This section also provides information on configuring communication settings, selecting a network
port for communication, and managing security certificates.
2.14.8.1

Secure communication

Acronis Backup & Recovery 10 provides the capability to secure the data transferred between its
components within a local area network and through a perimeter network (also known as
demilitarized zone, DMZ).
There are two mechanisms which ensure secure communication between Acronis Backup &
Recovery 10 components:
 Secure authentication provides secure transfer of certificates needed to establish a connection,
by using the Secure Sockets Layer (SSL) protocol.
 Encrypted communication provides secure transfer of information between any two
components—for example, between Acronis Backup & Recovery 10 Agent and Acronis Backup &
Recovery 10 Storage Node—by encrypting the data being transferred.
For instructions on how to set up secure authentication and data encryption settings, see Configuring
communication options (p. 84).
For instructions on how to manage SSL certificates used for secure authentication, see SSL
certificates (p. 87).
Note: The components of earlier Acronis products, including those of the Acronis True Image Echo family,
cannot connect to the Acronis Backup & Recovery 10 components, regardless of the secure authentication and
data encryption settings.
2.14.8.2

Client and server applications

There are two stakeholders of the secure communication process:

Client application, or client, is an application that tries to establish connection.

Server application, or server, is an application to which the client tries to connect.
For example, if Acronis Backup & Recovery 10 Management Console is connecting to Acronis Backup
& Recovery 10 Agent on a remote machine, the former is the client and the latter is the server.
An Acronis component can act as a client application, a server application, or both, as shown in the
following table.
Component name
Acronis Backup & Recovery 10
Management Console
Acronis Backup & Recovery 10 Agent
Acronis Backup & Recovery 10
Management Server
Acronis Backup & Recovery 10 Storage
Node
Acronis PXE Server
Copyright © Acronis, Inc., 2000-2010
Can be Can be
client server
Yes No
Yes Yes
Yes Yes
Yes Yes
No Yes
83
