  6. Owner's operation and installation manual

Desa (V) CD36R(N Owner's Operation And Installation Manual

Direct-vent fireplace dedicated rear and top vent fireplaces
Hide thumbs Also See for (V) CD36R(N:
Table of Contents

Advertisement

Quick Links

See also: Owner's Operating & Installation Manual
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediatly call your gas wupplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
This appliance may be installed in an aftermarket*, permanently located, manufactured
(modile) home, where not prohibited by state or local codes.
This appliance is only for use with the type od gas indicated on the rating plate. This appliance
is not convertible for use with other gases, unless a certified kit is used.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.
State of Massachusetts: The installation must be made by a licensed plumber or gas fitter in
the Commonwealth of Massachusetts.
MODELS: (V) CD36R(N,P) (E)
FOR YOUR SAFETY
Save this manual for future reference.
For more information, visit www.desatech.com
DIRECT-VENT FIREPLACE
OWNER'S OPERATION AND
INSTALLATION MANUAL
DEDICATED REAR AND TOP VENT FIREPLACES
MODELS: (V) CD36T(N,P) (E)
WARNING: Improper installation
adjustment, alteration, service,
or maintenance can cause injury
or property damage. Refer to this
manual for correct installation and
operational procedures. For as-
sistance or additional information
consult a qualified installer, ser-
vice agency, or the gas supplier.
Installation and service must be
performed by a qualified in-
staller, service agency, or the
gas supplier.
