Page 1: Table Of Contents
GF7050-M2 SE/GF7025-M2 TE BIOS Setup BIOS Setup ....................1 1 Main Menu ..................... 3 2 Standard CMOS Features..............7 3 Advanced BIOS Features ..............9 4 Advanced Chipset Features..............16 5 Integrated Peripherals................. 18 6 Power Management Setup..............25 7 PnP/PCI Configurations..............29 8 PC Health Status ..................
Page 2: Bios Setup
GF7050-M2 SE/GF7025-M2 TE BIOS Setup Introduction The purpose of this manual is to describe the settings in the Phoenix-Award™ BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. The power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off.
Page 3 GF7050-M2 SE/GF7025-M2 TE ACPI Support Phoenix-Award ACPI BIOS support Version 1.0b of Advanced Configuration and Power interface specification (ACPI). It provides ASL code for power management and device configuration capabilities as defined in the ACPI specification, developed by Microsoft, Intel and Toshiba. PCI Bus Support This PHOENIX-AWARD BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Interconnect) local bus specification.
Page 4: Main Menu
GF7050-M2 SE/GF7025-M2 TE 1 Main Menu Once you enter Phoenix-Award BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu.
Page 5 GF7050-M2 SE/GF7025-M2 TE Advanced BIOS Features This submenu allows you to configure advanced features of the BIOS. Advanced Chipset Features This submenu allows you to configure special chipset features. Integrated Peripherals This submenu allows you to configure certain IDE hard drive options and Programmed Input/ Output features.
Page 6 GF7050-M2 SE/GF7025-M2 TE Set Supervisor Password Setting the supervisor password will prohibit everyone except the supervisor from making changes using the CMOS Setup Utility. You will be prompted with to enter a password. Set User Password If the Supervisor Password is not set, then the User Password will function in the same way as the Supervisor Password.
Page 7 GF7050-M2 SE/GF7025-M2 TE Upgrade BIOS This submenu allows you to upgrade bios.
Page 8: Standard Cmos Features
GF7050-M2 SE/GF7025-M2 TE 2 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into several categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the<PgUp> or <PgDn> keys to select the value you want in each item.
Page 9 GF7050-M2 SE/GF7025-M2 TE Item Options Description Press <Enter> to enter the Options are in its sub SATA Channel 1~4 sub menu of detailed menu. options. 360K, 5.25 in 1.2M, 5.25 in Select the type of floppy 720K, 3.5 in Drive A disk drive installed in your 1.44M, 3.5 in system.
Page 10: Advanced Bios Features
GF7050-M2 SE/GF7025-M2 TE 3 Advanced BIOS Features Figure 3: Advanced BIOS Setup CPU Feature...
Page 11 GF7050-M2 SE/GF7025-M2 TE Virtualization The item allows you control the Virtualization function. The Choices: Enabled (default), Disabled. AMD K8 Cool&Quiet control The item allows you select K8 Cool’n’Quiet control. The Choices: Auto (default), Disabled. Virus Warning This option allows you to choose the VIRUS Warning feature that is used to protect the IDE Hard Disk boot sector.
Page 12 GF7050-M2 SE/GF7025-M2 TE Typematic Rate Setting When a key is held down, the keystroke will repeat at a rate determined by the keyboard controller. When enabled, the typematic rate and typematic delay can be configured. The Choices: Disabled (default), Enabled. Typematic Rate (Chars/Sec) Sets the rate at which a keystroke is repeated when you hold the key down.
Page 13 GF7050-M2 SE/GF7025-M2 TE OS Select For DRAM > 64MB A choice other than Non-OS2 is only used for OS2 systems with memory exceeding 64MB. The Choices: Non-OS2 (default), OS2. Small Logo(EPA) Show This item allows you to select whether the “Small Logo” shows. Enabled (default) “Small Logo”...
Page 14 GF7050-M2 SE/GF7025-M2 TE CPU Internal Cache Depending on the CPU/chipset in use, you may be able to increase memory access time with this option. Enabled (default) Enable cache. Disabled Disable cache. External Cache This option enables or disables “Level 2” secondary cache on the CPU, which may improve performance.
Page 15 GF7050-M2 SE/GF7025-M2 TE Removable Device Priority Select Removable Boot Device Priority. The Choices: Floppy Disks, Zip100, USB-FDD0, USB-FDD1, USB-ZIP0, USB-ZIP1, LS120. Hard Disk Boot Priority The BIOS will attempt to arrange the Hard Disk boot sequence automatically. You can change the Hard Disk booting sequence here. The Choices: Pri.
Page 16 GF7050-M2 SE/GF7025-M2 TE CD-ROM Boot Priority The Choices: Pri. Master, Pri. Slave, Sec. Master, Sec. Slave, USB CDROM0, USB CDROM 1. First/Second/Third Boot Device The BIOS will attempt to load the operating system in this order. The Choices: Removable, Hard Disk, CDROM, Legacy LAN, Disabled. Boot Other Device When enabled, BIOS will try to load the operating system from other device when it failed to load from the three devices above.
Page 17: Advanced Chipset Features
GF7050-M2 SE/GF7025-M2 TE 4 Advanced Chipset Features This submenu allows you to configure the specific features of the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus.
Page 18 GF7050-M2 SE/GF7025-M2 TE K8<->NB HT Width The Choices: AUTO (default), ↓8↑8, ↓16↑16. CPU Spread Spectrum This item allows you to select the CPU Spread Spectrum function. The Choices: 0.50% H.Kiss Cntr, 0.50% H.Kiss Down, 0.75% H.Kiss Cntr, 0.75% H.Kiss Down, Disabled (default). PCIE Spread Spectrum This item allows you to select the PCIE Spread Spectrum function.
Page 19: Integrated Peripherals
GF7050-M2 SE/GF7025-M2 TE 5 Integrated Peripherals Figure 5. Integrated Peripherals IDE Function Setup Highlight the “Press Enter” label next to the “IDE Function Setup” label and press enter key will take you a submenu with the following options:...
Page 20 GF7050-M2 SE/GF7025-M2 TE MCP Storage Config SATA Operation Mode This option allows you to choose SATA function. The Choices: IDE (default), RAID, AHCI, Linux AHCI. SATA Pri-/Sec- Master/Slave RAID This option allows you to enable or disable SATA Primary/Secondary RAID. The Choices: Disabled (default), Enabled.
Page 21 GF7050-M2 SE/GF7025-M2 TE Primary Master/Slave UDMA Ultra DMA function can be implemented if it is supported by the IDE hard drives in your system. As well, your operating environment requires a DMA driver (Windows 95 or OSR2may need a third party IDE bus master driver). If your hard drive and your system software both support Ultra DMA, select Auto to enable BIOS support.
Page 22 GF7050-M2 SE/GF7025-M2 TE Onboard Device Highlight the “Press Enter” label next to the “Onboard Device” label and press the enter key will take you a submenu with the following options: HD Audio This option allows you to control the onboard HD audio. The Choices: Auto (default), Disabled.
Page 23 GF7050-M2 SE/GF7025-M2 TE Onboard SuperIO Device Press Enter to configure the Super I/O device. Onboard FDC Controller Select enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If you installed another FDC or the system uses no floppy drive, select disabled in this field.
Page 24 GF7050-M2 SE/GF7025-M2 TE Parallel Port Mode This item allows you to determine how the parallel port should function. The default value is SPP. The Choices: SPP (default) Using Parallel port as Standard Printer Port. Using Parallel Port as Enhanced Parallel Port. Using Parallel port as Extended Capabilities Port.
Page 25 GF7050-M2 SE/GF7025-M2 TE USB Keyboard/Storage Support This item allows you to enable or disable the USB Keyboard / storage Legacy Support. Enabled (default) Enable USB Keyboard / storage Support. Disabled Disable USB Keyboard/ storage Support. USB Mouse Support This item allows you to enable or disable the USB mouse Legacy Support. Enabled (default) Enable USB mouse Support.
Page 26: Power Management Setup
GF7050-M2 SE/GF7025-M2 TE 6 Power Management Setup The Power Management Setup Menu allows you to configure your system to utilize energy conservation and power up/power down features. Figure 6. Power Management Setup ACPI Function This item displays the status of the Advanced Configuration and Power Management (ACPI).
Page 27 GF7050-M2 SE/GF7025-M2 TE Power Management This category allows you to select the power saving method and is directly related to the following modes: 1. HDD Power Down. 2. Suspend Mode. There are three options of Power Management, three of which have fixed mode settings Min.
Page 28 GF7050-M2 SE/GF7025-M2 TE HDD Down In Suspend This option allows you to enabled or disabled the HDD power down function in suspend mode. The Choices: Disabled (default), Enabled Soft-Off by PBTN This item determines the behavior of system power button. Instant off turn off the power immediately, and Delay 4 Sec.
Page 29 GF7050-M2 SE/GF7025-M2 TE Date (of Month) Alarm You can choose which month the system will boot up. Time (hh:mm:ss) Alarm You can choose the system boot up time, input hour, minute and second to specify. Note: If you have change the setting, you must let the system boot up until it goes to the operating system, before this function will work.
Page 30: Pnp/Pci Configurations
GF7050-M2 SE/GF7025-M2 TE 7 PnP/PCI Configurations This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components.
Page 31 GF7050-M2 SE/GF7025-M2 TE The above settings will be shown on the screen only if “Manual” is chosen for the resources controlled by function. Legacy is the term, which signifies that a resource is assigned to the ISA Bus and provides non-PnP ISA add-on cards. PCI / ISA PnP signify that a resource is assigned to the PCI Bus or provides for ISA PnP add-on cards and peripherals.
Page 32: Pc Health Status
GF7050-M2 SE/GF7025-M2 TE 8 PC Health Status Figure 8: PC Health Status Smart Fan Option...
Page 33 GF7050-M2 SE/GF7025-M2 TE CPU Smart Fan This item allows you to control the CPU Fan. The Choices: Disabled (default), Auto, 4-pin, 3-pin.. Smart Fan Calibration Choose this item and then the BIOS will auto test and detect the CPU fan functions and show CPU fan speed.
Page 34 GF7050-M2 SE/GF7025-M2 TE CPU Vcore, Chipset Volt, +3.3V, +5.0V, +12.0V, DDR Voltage, HT Voltage, Voltage Battery Detect the system’s voltage status automatically. CPU Temp This field displays the current temperature of CPU. Current CPU FAN Speed This field displays the current speed of CPU fan. Current SYS FAN Speed This field displays the current speed SYSTEM fan.
Page 35: Performance Booster Zone
GF7050-M2 SE/GF7025-M2 TE 9 Performance Booster Zone VCore Voltage This item allows you to adjust the CPU Vcore voltage. The Choices: Default (default), +3.3%, +6.6%, +10% Memory Voltage This item allows you to adjust the memory voltage. The Choices: Default (default), 2.000V, 2.045V, 2.100V CPU Frequency This item allows you to select the CPU Frequency.
Page 36 GF7050-M2 SE/GF7025-M2 TE DRAM Configuration Timing Mode This item allows you to choose to manually or automatically regulate the DDR Timing. The Choices: Auto (default), MaxMemClk. Memory Clock Value OR Limi The Choices: DDR 400 (default), DDR 533, DDR 667, DDR 800. DQS Training Control The Choices: Perform DQS, Skip DQS (default).
Page 37 GF7050-M2 SE/GF7025-M2 TE Memory Hole Remapping The Choices: Enabled (default), Disabled. Auto Optimize Bottom IO The Choices: Enabled (default), Disabled. Bottom of [31:24] IO space The Choices: E0 (default); Min=0000, Max=00FF, key in a HEX number. Bottom of UMA DRAM [31:24] The Choices: FC (default);...
Page 38 GF7050-M2 SE/GF7025-M2 TE <Trtp> Precharge Time The Choices: 3 clocks (default), 2 clocks. <Trc> Row Cycle Time The Choices: 26 bus clocks (default), 11-25 bus clocks. <Trcd> RAS to CAS R/W Delay The Choices: 6 clocks (default), 3 clocks, 4 clocks, 5 clocks. <Trrd>...
