Using RGB video

To connect your HDTV decoder set-top box using RGB video:
1
Connect the 15-pin D-Sub RGB jack on the back of your HDTV set-top box
to the RGB-IN jack on the back of your plasma TV.
2
Connect the red (R) and white (L) audio-out jacks on the back of your
HDTV set-top box to the R and L audio-in jacks on the back of your
plasma TV.
3
Select
RGB
After you connect your HDTV set-top box to the RGB input jack on your
plasma TV, you may need to adjust various plasma TV picture settings to
correctly match the output from the HDTV set-top box (see "PICTURE –
RGB/DVI video sources" on page 38).
using the button on the front of your plasma TV.
INPUT
