- Page 1 EQUIPMENT TRAILERS USER MANUAL 1420/1424 Models 12/22...
- Page 2 Authorized Dealer for service or warranty department. This user’s manual contains safety information and operators instructions for your trailer. Make sure to read this manual along with owner’s manual prior to loading or towing of trailer. Timpte advises that all safety precautions and instructions be followed.
- Page 3 Hooking up the tow vehicle Connect the tow vehicle to the trailer using a 2 5/16” hitch. Next, attach the trailer safety chains to the tow vehicle. Connect the trailers electrical hookup to the tow vehicle. www.timpte.com...
- Page 4 Hooking up the tow vehicle Attach the break-away safety cable to the tow vehicle. Release the jack handle by unhooking safety pin from jack. Next, lower your trailer by cranking jack handle. Timpte Equipment Trailers | User Manual...
- Page 5 (Keep fingers out of the way of jack plate). Next, release safety pin on the safety lever and place in forward facing position to allow the trailer to lower to the ground. Timpte Equipment Trailers | User Manual...
-
Page 6: Loading The Trailer
Before loading, push down on rear side of the trailer to lower the deck to the ground. Once lowered, carefully drive your equipment onto trailer. Timpte Equipment Trailers | User Manual... - Page 7 After you have secured your safety lever, you have succesfully loaded your equipment. Do not tow trailer without verifying the safety lever is in place. Damage may occur to safety lever during travel. Timpte Equipment Trailers | User Manual...
- Page 8 When loading your equipment make sure to raise the buckets to ensure you do not hit the trailer. Do not tow trailer without verifying the safety lever is in place. Damage may occur to safety lever during travel. Timpte Equipment Trailers | User Manual...
-
Page 9: Service And Maintenance
Check brake adjustment 200 miles and 3,000 miles. Check drum brakes pads for wear. Check tire pressure before each tow. Lubricate wheel bearings every 12 months or 10,000 miles. Check lights are in working order. Check breakaway switch operation before each tow. www.timpte.com...
