiving A/C power.
Rear Panel Functions
A/C Input
Connects amplifier to A/C power via the supplied power cord.
Fuse
Protective fuse; refer to Fuse Chart for specifications.
Power Switch
Turns the amplifier's power on.
Speaker Output Jacks
Jacks for connecting speaker cabinets (4, 8, 16 ohms).
REVERB DRIVE
Controls signal to reverb tank, affecting reverb effect intensity.
Effects Loop
Passive loop for integrating external effects units.
Foot Switch Jack
Connection point for the external footswitch.
Tube Complement
V1-V7 Tube Descriptions
Identifies specific tubes and their function within the amplifier circuit.
Declaration of Conformity
Manufacturer and Product Details
Details concerning the manufacturer, product name, and model numbers.
Technical Regulations and Standards
Lists technical regulations and conformity standards met by the product.
