GF7100P-M7 Setup Manual
FCC Information and Copyright
This equipment has been tes ted and found to comply with the limits of a Class
B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed
to provide reasonable protec tion against harmful interference in a residential
installation. T his equipment generates , uses , and c an radiate radio frequency
energy and, if not ins talled and used in accordance with the instructions , may
cause harmful interference to radio communications . There is no guarantee
that interference will not occur in a particular ins tallation.
The vendor makes no representations or warranties with respec t to the
contents here and s pecially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make c hanges to the c ontents here without obligation to
notify any party beforehand.
D uplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be c hanged without notice and
we will not be res ponsible for any mis takes found in this user's manual. All the
brand and produc t names are trademarks of their respec tive companies .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GF7100P-M7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Biostar GF7100P-M7

  • Page 1 GF7100P-M7 Setup Manual FCC Information and Copyright This equipment has been tes ted and found to comply with the limits of a Class B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed to provide reasonable protec tion against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction.............3 Before You Start..............3 Package Checklist..............3 Motherboard Features............4 Rear Panel Connectors............5 Motherboard Layout ............6 Chapter 2: Hardware Installation........7 Installing Central Processing Unit (CPU) ........ 7 FAN Headers................ 9 Installing System Memory.............10 Connectors and Slots ............12 Chapter 3: Headers &...
  • Page 3: Chapter 1: Introduction

    GF7100P-M7 CHAPTER 1: INTRODUCTION EFORE T ART Thank you for choosing our product. Be fore you start installing the mothe rboard, please make sure you follow the instructions be low: Prepare a dry and stable work ing environment with sufficie nt lighting. Always disconne ct the compute r from powe r outle t be fore ope ration.
  • Page 4: Motherboard Features

    Motherboard Manual OT HERBOARD EAT URES SPEC LGA 775 Supports Hyper-Threading / Execu te Disable Bit / Intel Core2Duo / Core2Qu ad / Celeron Enhanced In tel SpeedStep® / In tel Arch itectu re-64 / 4xx / Pen tiu m D / Pen tium 4 processor Extended Memory 64 Technology / Virtualization Supports 45nm CPU Technology...
  • Page 5: Rear Panel Connectors

    Board Size 200 mm(W) x 244 mm(L) Special RAID 0 / 1 / 5 / 0+1 support Features Biostar Reserves the righ t to add or remove support for OS Support Windows XP / VISTA any OS With or without notice. ANEL...
  • Page 6: Motherboard Layout

    Motherboard Manual OT HERBOARD AYOUT JCFAN1 JKBMS1 JATXPWR3 LGA775 JPSPW1 JATXPWR2 CPU1 JUSB 1 JUSBPW1 JRJ45USB1 GeForce 7100P/ LA N nForce 630i AUDIO1 PEX1_1 JCMOS1 PEX16_1 Codec BAT1 SATA2 SATA4 PCI1 JCDIN1 Super I/O JSPDIF_OUT1 JCOM1 PCI2 SATA1 SATA3 JU SBPW2 JSFAN 1 JPRNT1 JUSB2...
  • Page 7: Chapter 2: Hardware Installation

    GF7100P-M7 CHAPTER 2: HARDWARE INSTALLATION (CPU) NST ALLING ENT RAL ROCESSING Special Notice: Remove Pin Cap before installation, and make good preservation for future use. When the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged. Pin-Cap Step 1: Pull the socket locking lever out from the socket and then raise the lever up to a 90-degree angle.
  • Page 8 Motherboard Manual Step 2: Look for the triangular cut edge on socket, and the golden dot on CPU should point forwards this triangular cut edge. The CPU will fit only in the correct orientation. Step 2-1: Step 2-2: Step 3: Hold the CPU down firmly, and then lower the lever to locked position to complete the installation.
  • Page 9: Fan Headers

    GF7100P-M7 FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1. JCFAN1: CPU Fan Heade r Assignment Ground...
  • Page 10: Installing System Memory

    Motherboard Manual NST ALLING YST EM EMORY A. Memory Modules Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot.
  • Page 11 GF7100P-M7 Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated. B. Memory Capacity DIMM Socket Total Memory DDR2 Module Location Size DIMMA1 512MB/1GB/2GB Max is 4GB. DIMMA2 512MB/1GB/2GB...
  • Page 12: Connectors And Slots

    Motherboard Manual ONNECT ORS AND LOT S FDD1: Floppy Disk Conne ctor The motherboard prov ides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk ty pes. This connector supports the prov ided f loppy drive ribbon cables. IDE1: Hard Disk Conne ctor The motherboard has a 32-bit Enhanced PCI IDE Controller that prov ides PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 f unctionality.
  • Page 13 GF7100P-M7 PCI-EX16: PCI-Express x16 Slot PCI-Express 1.0a compliant. Maximum theoretical realized bandwidth of 4GB/s simultaneously per direction, f or an aggregate of 8GB/s totally. PCI-EX1_1: PCI-Express x1 Slot PCI-Express 1.0a compliant. Data transf er bandwidth up to 250MB/s per direction; 500MB/s in total. PCI-Express supports a raw bit-rate of 2.5GB/s on the data pins.
  • Page 14: Chapter 3: Headers & Jumpers Setup

    Motherboard Manual CHAPTER 3: HEADERS & JUMPERS SETUP OW T O ET UP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.
  • Page 15 GF7100P-M7 JATXPWR2: ATX Powe r Source Conne ctor This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V -12V +3.3V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage+5V +12V +12V Ground +3.3V...
  • Page 16 Motherboard Manual JUSB2/JUSB3/JUSB4: He ade rs for USB 2.0 Ports at Front Panel This header allows user to connect additional USB cable on the PC f ront panel, and also can be connected with internal USB devices, like USB card reader. Assignment +5V (fused) +5V (fused)
  • Page 17: Cd-Rom Audio-In Connector

    GF7100P-M7 JAUDIO F1: Front Panel Audio Heade r This header allows user to connect the front audio output cable with the PC f ront panel. This header allows only HD audio front panel connector; AC’97 connector is not acceptable. Assignment Mic Left in Ground Mic Right in...
  • Page 18 Motherboard Manual JSPDIF_O UT1: Digital Audio-out Conne ctor This connector allows user to connect the PCI bracket SPDIF output header. Assignment SPDIF_OUT Ground JCMO S1: Cle ar CMOS Heade r By placing the jumper on pin2-3, it allows user to restore the BIOS saf e setting and the CMOS data, please carefully f ollow the procedures to avoid damaging the motherboard.
  • Page 19 GF7100P-M7 JPRNT1: Printe r Port Connector This header allows you to connector printer on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground -Init -ACK Data 2 Ground -Scltin Busy Data 3 Ground Ground Data 4...
  • Page 20 Motherboard Manual JUSBPW1/JUSBPW2: Powe r Source Heade rs for USB Ports Pin 1-2 Close: JUSBPW1: +5V f or USB ports at JUSB1/JRJ45USB1. JUSBPW2: +5V f or USB ports at front panel (JUSB2/JUSB3/JUSB4). Pin 2-3 Close: JUSBPW1: +5V STB f or USB ports at JUSB1/JRJ45USB1. JUSBPW2: +5V STB f or USB ports at front panel (JUSB2/JUSB3/JUSB4).
  • Page 21: Chapter 4: Raid Functions

    GF7100P-M7 CHAPTER 4: RAID FUNCTIONS PERAT ION YST EM Supports Windows XP Home/Prof essional Edition, and Windows Vista. RRAYS RAID supports the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications.
  • Page 22 Motherboard Manual RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array.
  • Page 23 GF7100P-M7 RAID 0+1: RAID 0 drives can be mirrored using RAID 1 techniques. Resulting in a RAID 0+1 solution for improved performance plus resiliency. Features and Benefits ­ Drives: Minimum 4, and maximum is 6 or 8, depending on the platform. ­...
  • Page 24 Motherboard Manual RAID 5: RAID 5 stripes both data and parity information across three or more drives. It writes data and parity blocks across all the drives in the array. Fault tolerance is maintained by ensuring that the parity information for any given block of data is placed on a different drive from those used to store the data itself.
  • Page 25: Chapter 5: Useful Help

    GF7100P-M7 CHAPTER 5: USEFUL HELP RIVER NST ALLAT ION OT E After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance. You will see the following window after you insert the CD The setup guide will auto detect your motherboard and operating system.
  • Page 26: Award Bios Beep Code

    Motherboard Manual BIOS B WARD Beep Sound Meaning One long beep followed by two short Video card not found or v ideo card beeps memory bad High-low siren sound CPU overheated System will shut down automatically One Short beep when system boot-up No error found during POST Long beeps every other second No DRAM detected or install XT RA...
  • Page 27: Troubleshooting

    GF7100P-M7 ROUBLESHOOT ING Probable Solution No power to the system at all Make sure power cable is Power light don’t illuminate, f an securely plugged in. inside power supply does not turn Replace cable. Contact technical support. Indicator light on key board does not turn on.
  • Page 28: Appendencies: Spec In Other Language

    Motherboard Manual APPENDENCIES: SPEC IN OTHER LANGUAGE ERMAN Spezifikationen LGA 775 Unterstü tzt Hyper-Threading / E xecute Disable Bit / Intel Core2Duo / Core2 Quad / Celeron 4 xx Enhanced In tel SpeedStep® / Intel Architecture-64 / / Pentium 4 / Pen tiu m D Prozessoren Extended Memory 64 Technology / Virtualization Unterstü...
  • Page 29 Platinengröße 200 mm (B) X 244 mm (L) Sonderfun kti Unterstü tzt RAID 0 / 1 / 5 / 0+1 onen Biostar behält sich das Recht vor , ohn e An kündigung OS-Un terstüt Windows XP / VISTA die Un terstützung für ein Betriebssystem zung hinzu zufügen oder zu entfernen .
  • Page 30: France

    Motherboard Manual RANCE SPEC LGA 775 Prend en charge les techn ologies Hyper-Threading / Processeu rs In tel Core2Duo / Core2 Quad d'exécu tion de bit de désactivation / In tel SpeedStep® / Celeron 4xx / Pen tiu m 4 / Pen tium D optimisée/ d'architectu re In tel 64 / de mémoire Prend en charge le 45n m UC étendue 64 / de virtualisation...
  • Page 31 Fonctionnali tés Prise en charge RAID 0 / 1 / 5 / 0 +1 spéciales Biostar se réserve le droit d'ajouter ou de supprimer le Support SE Windows XP / VISTA support de SE avec ou san s préavis.
  • Page 32: Italian

    Motherboard Manual T ALIAN SPECIFICA LGA 775 Supporto di Hyper -Threadi ng / Execute Disable Processore Intel Core 2Duo / Bit / Enhance d I ntel Spee dStep® / Architettura Core2Quad / Celero n 4xx / Penti um 4 Intel 64 / Tecnologia Exte nde d Memory 64 / / Pentium D Tecnolo gia Virtualization Supporto 45nm CPU...
  • Page 33 (altezza) Caratterist iche Supporto RAID 0 / 1 / 5 / 0+1 speciali Sistemi Biostar si riserva il diritto di aggiungere o operativi Windows XP / VISTA rimuovere il supporto di qualsiasi sistema supportati operativo se nza pre avviso.
  • Page 34: Spanish

    Motherboard Manual PANISH Especificación LGA 775 Admite Hyper-Threading / Bit de deshabilitación de Procesador Intel Core2Duo / Core2 Quad / ejecu ción / In tel SpeedStep® Mejorado / Intel Celeron 4xx / Pen tiu m 4 / Pen tiu m D Architectu re-64 / Tecnología Extended Memory 64 / Admite 45nm CPU Tecnología de virtualización...
  • Page 35 Funciones Admite RAID 0 / 1 / 5 / 0 +1 especiales Soporte de Biostar se reserva el derecho de añ adir o retirar el sistema Windows XP / VISTA soporte de cualquier SO con o sin aviso previo. operativo...
  • Page 36: Portuguese

    Motherboard Manual ORT UGUESE ESPECIFICAÇÕES LGA 775 Processador In tel Core2Duo / Suporta as tecn ologias Hyper-Threading / Execu te Core2 Quad / Celeron 4 xx / Pentium 4 / Disable Bit / Enhan ced In tel SpeedStep® / In tel Pentium D Arqu itecture -64 / Extended Memory 64 / Virtualization Suporta 45nm CPU...
  • Page 37 Característi Suporta as funções RAID 0 / 1 / 5 / 0 +1 especiais Sistemas A Biostar reserva-se o direito de adicionar ou remover operativos Windows XP / VISTA suporte para qualquer sistema operativo com ou sem suportados...
  • Page 38: Polish

    Motherboard Manual OLISH SPEC LGA 775 Obsługa Hyper-Th reading / Execu te Disable Bit / Procesor In tel Core2Duo / Core2 Quad / Enhanced In tel SpeedStep® / In tel Procesor Celeron 4xx / Pen tiu m 4 / Pen tiu m D Architectu re-64 / E xtended Memory 64 Obsługa 45n m Procesor Technology / Virtualization Technology...
  • Page 39 200 mm (S) X 244 mm (W) płyty Funkcj e Obsługa RAID 0 / 1 / 5 / 0 +1 specjaln e Obsluga Biostar zastrzega sobie prawo dodawania lub systemu Windows XP / VISTA odwoływania obsługi dowoln ego systemu operacyjne operacyjnego bez powiadomien ia.
  • Page 40: Russian

    Motherboard Manual USSIAN СПЕЦ LGA 775 Поддержка технологий Hyper-Threading / Execu te (центральн Процессор In tel Core2Duo / Core2 Quad / Disable Bit / Enhan ced In tel SpeedStep® / In tel ый Celeron 4xx / Pen tiu m 4 / Pen tiu m D Architectu re-64 / Extended Memory 64 T echnology / процессор) Поддержка...
  • Page 41 панели Специальн ые технически Поддержка RAID 0 / 1 / 5 / 0+1 е характери с тики Biostar сохран яет за собой право добавлять или Поддержка Windows XP / VISTA удалять средства обеспечения для OS с или без предварительного уведомления.
  • Page 42: Arabic

    Motherboard Manual RABIC ‫اﻟﻤﻮاﺻﻔﺎت‬ LGA 775 ‫ﺕﺪﻋﻢ ﺕﻘﻨﻴﺎت‬Hyper-Threading / Execu te Disable Bit / ‫ﻡﻌ ﺎ ﻟﺠﺎت‬Intel Core2Duo / Core2 Quad / Enhanced In tel SpeedStep® / In tel Arch itectu re-64 / ‫وﺣﺪة ا ﻟﻤﻌ ﺎ ﻟﺠﺔ‬ Celeron 4xx / Pen tiu m 4 / Pen tiu m D ‫ﺘﺮدد‬...
  • Page 43 ‫ﺕﺪﻋﻢ ﺕﻘﻨﻴﺔ‬RAID 0 / 1 / 5 / 0 +1 ‫ﻡﺰاﻳﺎ ﺥﺎﺹﺔ‬ ‫ارﺕﻔﺎع‬ ‫ﻡﻢ‬ ‫ﻋﺮض‬ ‫ﻢ ﻡ‬ ‫ﺣﺠﻢ اﻟﻠﻮﺣﺔ‬ Windows XP / VISTA ‫ﺕﺤﺘﻔﻆ‬Biostar ‫ﺑﺤﻘﻬﺎ ﻓﻲ إﺿﺎﻓﺔ أو إز ا ﻟﺔ اﻟﺪﻋﻢ ﻷ ي ﻥﻈﺎم ﺕﺸﻐﻴﻞ ﺑﺈﺥﻄﺎ ر أو ﺑﺪون إﺥﻄﺎ ر‬ ‫دﻋﻢ أﻥﻈﻤﺔ ا ﻟﺘﺸﻐﻴﻞ‬...
  • Page 44: Japanese

    Motherboard Manual APANESE 仕様 LGA 775 Hyper-Threading / Execu te Disable Bit / Enhan ced Intel Intel Core2Du o / Core2 Quad / Celeron 4 xx SpeedStep® / Intel Architectu re-64 / Extended / Pentium 4 / Pen tiu m D processor Memory 64 Technology / Virtualization Technologyをサ...
  • Page 45 電源コネクタ(24 ピン) 電源コネクタ(4 ピン) PS/2 キーボード PS/2 マウス VGAポート 背面パネル DVI-D ポート LANポート USBポート オーディオジャック ボードサイズ 200 mm (幅) X 244 mm (高さ) RAID 0 / 1 / 5 / 0+1 のサポート 特殊機能 Biostarは事前のサポートなしにOSサポートを追加または削 OSサポート Windows XP / VISTA 除する権利を留保します。 2008/03/17...
