MANUAL FOR INSTALLATION, USE AND
MAINTENANCE
PURE L and PURE XL
Congratulations!
You have chosen an appliance of the Jidé range and we would like to thank you for it. We
are convinced that it will bring you warmth and comfort. In order to derive the greatest
benefit from your fireplace, we greatly stress the importance of following the instructions
and recommendations given in this notice.
Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 –
www.jide.be
-
info@jide.be
PURE (EN) June 2018
Advertisement
Table of Contents
Related Manuals for Jide PURE XL
Summary of Contents for Jide PURE XL
- Page 1 MANUAL FOR INSTALLATION, USE AND MAINTENANCE PURE L and PURE XL Congratulations! You have chosen an appliance of the Jidé range and we would like to thank you for it. We are convinced that it will bring you warmth and comfort. In order to derive the greatest benefit from your fireplace, we greatly stress the importance of following the instructions and recommendations given in this notice.
-
Page 2: Table Of Contents
PRODUCT FICHE – EU 2015/1186 ......................27 WARRANTY ............................28 Warranty agreement ............................28 Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... -
Page 3: Introduction
A list of our dealers-installers is available on our site www.jide.be/en. Before using your fireplace for the first time and in order to guarantee its good usage and operation over time, we suggest you carefully read these instructions for use in order to familiarise yourself with its various functions and characteristics. -
Page 4: Technical Characteristics And Compliance
Ecological solution: cleaner emissions, less dust and CO Economic: greatly reduced wood consumption. Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... - Page 5 In both cases, keep the face of the air box. Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018...
- Page 6 European EN standards on safety and efficiency while limiting CO emissions. Test results according to the standards: EN 13229:2001 - EN 13229/A1:2003 – EN 13229/A2:2004 PURE L 67 PURE L 90 Nominal power: 9-12 kW Nominal power: 11-13 kW...
-
Page 7: Additional Parts - Identification Plate
(traceability) if necessary. We advise you to paste it on this user and installation notice or on your invoice. Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... -
Page 8: User Notice
We advise you to use fire starter cube which facilitate a quicker and cleaner wood combustion. Do not use inflammable liquid products. Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... -
Page 9: Combustion
These 2 hot air outlets must be plugged to at least 1 meter flexible diameter 125 Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be... - Page 10 NEVER use flammable liquid products (ex: methanol) to light the fire or reactivate the fire! Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018...
-
Page 11: The Wood - Choice And Usage
Birch ....................300 – 400 kg per m³ Poplar ....................250 – 350 kg per m³ Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... - Page 12 Loading of the fireplace with wood: PURE L 67 ..............3 kg (maximum) of dry wood per hour PURE L 90 ............. 3,5 kg (maximum) of dry wood per hour PURE XL 77 ............3,5 kg (maximum) of dry wood per hour PURE XL 16/9 ............
-
Page 13: Installation Notice
The fireplace emits heat by radiation through the window and by air convection. It is thus essential to provide non-inflammable materials in the distribution zone. Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... - Page 14 The chimney must have a normal pulling i.e. that with its power maximum, the depression will have to range between 12 and 20 Pa. Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018...
-
Page 15: Fitting
The clips are located outside the body. Right fitting Wrong fitting Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... -
Page 16: Fitting Of The Chimney Connection
These 2 hot air outlets must be plugged to at least 1 meter flexible diameter 125 Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be... -
Page 17: Fitting Of The Combustion Air Intake
(blow the cover and plug the rear entrance). In this case, keep the front face of the air box. Back face Below Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... -
Page 18: Electrical Connection
Your appliance is equipped with fans controlled by a speed controller. This is the diagram for their electrical connection. Attention: disconnect the power before working on the electrical. Pure L 67 L 90 XL 77 XL 16/9 Speed controller (with a 1,5 ampere fuse) Airstat (thermal contact) Fan of 140 m³/h (power: 24 W) -
Page 19: Vermiculite Removing
3 Remove the bottom vermiculite 4 Remove the back vermiculite 5 Unscrew and remove the back plates Ventilation access Integrated ventilation and airstat access for Pure L 67 L 90 XL 77 XL 16/9 Unscrew and remove Remove the fans right and left plates You have now the possibility to clean the fan. -
Page 20: Manual Setting Air Inlet Access
Complementary products used for the installation must be conform to local regulations. Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... -
Page 21: Maintenance Of The Fireplace
Unscrew the nut with a spanner (8), rotate the eccentric to the back of the appliance and screw back the nut. Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... - Page 22 Vacuum three or four times per year the residues above the baffle. Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018...
-
Page 23: Troubleshooting
- Negligence with the sweeping - Respect the normal frequency of the sweeping Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... - Page 24 - Sanding and repainting - Respect the maximum loading of wood per hour Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018...
-
Page 25: Declaration Of Conformity Jidé
According to the test report issued by the A.R.G.B. laboratories (Royal association of Belgian gas-fitters) meeting the European EN 13229/A2 standard, it was stated that: The power in kW for: Pure L 67 ............................9 to 12 kW Pure L 90 ............................. 11 to 13 kW Pure XL 77 ..........................11 to 13 kW Pure XL 16/9 .......................... -
Page 26: Ce Marking
CE MARKING Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... -
Page 27: Product Fiche - Eu 2015/1186
PRODUCT FICHE – EU 2015/1186 Jidé SA Pure L 67 – Pure L 90 – Pure XL 77 – Pure XL 16-9 Energy efficiency class : ………………………………………………………………………………………….A+ Direct heat output : Pure L 67 :…………………………………………………………………………………………………9 to 12 kW Pure L 90 :……………………………………………………………………………………………….11 to 13 kW Pure XL 77 :……………………………………………………………………………………………..11 to 13 kW... -
Page 28: Warranty
Overload of the fireplace with wood compared to the permitted limits; Intentional and permanent interruption of the ventilation. Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018... - Page 29 The warranty is only provided through the dealer-agent on presentation of the purchase invoice. Jidé S.A. reserves the right to modify its products and brochures at any time at its sole discretion. Jidé Model: PURE L and XL Purchaser: Surname ………………………………………….. Forename…………………………………… Address ………………………………………………………………………………………… Postcode ……………… City ………………………………………………………….
- Page 30 ..............................……………………………………………………………………………………………………………………………………………............................................................……………………………………………………………………………………………………………………………………………............................................................……………………………………………………………………………………………………………………………………………........................................................................................................................Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018...
- Page 31 Jidé s.a. – Rue des Meuneries 11 – B-4650 HERVE (Belgique) – Tél. +32 87 31.75.12 – Fax +32 87 31.75.11 – www.jide.be info@jide.be PURE (EN) June 2018...
