Side view

Side components
1. Lock slot
2. Home button
3. Menu button
4. Volume/brightness buttons
5. Indicators
6. Power switch

Navigation, Control Buttons

The external buttons have different function in different OS.
Button Icon Location
Home Top
Menu Top
Volume- Top
7. Back button
8. Power jack
9. Audio output jack
10. USB ports
11. Memory card slot
12. 3G SIM card slot(Optional)
Function in Windows
Short press:
Go to desktop
Press and hold for 3
seconds:
Turn on/off light sensor
Ctrl+Alt+Delete
Short press:
volume decrease;
Press and hold for 3
seconds:
brightness decrease.
4
13. Docking connector
14. MIC
15. Lock switch
16. Reset eject hole
ANDR OI D
Go to home screen
Open Menu
Short press:
volume decrease
Function
in DOS
UP Arrow
Down Arrow
Left Arrow
