UNVeNTed (VeNT-Free) Gas ComPaCT ClassiC hearTh
dUal BUrNer dUal FUel FirePlaCe
oWNer's oPeraTioN aNd iNsTallaTioN maNUal
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
ThermosTaT model CCFPdFT
Fireplace/Mantel Assembly CFDFM Shown
For more information, visit www.desatech.com
®
Advertisement
Table of Contents
Related Manuals for Desa CCFPDFT
Summary of Contents for Desa CCFPDFT
- Page 1 UNVeNTed (VeNT-Free) Gas ComPaCT ClassiC hearTh ® dUal BUrNer dUal FUel FirePlaCe oWNer’s oPeraTioN aNd iNsTallaTioN maNUal ThermosTaT model CCFPdFT Fireplace/Mantel Assembly CFDFM Shown WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TaBle oF CoNTeNTs Safety ..............2 Inspecting Burners..........22 Product Identification ........... 4 Cleaning and Maintenance ........ 23 Local Codes............5 Troubleshooting ..........24 Product Features ..........5 Parts ..............28 Qualified Installing Agency ........5 Replacement Parts ..........32 Unpacking............ -
Page 3: With Fireplace
saFeTy Continued Do not place clothing or other DANGER: Carbon monoxide flammable material on or near poisoning may lead to death! the appliance. Never place any objects on the heater. Carbon Monoxide Poisoning: Early signs of carbon monoxide poisoning resemble the flu, with headaches, dizziness or nausea. -
Page 4: Product Identification
saFeTy Continued 5. Do not use this fireplace as a wood-burn- 11. Do not run fireplace ing fireplace. Use only the logs provided • where flammable liquids or vapors are with the fireplace. used or stored. 6. Do not add extra logs or ornaments such as •... -
Page 5: Local Codes
Log is wrapped and inside fireplace. Do not remove at this time. 4. Check fireplace for any shipping damage. If fireplace is damaged, call DESA Heat- 2. Remove all protective packaging applied ing, LLC at 1-866-672-6040 for replace- to fireplace for shipment. -
Page 6: Air For Combustion And Ventilation
air For ComBUsTioN aNd VeNTilaTioN Unusually tight construction is defined as WARNING: This heater shall construction where: not be installed in a room or space a. walls and ceilings exposed to the out- side atmosphere have a continuous unless the required volume of in- water vapor retarder with a rating of one door combustion air is provided perm (6 x 10... - Page 7 air For ComBUsTioN aNd VeNTilaTioN Continued Example: Space size 16 ft. (length) x 14 ft. If the actual Btu/Hr used is less than the maxi- (width) x 8 ft. (ceiling height) = 1792 cu. ft. mum Btu/Hr the space can support, the space is (volume of space) an unconfined space.
-
Page 8: Installation
air For ComBUsTioN aNd VeNTilaTioN Continued Ventilation Air From Outdoors Provide extra fresh air by using ventilation Ventilated Outlet Attic grills or ducts. You must provide two perma- nent openings: one within 12" of the ceiling Outlet and one within 12" of the floor. Connect these To Attic items directly to the outdoors or spaces open to the outdoors. - Page 9 iNsTallaTioN Continued Note: When installing fireplace directly on HOOD ASSEMBLy carpeting, tile or other combustible material, WARNING: Always have other than wood flooring, the fireplace shall be installed on a metal or wood panel extending hood in place before operating the full width and depth of the fireplace.
-
Page 10: Fireplace Clearances
iNsTallaTioN Continued FIREPLACE CLEARANCES C. For mantel clearances, see Figure 9 on page 12. WARNING: Maintain the MINIMUM CLEARANCE TO minimum clearances shown COMBUSTIBLE MATERIALS in Figure 5. If you can, provide Top 36", Left and Right Sides 6", greater clearances from floor, Bottom and Rear 0", Front 36"... - Page 11 iNsTallaTioN Continued Note: If not installing blower accessory, gypsum board, sheet rock, drywall, plywood, you may wish to run electrical wiring to etc. may be butted up next to the sides and your fireplace for future blower installation top edge of the firebox. Combustible materi- (see Accessories, page 33).
- Page 12 iNsTallaTioN Continued NOTICE: If your installation does WARNING: Do not allow not meet the minimum clear- combustible or noncombustible ances shown, you must do one materials to cover any necessary of the following: openings like louvered slots. • raise the mantel to an accept- able height WARNING: Never modify or •...
- Page 13 iNsTallaTioN Continued GAS SELECTION 4. Remove pipe plug from natural gas regu- lator (see Figure 12). CAUTION: Two gas line in- 5. Apply pipe sealant to 3/8" NPT pipe plug stallations at the same time are and install in propane/LP regulator. forbidden.
- Page 14 iNsTallaTioN Continued Changing from Natural Gas to Operation 7. Install flex line and brass fitting into pro- on Propane/LP Gas (for Previously pane/LP gas regulator. Installed Log Sets) 8. Remove set screw from selector valve 1. Carefully remove logs from firebox. linkage (see Figure 13).
- Page 15 iNsTallaTioN Continued Log set is equipped with a CAUTION: Never connect system to turn off log set if not propane/LP fireplace directly converted correctly. If the tem- to the propane/LP supply. This perature switch requires reset- fireplace requires an external ting, press button (see Figure regulator (not supplied).
- Page 16 iNsTallaTioN Continued Installation must include an equipment shutoff CONNECTING EQUIPMENT valve, union and plugged 1/8" NPT tap. Locate SHUTOFF VALVE TO HEATER NPT tap within reach for test gauge hook up. CONTROL NPT tap must be upstream from heater (see Installation Items Needed Figure 16).
- Page 17 iNsTallaTioN Continued PRESSURE TESTING GAS SUPPLy 4. Check all gas connections for leaks. See PIPING SySTEM Checking Gas Connections, below. Feed Test Pressures In Excess Of 1/2 PSIG flexible gas line into fireplace. Make sure (3.5 kPa) the entire flexible gas line is in fireplace. 1.
- Page 18 iNsTallaTioN Continued PRESSURE TESTING FIREPLACE GAS INSTALLING LOG SET AND SCREEN CONNECTIONS 1. Remove log packaging material and dis- 1. Open equipment shutoff valve (see Figure card. Gently place log over burner. Place 19, page 17). front of log onto pin on firebox floor (see 2.
-
Page 19: Operation
iNsTallaTioN Continued ASSEMBLING AND INSTALLING TRIM Align hanging notches on trim with hang- ing screws on side of fireplace (see Figure 1. Remove packaging from 3 pieces of 25). Push trim firmly into place, sliding trim. hanging notches over hanging screws. 2. - Page 20 oPeraTioN Continued LIGHTING Note: You may be running this fireplace for the first time after hooking up to gas INSTRUCTIONS supply. If so, the control knob may need to be pressed in for 30 seconds or more. WARNING: You must operate This will allow air to bleed from the gas this fireplace with the screen system.
-
Page 21: Specifications
3. Keep control knob pressed in for 30 sec- onds after lighting pilot. After 30 seconds, release control knob. Now follow step 8 under Lighting Instructions, page 20. sPeCiFiCaTioNs Model CCFPDFT • Gas Type Natural Propane/LP • Input Max. 26,000 Btu/Hr 26,000 Btu/Hr •... -
Page 22: Inspecting Burners
iNsPeCTiNG BUrNers Check pilot flame pattern and burner flame Note: The pilot flame on natural gas units will patterns often. have a slight curve, but flame should be blue and have no yellow or orange color. PILOT FLAME PATTERN BURNER FLAME PATTERN Figure 29 shows a correct pilot flame pattern. -
Page 23: Cleaning And Maintenance
CleaNiNG aNd maiNTeNaNCe 4. Check injector holder located at the end WARNING: Turn off fireplace of burner tube again. Remove any large and let cool before cleaning. particles of dust, dirt, lint or pet hair with a soft cloth or vacuum cleaner nozzle. 5. -
Page 24: Troubleshooting
TroUBleshooTiNG WARNING: Turn off and unplug fireplace and let cool before servicing. Only a qualified service person should service and repair fireplace. CAUTION: Never use a wire, needle or similar object to clean ODS/pilot. This can damage ODS/pilot unit. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY... - Page 25 TroUBleshooTiNG Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY ODS/pilot lights but flame 1. Control knob not fully 1. Press in control knob fully goes out when control knob pressed in is released 2. Control knob not pressed in 2. After ODS/pilot lights, keep long enough control knob pressed in 30 seconds...
- Page 26 TroUBleshooTiNG Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Slight smoke or odor during 1. Residues from manufac- 1. Problem will stop after a few initial operation turing processes and log hours of operation curing 2. Not enough air 2. Check burner for dirt and debris.
- Page 27 TroUBleshooTiNG Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions.
-
Page 28: Parts
ParTs FIREBOx MODEL CCFPDFT www.desatech.com 123721-01E... - Page 29 ParTs FIREBOx MODEL CCFPDFT This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 32 of this manual. NO. PART NO. DESCRIPTION QTy. Outer Casing Top Baffle Outer Casing...
- Page 30 ParTs BURNER ASSEMBLy MODEL CCFPDFT 30 29 www.desatech.com 123721-01E...
- Page 31 ParTs BURNER ASSEMBLy MODEL CCFPDFT This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 32 of this manual. NO. PART NO. DESCRIPTION 123697-01 Dual Burner 099056-34 Injector 123635-01 Outlet Tube...
-
Page 32: Replacement Parts
• for propane/LP units, propane/LP gas sup- ply may be low TeChNiCal serViCe You may have further questions about installa- You can also visit DESA Heating, LLC’s web tion, operation, or troubleshooting. If so, con- site at www.desatech.com. tact DESA Heating, LLC at 1-866-672-6040. -
Page 33: Accessories
Purchase these accessories from your local dealer. If they can not supply these accessories call DESA Heating, LLC at 1-866-672-6040 for THERMOSTAT-CONTROLLED information. You can also write to the address BLOWER KIT - GA3450TA listed on the back page of this manual. - Page 34 NoTes _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ www.desatech.com 123721-01E...
- Page 35 NoTes _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 123721-01E www.desatech.com...
-
Page 36: Warranty
This is DESA Heating, LLC’s exclusive warranty, and to the full extent allowed by law; this express warranty excludes any and all other warranties, express or implied, written or verbal and limits the duration of any and all implied warranties, including warranties of merchantability and fitness for a particular purpose to one (1) year on new products and 30 days on factory reconditioned products from the date of first purchase.
