Hooking Up the Tow Vehicle
Connect Trailer to Tow Vehicle
Connect the hitch, safety chains, and electrical hookup between the trailer and tow vehicle.
Secure Trailer Jack
Attach the break-away cable, release the jack handle, and lower the trailer jack.
Operating the Tilt Deck Trailer
Raise Jack Plate
Raise the jack plate fully by pulling the lower jack lever.
Lower Trailer Deck
Release safety pin and position lever to lower the trailer deck to the ground.
Loading the Trailer
Prepare Trailer for Loading
Adjust hydraulic pressure and lower the trailer deck to the ground.
Load and Secure Equipment
Drive equipment onto the trailer, position for load distribution, and secure the loading lever.
Safety Precautions
Avoid Pinch Points
Exercise caution around pinch points during loading and unloading operations.
Prevent Trailer Damage
Raise equipment buckets during loading to avoid hitting the trailer.
Ensure Tow Safety
Verify the safety lever is in place before towing to prevent damage during travel.
Service and Maintenance
Torque and Bearing Checks
Check wheel lug nut torque and wheel bearings for heat and play at specified intervals.
Brake and Tire Maintenance
Check brake adjustment, drum brake pads, and tire pressure regularly.
Lubrication and Light Checks
Lubricate wheel bearings annually and check lights and breakaway switch operation.
