- Page 1 NEXCOM International Co., Ltd. Industrial Computing Solutions Fan-less Computer NISE 3600E Series User Manual NEXCOM International Co., Ltd. www.nexcom.com Published April 2013...
-
Page 2: Table Of Contents
COM 5 and COM 6 Ports ...............20 Front Panel ..................4 LAN1 and USB 3.0 Ports ..............20 Rear Panel ...................5 LAN2 and USB 2.0 Ports ..............21 Mechanical Dimensions ................6 Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual... - Page 3 Chapter 3: System Setup Appendix B: GPI/O Programming Guide....85 Removing the Chassis Bottom Cover ............38 Installing a SATA Hard Drive ..............39 Appendix C: Watchdog Timer Setting....87 Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual...
-
Page 4: Preface
No describes how to keep the system CE compliant. part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM Declaration of Conformity International Co., Ltd. -
Page 5: Rohs Compliance
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm. In order to meet the RoHS compliant directives, NEXCOM has established an engineering and manufacturing task force to implement the introduction of green products. -
Page 6: Warranty And Rma
(manuals, cable, etc.) and any components from the card, such as CPU and RAM. If the components were suspected as part of the problems, ▪ If RMA goods can not be repaired, NEXCOM will return it to the customer please note clearly which components are included. Otherwise, NEXCOM without any charge. - Page 7 ESD workstation. If no such station is available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis. Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual...
-
Page 8: Safety Information
Danger of explosion if battery is incorrectly replaced. Replace with the same or equivalent type recommended by CAUTION! CAUTION! CAUTION! the manufacturer. Discard used batteries according to the manufacturer’s instructions. viii Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual... -
Page 9: Safety Precautions
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS. 10. All cautions and warnings on the equipment should be noted. Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual... -
Page 10: Technical Support And Assistance
Preface Technical Support and Assistance Conventions Used in this Manual 1. For the most updated information of NEXCOM products, visit NEXCOM’s Warning: website at www.nexcom.com. Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself 2. -
Page 11: Global Service Contact Information
Chongde Rd., Beitun Dist., Shanghai, 200062, China Fax: +86-27-8722-7400 Taichung City 406, R.O.C. Tel: +86-21-6150-8008 Email: sales@nexcom.cn Tel: +886-4-2249-1179 Fax: +86-21-3251-6358 www.nexcom.cn Fax: +886-4-2249-1172 Email: sales@nexcom.cn www.nexcom.com.tw www.nexcom.cn Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual... - Page 12 Fax: +33 (0) 1 40 90 31 01 Email: sales.uk@nexcom.eu Email: sales.fr@nexcom.eu www.nexcom.eu www.nexcom.eu Germany NEXCOM GmbH Leopoldstraße Business Centre, Leopoldstraße 244, 80807 Munich, Germany Tel: +49-89-208039-278 Fax: +49-89-208039-279 Email: sales.de@nexcom.eu www.nexcom.eu Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual...
-
Page 13: Package Contents
(N)NISB 3600 Quick Reference Guide VER:A 60177A0299X00 NISE 3600E Series Quick Note VER:A 6023344361X00 Cable EDI:231441090251-RS 60233POW33X00 DC Cord EDI:281040051051-RS 602DCD0581X00 (N)NISE 3600E DVD Driver VER:2.0 xiii Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual... -
Page 14: Ordering Information
Preface Ordering Information The following information below provides ordering information for NISE 3600E Series. • Barebone NISE3600E (P/N: 10J00360000X0) - 3rd Generation Intel® Core™ i5/i3 Fanless System with one PCIe x4 Expansion NISE3600E2 (P/N: 10J00360001X2) - 3rd Generation Intel® Core™ i5/i3 Fanless System with two PCIe x4 Expansion NISE3600P2 (P/N: 10J00360002X0) - 3rd Generation Intel®... -
Page 15: Chapter 1: Product Introduction
▪ 1x VGA, 1x DVI-D and 2x Display port with Independent Display support ▪ Support ATX power mode, WoL, LAN teaming and PXE function ▪ Dual Intel® GbE LAN ports Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual... -
Page 16: Hardware Specifications
- VGA and DVI-D ▪ 2-pin Remote Power on/ off switch - Display Port and VGA ▪ 9~30V DC input - Display Port and DVI-D Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual... - Page 17 ▪ ATX power mode ▪ FCC Class A ▪ On-board DC to DC power support from 9V to 30V DC ▪ UL ▪ Optional power adapter Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual...
-
Page 18: Knowing Your Nise 3600E
Indicates the power status, hard drive and LAN activity of the system. Power Switch Press to power-on or power-off the system. SIM Card USB 3.0 Display Port CFast Power/HDD/LAN LEDs Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual... -
Page 19: Rear Panel
Used to connect a remote to power on/off the system. Line-out Digital Output Used to connect a headphone or a speaker. Support S3 Wake on LAN. Mic-in Used to connect an external microphone. Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual... -
Page 20: Mechanical Dimensions
Chapter 1: Product Introduction Mechanical Dimensions NISE 3600E 214.66 92.73 224.68 100.73 236.68 Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. NISE 3600E Series User Manual...
