Summarization of Contents
Intended use
Appliance purpose and limitations
Appliance for domestic use, up to 2000m, may be used by children/persons with reduced capabilities under supervision.
Important safety information
Danger of suffocation!
Packaging material is dangerous to children; never let them play with it.
Danger of death from flue gases!
Risk of poisoning from flue gases drawn back in; ensure adequate fresh air.
Risk of fire!
Grease deposits in filters can catch fire; clean filters regularly and avoid naked flames.
Important safety information
Risk of burns!
Accessible parts become hot; never touch hot parts and keep children away.
Risk of injury!
Sharp edges inside; wear gloves. Items may fall; do not place objects on appliance.
Risk of electric shock!
Defective appliance or incorrect repairs can cause shock. Unplug/switch off before servicing.
Causes of damage
Damage prevention tips
Avoid corrosion, electronic damage, and surface damage by proper cleaning and installation.
Environmental protection
Energy saving and disposal
Tips for saving energy during use and advice on environmentally-friendly disposal.
Operating modes
Exhaust air and recirculation
Explanation of exhaust air mode and air recirculation mode functionalities.
Operating the appliance
Control panel and fan functions (Model 1)
Overview of Model 1 control panel, fan speed, intensive, and run-on time settings.
Lighting, saturation, and signals (Model 1)
Control lighting, view filter saturation, reset indicators, and manage audible signals.
Operating the appliance
Control panel and fan functions (Model 2)
Overview of Model 2 control panel, fan speed, intensive, and boost settings.
Lighting, saturation, and signals (Model 2)
Control lighting, view filter saturation, reset indicators, and manage audible signals.
Cleaning and maintenance
Safety precautions for cleaning
Warnings for burns, electric shock, injury, and proper cleaning agents to avoid damage.
Cleaning metal mesh grease filters
Instructions for cleaning metal mesh grease filters manually or in dishwasher.
Trouble shooting
Safety during troubleshooting
Warning about electric shock from incorrect repairs; handle LED lights safely.
Common malfunctions and solutions
Table of common problems, possible causes, and solutions for appliance malfunctions.
Customer service
Contacting after-sales service
Information on calling for support, including product number and potential charges.
Accessories
Available optional accessories
List of optional accessories like starter sets, frames, and handle strips with order numbers.
INSTALLATION INSTRUCTIONS
Installation details for 60 cm width
Diagrams and required parts for installing a 60 cm wide appliance.
Installation details for 90 cm width
Diagrams and required parts for installing a 90 cm wide appliance.
Important safety information
Risk of death from flue gases (1)
Warning about flue gas poisoning if exhaust air is not properly vented.
Risk of death from flue gases (2)
Ensure adequate fresh air for room air-dependent appliances to prevent flue gas poisoning.
Risk of death from flue gases (3)
Ensure electrical safety switch for hood connected to heat-producing appliances/chimneys.
General information
Fire and injury prevention
Safety warnings for fire risk, injury from sharp edges, and appliance stability.
Electrical safety and packaging
Warnings about electric shock from cable damage, proper connection, and suffocation from packaging.
Exhaust duct requirements
Notes on pipe section warranty, recommended diameters, material, and flat duct specifications.
General information
Electrical connection safety
Warnings about electric shock from cable damage and requirements for safe electrical connection.
Preparing the unit and clearances
Guidelines for fitting unit levelness, load capacity, heat resistance, and safety clearances.
General information
Mounting piece installation (16mm wall)
Steps for attaching mounting pieces to a 16 mm thick body wall.
Mounting piece installation (19mm wall)
Steps for attaching mounting pieces to a 19 mm thick body wall.
Appliance preparation
Instructions for attaching a handle strip and connecting the power cord with strain relief.
Installation
Sliding appliance into place
Steps for sliding the appliance into position and marking/shortening the filler strip.
Sliding appliance out
Instructions on how to release fastening bolts to remove the appliance.
Installation
Securing filler strip and cabinet
Steps for fully screwing in filler strip and securing 90cm appliance to cabinets.
Final fitting and electrical connection
Steps for locking bolts, fitting caps, and establishing the electrical connection.
Adjusting filter pull-out stop
Instructions on how to adjust the filter pull-out limit stop using spacers.
Installation
Connecting exhaust pipes
Instructions for connecting 150mm and 120mm exhaust air pipes.
Removing the appliance
Steps to disconnect electrical, pipes, remove filter, caps, and then the appliance.
