  • Page 1 USER GUIDE SOLUXTEC SOLAR PRODUCTS...

  • Page 2: Table Of Contents

    1. INTRODUCTION 2. BASIC SAFETY INSTRUCTIONS 3. REGULATION 4. TRANSPORTATION AND HANDLING 5. PRODUCT DETAILS 6. INSTALLATION Modules Design Precaution Installation Option 7. ELECTRICAL INSTALLATION Precaution Installation Option 8. MAINTENANCE AND CLEANING SOLUXTEC USER GUIDE 2021_Version 1/a_ALL RIGHTS RESERVED...

  • Page 3: Introduction

    INTRODUCTION Thank you for electing SOLUXTEC GmbH PV modules. The following user guide covers important instructions to be read and understood before installation of SOLUXTEC products. This document does not have any relation to quality warranties and only acts as a user guide for electrical, mechanical and general handling safety of SOLUXTEC products.

  • Page 4: Regulation

     EMC and Low Voltage regulation  NOTE: SOLUXTEC is always improving its products. Please contact customer service if a standard is missing for your project from the above list. TRANSPORTATION AND HANDLING During transportation and interim storage, following points have to be respected: Transportation of the modules needs to be done only with SOLUXTEC original packaging.

  • Page 5: Product Details

    Black/White/Transparent POWERSLATE MONO VI PG PSMVIPG Glass glass Black/White/Transparent Label explanation: All Modules from SOLUXTEC have their own label on back. This label summarizes the module data sheet as follows: Place of production Commercial name STC (standard test condition) data:...

  • Page 6: Installation

    INSTALLATION ON SITE When installing SOLUXTEC PV modules the following guidelines need to be respected on site. MODULE DESIGN PRESENTATION Frame design for M6 solar cells modules:  DMMVI  DMMVI_GEMINI  DMMVIPG 4 x mounting holes: 328 mm 4 x grounding...
  • Page 7 78 mm 1005 mm Frameless Design for M6 solar cells Module Glass + Foil & Glass + Glass:  PSMVI (total thickness of 5,5 mm)  PSMVIPG (total thickness of 6,5 mm) 1033 mm SOLUXTEC USER GUIDE 2021_Version 1/a_ALL RIGHTS RESERVED...

  • Page 8: Precaution

    SOLUXTEC’s PV modules can be installed only with mounting structures.  Mounting structures need to comply with any applicable laws specific to the country ...
  • Page 9  Please refer to the table on next page showing the different installation options from SOLUXTEC’s module range. Please note as well that the mechanical behaviour from our product will vary depending on the option elected.

  • Page 10: Installation Option

    & +5400/-1600 DMMIVPG DMMXPG Test: +2400/-2400 Design: +1600/-1600 X= 50 Clamps not in contact with plastic corner Y = 250 X = 350 PSMVI Test: Y = 460 +2400/-2400 & Design: PSMVIPG +1600/-1600 SOLUXTEC USER GUIDE 2021_Version 1/a_ALL RIGHTS RESERVED...
  • Page 11 +5400/-1600 DMMIV X = 328 mm DMMX (4 positions) Test: & +8100/-2400 DMMIVPG Design: +5400/-1600 DMMXPG DMMIV X = 328 mm DMMX (4 positions) Test: & +2400/-2400 DMMIVPG Design: +1600/-1600 DMMXPG & GEMINI SOLUXTEC USER GUIDE 2021_Version 1/a_ALL RIGHTS RESERVED...
  • Page 12  Make sure that module cables are not damaged and not in mechanical stress.  Make sure that the mounting system or any sharp component is not in contact with the surface of the modules nor the foil or glass backside. SOLUXTEC USER GUIDE 2021_Version 1/a_ALL RIGHTS RESERVED...

  • Page 13: Electrical Installation

    PV modules can be connected in serial or in parallel.  In serial: • total voltage is the sum of each module voltage (in serial we add voltage, we do not add intensities) SOLUXTEC USER GUIDE 2021_Version 1/a_ALL RIGHTS RESERVED...
  • Page 14  The planning for the wiring of the PV system should consider a tight loop wiring of the plus and minus line. The area enclosed by the conductors should be kept as small as possible (here in grey). This reduces the risk of inductive coupling caused by lightning strokes. SOLUXTEC USER GUIDE 2021_Version 1/a_ALL RIGHTS RESERVED...
  • Page 15 It is recommended to use a 10 mm² bonding connector to realize the grounding between each module. The recommended section to the main equipotential bonding is 16 mm². The legal standard from the installation place might be different and need to be follow in priority. SOLUXTEC USER GUIDE 2021_Version 1/a_ALL RIGHTS RESERVED...

  • Page 16: Maintenance And Cleaning

    Hence, it is recommended to clean the surface of the modules only with a soft broom and water. An alcohol based cleaner solution is also allowed. For any issues with SOLUXTEC’s products you can contact us via our email address info@soluxtec.de SOLUXTEC’S technical service will support you.
  • Page 17 SOLUXTEC GmbH Werner von Siemens Str. 25 D-54634 Deutschland HRB Wittlich 41318 info@soluxtec.de SOLUXTEC USER GUIDE 2021_Version 1/a_ALL RIGHTS RESERVED...
