INTRODUCTION Thank you for electing SOLUXTEC GmbH PV modules. The following user guide is covering important points to be read and understood before installation of SOLUXTEC products. This document is not having any aims in relation to quality warranties but only for safety, electrical, mechanical and general handling of SOLUXTEC products.
EMC and Low Voltage regulation NOTE: As SOLUXTEC is always improving his products. Please contact your customer service if a standard is missing for your project from above list. TRANSPORT AND HANDLING During transportation and Interim storage, following point have to be respected: Transportation of the modules need to be done only with SOLUXTEC original packaging.
Bifacial frameless transparent Ninside Pure Glass Label explanation: All Module Type from SOLUXTEC is having his own label on back. This label is summarizing the module data sheet as follow: Place of production Commercial name STC (standard test condition) data:...
INSTALLATIONS ON SITE SOLUXTEC pv modules installation need to respect the following guidelines on site. MODULE DESIGN PRESENTATION a) DAS MODUL MONO XSC (DMMXSC) Mono perc M10 half cut (all values are given in mm) 1133 Frame section (double section):...
Page 7
DAS MODUL MONO XSC Ni (DMMXSCNi) Mono ntype M10 half cut TOPCON (all values are given in mm) 1133 Frame section: : 4 mounting holes : 4 grounding holes Maximum load test: + 5400 Pa // - 2400 Pa...
Page 8
DAS MODUL MONO XSC Ni Pure Glass (DMMXSCNi_PG) Mono ntype M10 half cut TOPCON GLASS GLASS (all values are given in mm) 1133 Frame section: : 4 mounting holes : 4 grounding holes Maximum load test: + 8100 Pa // - 2400 Pa...
Page 9
: 4 mounting holes : 4 grounding holes Maximum load test: + 5400 Pa // - 2400 Pa New cells Ntype Topcon New Frame with stronger alloy New plastic corner unbreakable Easy to carry SOLUXTEC USER GUIDE 2023_Version 2/a_ALL RIGHTS RESERVED...
Page 10
: 4 mounting holes : 4 grounding holes Maximum load test: + 8100 Pa // - 2400 Pa New cells Ntype Topcon New Frame with stronger alloy New plastic corner unbreakable Bifaciality 0,8 Easy to carry SOLUXTEC USER GUIDE 2023_Version 2/a_ALL RIGHTS RESERVED...
Page 11
Mono ntype M10 half cut TOPCON 108 cells frameless (all values are given in mm) 1128 Maximum load test: + 2400 Pa // - 2400 Pa New cells Ntype Topcon Frameless Total thickness 5,5 mm SOLUXTEC USER GUIDE 2023_Version 2/a_ALL RIGHTS RESERVED...
Page 12
Mono ntype M10 half cut TOPCON 90 cells frameless Glass/Glass (all values are given in mm) Maximum load test: + 3600 Pa // - 2400 Pa New cells Ntype Topcon Frameless 3,2 / 2 Total thickness 6,5 mm Bifaciality 0,8 SOLUXTEC USER GUIDE 2023_Version 2/a_ALL RIGHTS RESERVED...
Shadowing could result in to a significant energy loss. SOLUXTEC’s pv modules can be installed only with mounting structures. Mounting structures need to comply with any applicable law requested from the country of installation.
Page 14
Please refer to table on next page showing the different installation option from SOLUXTEC’s modules range. Please note as well that the mechanical behaviour from our product will vary depending on the option elected.
INSTALLATION OPTION a) DMMXSC b) DMMXSCNi c) DMMXSCNi_PG d) DMMAXSCNi e) DMMAXSCNi_PG f) PSMXSCNi g) PSMAXSCNi_PG Clamps long side X = 305 mm X = 305 mm X = 305 mm X = 305 mm X = 305 mm X = 305 mm X = 305 mm +/- 50 mm +/- 50 mm...
Page 16
Design load: Design load: Design load: Design load: +1600 Pa / -1600 Pa +1600 Pa / -1600 Pa +1600 Pa / -1600 Pa +1600 Pa / -1600 Pa +1600 Pa / -1600 Pa SOLUXTEC USER GUIDE 2023_Version 2/a_ALL RIGHTS RESERVED...
Page 17
All above data are given based on module resistance. It is on the installer to elect a mounting instruction having at least same behaviour than the module. The whole solution needs to be evaluated by the solution supplier for the set “PV module + mounting system + clamp system”.
PV modules can be connected in serial or in parallel. In serial: total voltage is the sum of each module voltage (in serial we add voltage, we do not add intensities) SOLUXTEC USER GUIDE 2023_Version 2/a_ALL RIGHTS RESERVED...
Page 19
The planning of the wiring of the PV system should consider a tight loop wiring of the plus and minus line. The area enclosed by the conductors should be kept as small as possible (here in grey). This reduces the risk of inductive coupling caused by lightning strokes. SOLUXTEC USER GUIDE 2023_Version 2/a_ALL RIGHTS RESERVED...
Page 20
It is recommended to use a 10 mm² bonding connector to realize the grounding between each module. The recommended section to the main equipotential bonding is 16 mm². The legal standard from the installation place might be different and need to be follow in priority. SOLUXTEC USER GUIDE 2023_Version 2/a_ALL RIGHTS RESERVED...
MAINTENANCE AND CLEANING: SOLUXTEC Pv modules are offered with a long-lasting operating life together with a low level of maintenance. SOLUXTEC recommend a yearly inspection from a qualified company and ideally from the company having realised the installation in order to control the efficiency of the complete generator.
Page 22
SOLUXTEC GmbH Werner von Siemens Str. 25 D-54634 Deutschland HRB Wittlich 41318 Info@soluxtec.de SOLUXTEC USER GUIDE 2023_Version 2/a_ALL RIGHTS RESERVED...
