Siemens SIMATIC NET SCALANCE X108PoE 6GK5108-0PA00-2AA3 Operating Instructions Manual
Industrial ethernet
Hide thumbs
Also See for SIMATIC NET SCALANCE X108PoE 6GK5108-0PA00-2AA3:
- Operating instructions manual (80 pages)
Table of Contents
Advertisement
Advertisement
Table of Contents
Related Manuals for Siemens SIMATIC NET SCALANCE X108PoE 6GK5108-0PA00-2AA3
Summarization of Contents
Introduction to SCALANCE X-100
Overview and Manual Purpose
Provides an overview of the manual, its purpose, validity, and intended audience.
Further Documentation and Information Access
Guides users to additional resources and methods for finding information within the manual.
Standards, Approvals, and Product Capabilities
Details standards met, approvals, and the capabilities of the SCALANCE X-100.
SCALANCE X Product Family Overview
Introduces the SCALANCE X product family, including specific models like X005, X-100, X-200, X-200IRT, and X-400.
Connectivity to Corporate Networks
Explains how SCALANCE X-400 switches connect to corporate networks via IT standards.
Network Topologies with SCALANCE X-100
Topology Implementation Options
Discusses the implementation of bus and star topologies, with a focus on bus topology.
Star Topology Examples
Illustrates electrical and electrical/optical star topologies using SCALANCE switches.
SCALANCE X-100 Product Properties
Product Characteristics and Connection Options
Compares product features and connection options across SCALANCE models.
Product Components and Handling
Details product components and provides unpacking/checking instructions.
SCALANCE X104-2 Overview
Details characteristics and possible connections for the SCALANCE X104-2.
SCALANCE X104-2 TP Ports
Describes the connector pinout for the RJ-45 TP ports on the SCALANCE X104-2.
SCALANCE X104-2 Port Features
Explains autonegotiation, auto polarity exchange, and MDI/MDIX functions for X104-2.
SCALANCE X104-2 FO Port Specifications
Details transmission rate, mode, medium, range, and connectors for FO ports.
SCALANCE X106-1 Overview
Details characteristics and possible connections for the SCALANCE X106-1.
SCALANCE X106-1 TP Ports
Describes the connector pinout for the RJ-45 TP ports on the SCALANCE X106-1.
SCALANCE X106-1 Port Features
Explains autonegotiation, auto polarity exchange, and MDI/MDIX functions for X106-1.
SCALANCE X106-1 FO Port Specifications
Details transmission rate, mode, medium, range, and connectors for FO ports.
SCALANCE X108 Overview
Details characteristics and possible connections for the SCALANCE X108.
SCALANCE X108 TP Ports
Describes the connector pinout for the RJ-45 TP ports on the SCALANCE X108.
SCALANCE X108 Port Features
Explains autonegotiation, auto polarity exchange, and MDI/MDIX functions for X108.
SCALANCE X108 PoE Overview
Details characteristics and possible connections for the SCALANCE X108 PoE.
SCALANCE X108 PoE TP Ports
Describes the connector pinout for the RJ-45 TP ports on the SCALANCE X108 PoE.
SCALANCE X108 PoE Functionality
Explains Power-over-Ethernet functionality, autonegotiation, and MDI/MDIX for X108 PoE.
SCALANCE X112-2 Overview
Details characteristics and possible connections for the SCALANCE X112-2.
SCALANCE X112-2 TP Ports
Describes the connector pinout for the RJ-45 TP ports on the SCALANCE X112-2.
SCALANCE X112-2 Port Features
Explains autonegotiation, auto polarity exchange, and MDI/MDIX functions for X112-2.
SCALANCE X112-2 FO Port Specifications
Details transmission rate, mode, medium, range, and connectors for FO ports.
SCALANCE X116 Overview
Details characteristics and possible connections for the SCALANCE X116.
SCALANCE X116 TP Ports
Describes the connector pinout for the RJ-45 TP ports on the SCALANCE X116.
SCALANCE X116 Port Features
Explains autonegotiation, auto polarity exchange, and MDI/MDIX functions for X116.
SCALANCE X124 Overview
Details characteristics and possible connections for the SCALANCE X124.
SCALANCE X124 TP Ports
Describes the connector pinout for the RJ-45 TP ports on the SCALANCE X124.
SCALANCE X124 Port Features
Explains autonegotiation, auto polarity exchange, and MDI/MDIX functions for X124.
SCALANCE X-100 Button Operation
Explains the function of the device button for fault mask display and modification.
Fault and Power Status Indicators
Explains the meaning of the red fault LED and the power supply LEDs.
Port Status Indicators
Explains the status indications of the two-color port LEDs.
Installation, Connection, and Troubleshooting
Assembly and Mounting Options
Outlines assembly procedures and different mounting types (DIN rail, S7 rail, wall).
DIN Rail Installation Procedure
Provides step-by-step instructions for mounting on a 35 mm DIN rail.
Standard Rail Installation Procedure
Provides instructions for mounting on a SIMATIC S7-300 standard rail.
Wall Mounting Procedure
Details the process and requirements for wall mounting the device.
Electrical Connections and Power Supply
Explains how to connect the power supply, including redundant options.
Signaling Contact Functionality
Describes the floating switch for signaling error/fault states.
Grounding Procedures
Explains grounding procedures for different installation types.
RJ-45 Plug Assembly and Removal
Details the assembly, insertion, and removal of the IE FC RJ-45 Plug.
Troubleshooting Common Issues
Covers fuses, optical port link display, and voltage drop issues.
Approvals and Markings
Product Identification and Guidelines
Lists product names, EMC guidelines, application areas, installation rules, and conformity certificates.
Machine Manufacturer Notes and Certifications
Clarifies product status regarding EC Machinery Directive and lists various certifications.
Technical Specifications
Connector Specifications
Details the types and quantities of connectors for each SCALANCE device.
Electrical and Cable Data
Provides electrical specs, signaling contact data, and copper cable length limits.
Fiber Optic Cable Lengths and Environmental Conditions
Details fiber optic cable lengths, aging time, MAC addresses, MTBF, and environmental limits.
Accessory Order Numbers
Lists order numbers for accessories and manuals.
Frame Propagation Time Considerations
Explains how the number of switches affects frame propagation time.
References
Related Information Sources
Lists related manuals and guidelines for further information.
Dimension Drawings
SCALANCE X104-2, X106-1, X108, X108PoE Dimensions
Shows the physical dimensions for specific SCALANCE models.
SCALANCE X116, X112-2 Rear View Dimensions
Displays the rear view dimensions for X116 and X112-2 models.
SCALANCE X124 Rear View Dimensions
Shows the rear view dimensions for the SCALANCE X124 model.
SCALANCE X-100 Side View Dimensions
Illustrates the side view dimensions of the SCALANCE X-100 series.
Cable Bending Radii and Clearances
Depicts recommended bending radii and clearances for cabling.
Glossary of Terms
Key Terminology Definitions (A-F)
Defines key terms such as Aging time, Autocrossover, Autonegotiation, C-PLUG, CRC, Fault mask, FO, IRT.
Key Terminology Definitions (M-S)
Defines key terms such as Monomode, Multicast, Multimode, Power over Ethernet, Reconfiguration time, Redundancy manager, Segment, Signaling contact.
Key Terminology Definitions (S-T)
Defines key terms such as Single mode, SNMP, Store and forward, TP, TP port.
