G31E-M7 BIOS Manual
BIOS Setup .................................................................................................1
1 Main Menu...............................................................................................3
2 Advanced Menu.......................................................................................7
3 PCIPnP Menu........................................................................................18
4 Boot Menu..............................................................................................22
5 Chipset Menu.........................................................................................25
6 Performance Menu...............................................................................30
7 Exit Menu...............................................................................................33
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G31E-M7 - BIOS and is the answer not in the manual?

Questions and answers

Related Manuals for Biostar G31E-M7 - BIOS

Summary of Contents for Biostar G31E-M7 - BIOS

  • Page 1 G31E-M7 BIOS Manual BIOS Setup ....................1 1 Main Menu....................3 2 Advanced Menu..................7 3 PCIPnP Menu..................18 4 Boot Menu....................22 5 Chipset Menu..................25 6 Performance Menu................30 7 Exit Menu....................33...

  • Page 2: Bios Setup

    G31E-M7 BIOS Manual BIOS Setup Introduction T he purpose of this manual is to describe the settings in the AMI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. T he power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off.

  • Page 3: Pci Bus Support

    G31E-M7 BIOS Manual PCI Bus Support T his AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Interconn ect) local bus speci fication. DRAM S upport DDR2 SDRAM (Double Data Rate II Synchronous DRAM) is supported. Supported CP Us T his AMI BIOS supports the Intel CPU.

  • Page 4: System Memory

    G31E-M7 BIOS Manual 1 Main Menu Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system inform ation. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset Performance Exit...

  • Page 5: Ata/Ide Configuration

    G31E-M7 BIOS Manual Floppy A Select the type of floppy disk drive installed in your system. Options: 360K, 5.25 in / 1.2M, 5.25 in / 720K, 3.5 in / 1.44M, 3.5 in / 2.88M, 3.5 in / None IDE Configuration T he BIOS will automatically detect the presence of ID E/SAT A devices.
  • Page 6 G31E-M7 BIOS Manual SATA1/2/3/4 Dev ice; IDE Channel 1 Master/Slave BIOS SETU P U TILITY Main SATA1 Device Select the type of device connected Device to the system. Type [Aut o] LBA/Large Mode [Aut o] Block (Multi-S ector Transfer)[Aut o] PIO Mode [Aut o] DMA Mode...

  • Page 7: Hard Disk Write Protect

    G31E-M7 BIOS Manual S.M.A.R.T Set the Smart Monitoring, Analysis, and Reporting T echnology. Options: Auto (Default) / Disabled / Enabled 32Bit Data Transfer Enable or disable 32-bit data transfer. Options: Enabled (Default) / Disabled Hard Disk Write Protect Disable or enable device write protection. T his will be effective only if the device is accessed through BIOS.

  • Page 8: Advanced Menu

    G31E-M7 BIOS Manual 2 Advanced Menu T he Advanced Menu allows you to configu re the settings o f CPU, Super I/O, Power Management, and other system devices. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.
  • Page 9 G31E-M7 BIOS Manual C1E Support C1E is “Enhanced Halt State” function, this f unction helps to save power and decrease heat by lowering CPU frequen cy while the processor is not working. Options: Enabled (Default) / Disabled Hardware Prefetcher T he processor has a hardw are prefetch er that automatically analy zes its requirements and prefetches dat a and instructions from the memory into the Level 2 cache that are likely to be required in the near future.

  • Page 10: Super Io Configuration

    G31E-M7 BIOS Manual Core Multi-Processing T his item allows multi-processing fun ction for multi-core processors. Options: Enabled (Default) / Disabled Intel(R) SpeedStep(tm) Tech T his item allows you to enable SpeedStep technology for better power saving. SpeedStep is a technology built into some Intel processors that allows the clock speed o f the processor to be dynamically changed by software.
  • Page 11 G31E-M7 BIOS Manual Serial Port2 Address Select an address and corresponding interrupt fo r the first and second seri al ports. Options: 2F8/IRQ3 (Default) / 3E8/IRQ4 / 2E8/IRQ3 / Disabled Parallel Port Address T his item allows you to determine access onboard p arallel port controller with which I/O Address.

  • Page 12: Hardware Health Configuration

    G31E-M7 BIOS Manual Stroke Keys Selected T his item will show only when Keyboard PowerOn is set “Stroke Key.” Options: Ctrl+F1 (Default) / Wake Key / Power Key / Ctrl+F2 / Ctrl+F3 / Ctrl +F4 / Ctrl+F5 / Ctrl+F6 Mouse PowerOn T his item allows you to control the mouse power on function.

  • Page 13: Smart Fan Configuration

    G31E-M7 BIOS Manual Shutdow n Temperature Function T his item allows you to set up the CPU shutdown T emperature. T his item is only effective under Windows 98 ACPI mode. Options: Disabled (Default) / 60℃/140℉ / 65℃/149℉ / 70℃/158℉ / 75℃/167℉ / 80℃/176℉...

  • Page 14: Power Configuration

    G31E-M7 BIOS Manual Fan Ctrl OFF(℃ ) If the CPU/System T emperature is lower than the set value, FAN will turn off. 0~127 (℃) (Interval: 1℃) Options: Fan Ctrl On(℃ ) CPU/System f an starts to work under smart fan function when arrive this set value. 0~127 (℃) (Interval: 1℃) Options: Fan Ctrl Start Value...
  • Page 15 G31E-M7 BIOS Manual Suspend mode T he item allows you to select the suspend type under the ACPI operating system. Options: S1 (POS) (Default) Power on Suspend S3 (ST R) Suspend to RAM Auto POS+STR Repost Video on S3 Resume T he item allows you to determine whether to invoke VGA BIOS post on S3/ST R resume.
  • Page 16 G31E-M7 BIOS Manual APIC ACPI SCI IRQ Options: Disabled (Default) / Enabled USB Dev ice Wakeup from S3/S4 T his item allows you to enable or disabled the USB resume from S3/S4 function. Options: Disabled (Default) / Enabled High Performance Event Timer T his item allows you to enable or disabled the HPET.

  • Page 17: Usb Configuration

    G31E-M7 BIOS Manual RTC Alarm Time You can choose the system boot up time, input hour, minute and second to specify. USB Configuration T his item shows the USB controller and using USB device information. BIOS S ETUP UTILITY Advanced USB C onfiguration Options Modul e Version - 2 .24.3-13.4...
  • Page 18 G31E-M7 BIOS Manual USB Mass Storage Dev ice Configuration BIOS SETUP UTILITY Advanced USB Mass Storage Device Configuration Number of seconds POST waits for the USB Mass Storage Reset Delay [20 Sec] USB mass storage device after start Device # unit command.

  • Page 19: Pcipnp Menu

    G31E-M7 BIOS Manual 3 PCIPnP Menu T his section describes con figuring the PCI bus system. PCI, or Personal Computer Interconn ect, is a system which allows I/O devices to operate at speeds nearing the speed o f the CPU itself uses when communicating with its own special components. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.

  • Page 20: Pci Latency Timer

    G31E-M7 BIOS Manual PCI Latency Timer T his item controls how long a PCI device can hold the PCI bus bef ore another takes over. T he longer the latency, the longer the PCI device can retain control of the bus before handing it over to another PCI device.

  • Page 21: Reserved Memory Size

    G31E-M7 BIOS Manual IRQ3/4/5/7/9/10/11/14/15 T hese items will allow you to assign each system interrupt a type, depending on the type of device using the interrupt. T he option “Available” means the IRQ is going to assign automatically. Options: Available (Default) / Reserved DMA Channel 0/1/3/5/6/7 T hese items will allow you to assign each DMA channel a type, depending on the type of device using the channel.
  • Page 22 G31E-M7 BIOS Manual SB PCIE Ports Configuration BIOS SETU P U TILITY PCIPnP PCIE Ports Con figuration Options PCIE Port 0 [Aut o] PCIE Port 1 [Aut o] Auto PCIE Port 2 [Aut o] Enabled PCIE Port 3 [Aut o] Disabled PCIE Port 4 [Aut o]...

  • Page 23: Boot Device Priority

    G31E-M7 BIOS Manual 4 Boot Menu T his menu allows you to setup the system boot options. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset Performance Exit Boot Settings Specifies the Boot Device Priority sequence. > Boot Device Priority >...

  • Page 24: Cd/Dvd Drives

    G31E-M7 BIOS Manual CD/DV D Drives T he BIOS will attempt to arrange the CD/DVD drive boot sequence automatically. You can also change the booting sequence. The number of device items that appears on the screen depends on the number of devices installed in the system. Boot Settings Configuration BIOS S ETUP UTILITY Boot...

  • Page 25: Interrupt 19 Capture

    G31E-M7 BIOS Manual Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When set to Enabled, this item allows the option ROMs to trap interrupt 19. Options: Disabled (Default) / Enabled BOOT SUCCESS BEEP When this item is set to Enabled, BIOS will let user know boot success with beep.

  • Page 26: Chipset Menu

    G31E-M7 BIOS Manual 5 Chipset Menu T his submenu allows you to configure the speci fic features of the chipset installed on your system. T his chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.

  • Page 27: North Bridge Configuration

    G31E-M7 BIOS Manual North Bridge Configuration BIOS SETU P U TILITY Chipset North Bridge C hipset Configuratio n ENABLE: Allow remapping of Memory Remap F eature [E nabled] overlapped PCI memory PCI MMIO All ocation: above the total Memory Hole [D isabled] physical memory.

  • Page 28: Video Function Configuration

    G31E-M7 BIOS Manual PEG Port T his BIOS feature is a toggle that enables or disables the PCI Express port. Options: Auto (Default) / Disabled Video Function Configuration BIOS SETU P U TILITY Chipset Video Function Configuration Options DVMT Mode Sele ct [D VMT Mode] Fixed Mode DVMT/FIXED M emory...

  • Page 29: South Bridge Configuration

    G31E-M7 BIOS Manual South Bridge Configuration BIOS SETU P U TILITY Chipset South Bridge C hipset Configuratio n Options USB Functions [8 USB Ports] Disabled USB 2.0 Contro ller [E nabled] 2 USB Ports Audio Controll er [A zalia] 4 USB Ports 6 USB Ports Onboard Lan Co ntrol [E nabled]...

  • Page 30: Onboard Lan Boot Rom

    G31E-M7 BIOS Manual Onboard Lan Boot Rom T his item allows you to select the Onboard LAN Boot ROM. Options: Disabled (Default) / Enabled MAC ID Information T his item shows the LAN MAC ID. SMBUS Controller T his BIOS feature controls the I/O buffers fo r the SMBus. Options: Enabled (Default) / Disabled SLP_S4# Min.

  • Page 31: Performance Menu

    G31E-M7 BIOS Manual 6 Performance Menu T his submenu allows you to change voltage and clock of various devices. (Howev er, we suggest you use the default setting. Changing the voltage and clock improperly may damage the device.) Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.
  • Page 32 G31E-M7 BIOS Manual CPU Voltage T his item allows you to select CPU Voltage Control. Options: Default (Default) / +10% / +25% / +35% FS B Voltage T his item allows you to select FSB Voltage Control. Options: Default (Default) / +0.1V / +0.2V / +0.3V Chipset Voltage T his item allows you to select Chipset Voltage Control.
  • Page 33 G31E-M7 BIOS Manual DRAM RAS# Activate to Precharge Options: 15 DRAM Clocks (Default) / 9 DRAM Clocks / 10 DRAM Clocks / 11 DRAM Clocks / 12 DRAM Clocks / 13 DRAM Clocks / 14 DRAM Clocks...

  • Page 34: Save Changes And Exit

    G31E-M7 BIOS Manual 7 Exit Menu T his menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset Performance Exit Exit Options Exit system setup after saving the...

  • Page 35: Change Supervisor Password

    G31E-M7 BIOS Manual Security T his sub-menu allows you to provide/revise supervisor and user password. BIOS SETU P U TILITY Exit Security Setti ngs Install or Change the password. Supervisor Pas sword :Not Installe d User Password :Not Installe d Change Supervi sor Password User Access Le vel [Ful l Access]...
  • Page 36 G31E-M7 BIOS Manual Passw ord Check T his item is for setting the timing that checking password. Options: Setup (Default) / Always Boot Sector Virus Protection T his option allows you to choose the VIRUS Warning feature that is used to protect the IDE H ard Disk boot sector.
