Virtual Machines - ACRONIS Backup & Recovery 10 Advanced Server Virtual Edition User Manual

group.
Examine where the policy
applied to the group came
from
Filtering and sorting
Filtering and sorting of the backup policies is performed in the same way as for the Backup policies
view. See the Filtering and sorting backup policies (p. 290) section for details.
Inheritance order
The Inheritance order window lets you examine where the policy applied to the group came from.
The policy that is directly applied to the group is displayed as follows:
Group name
The following example illustrates how the policy that is applied on the group through inheritance is
displayed.
Group1 > Group2 > Group3
Group1 in the root contains Group2 to which the policy is applied directly. Group2, in turn, contains
child Group3 that inherits the policy from the parent.
The group to which the policy was applied directly is boldfaced and marked with an icon.
All items are interactive, i.e. when you click on a group, its parent group view will be opened.
7.1.4

Virtual machines

You can centrally manage virtual machines using either of the following methods or both:
Adding a virtual machine as a physical machine
Install Acronis Backup & Recovery 10 Agent for Windows or Agent for Linux on the virtual machine
and register (p. 295) it on the management server. The machine will be treated as a physical one. You
will be able to apply any backup policy to the machine, including policies that back up files.
This approach comes in handy when:

the machine is not hosted on a virtualization server

the virtualization product installed on the host server is not supported by Acronis Backup &
Recovery 10 Advanced Server Virtual Edition

you want to use pre/post backup or pre/post data capture commands on the machine

you want to apply file backup policies to the machine.
Adding a virtual machine as a virtual machine
On Acronis Backup & Recovery 10 Management Server, a machine is considered virtual if it can be
backed up from the virtualization host without installing an agent on the machine. This is possible
when using Acronis Backup & Recovery 10 Advanced Server Virtual Edition. A virtual machine
appears on the management server after registration of the virtualization server that hosts the
Copyright © Acronis, Inc., 2000-2010
The management server revokes the policy from the group. While the changes
are being transferred to the machines and the agents are deleting the backup
plans, the policy state of the group is Revoking.The policy itself remains on the
management server.
Click Explore inheritance.
The Inheritance order (p. 309) window will display the inheritance order of the
policy applied to the group.
309
