- Page 1 Extractor hood LB57574.., LB78574.., LB88574 User manual and installation instructions Register your product on My Siemens and discover exclusive ser- vices and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
en Safety Table of contents Do not use the appliance: ¡ With an external timer. INFORMATION FOR USE 1.3 Restriction on user group Safety .............. 2 This appliance may be used by children aged 8 or over and by people who have reduced Avoiding material damage........ 4 physical, sensory or mental abilities or inad- Environmental protection and saving en-... -
Page 3: Safety
Safety en ▶ Clean the grease filters regularly. WARNING ‒ Risk of poisoning! ▶ Never work with naked flames close to the Risk of poisoning from flue gases being appliance (e.g. flambéing). drawn back in. Room-air-dependent heat-pro- ▶ Do not install the appliance near a solid ducing appliances (e.g. -
Page 4: Avoiding Material Damage
en Avoiding material damage The filter cover may swing out. WARNING ‒ Risk of explosion! ▶ Open the filter cover slowly. Highly caustic alkaline or highly acidic clean- ▶ Take hold of the filter cover after opening ing agents in conjunction with aluminium parts until it no longer swings out. -
Page 5: Setting The Saturation Indicator
Setting the saturation indicator en 3.2 Saving energy Switch off the lighting if it is no longer required. ¡ When the lighting is switched off, it does not con- If you follow these instructions, your appliance will use sume any energy. less power. Clean or replace the filters at regular intervals. -
Page 6: Accessories
You can find out which accessories are available for (replacement) your appliance in our catalogue, in the online shop or LongLife air recirculation LZ11ITD11 from our after-sales service. www.siemens-home.bsh-group.com Long Life odour filter (re- LZ10ITP00 placement) 7 Basic operation 7.1 Switching on the appliance 7.4 Switching on intensive mode... -
Page 7: Cleaning And Servicing
Cleaning and servicing en Open the filter cover by pulling it downwards. WARNING ‒ Risk of electric shock! An ingress of moisture can cause an electric shock. Before cleaning, pull out the mains plug or switch ▶ off the fuse in the fuse box. Do not use steam- or high-pressure cleaners to ▶... - Page 8 en Cleaning and servicing Guide the odour filter around the motor. ATTENTION! The grease filters may become damaged if they are squeezed. Do not squeeze the grease filters. ▶ Note: When cleaning the grease filter in the dish- washer, light discolouration may occur. This discoloura- tion has no effect on the performance of the metal grease filters.
-
Page 9: Troubleshooting
Troubleshooting en Carefully slide the odour filter into the holder. Install the grease filters. 9 Troubleshooting You can rectify minor faults on your appliance yourself. WARNING ‒ Risk of electric shock! Read the troubleshooting information before contacting Incorrect repairs are dangerous. after-sales service. This will avoid unnecessary costs. Repairs to the appliance should only be carried out ▶... -
Page 10: Customer Service
en Customer Service 11 Customer Service Function-relevant genuine spare parts according to the The contact details for Customer Service can be found corresponding Ecodesign Order can be obtained from in the enclosed Customer Service directory or on our Customer Service for a period of at least 10 years from website. -
Page 11: Installation Instructions
Installation instructions en Risk of poisoning from flue gases being 12.4 Secure installation drawn back in. Follow these safety instructions when in- ▶ If an extractor hood with an open-flued heat stalling the appliance. production source is installed, the power WARNING ‒ Risk of poisoning! supply for the extractor hood must be Risk of poisoning from flue gases being provided with a suitable safety switch. - Page 12 en Installation instructions The appliance may fall down if it has not been ¡ The surfaces of the appliance are sensitive. Avoid damaging them during installation. properly fastened in place. ▶ All fastening components must be fixed 12.6 Instructions for the electrical firmly and securely in place.
- Page 13 Installation instructions en Round pipes Make the cut-out for the exhaust air pipe either above the fitted unit or behind the fitted unit. Use round pipes with an inner diameter of 150 mm (re- commended) or at least 120 mm. Flat ducts Use flat ducts with an inner cross-section that corres- ponds to the diameter of the round pipes: ¡...
- Page 14 en Installation instructions Undo the hinge lock and remove the filter cover. Installing the appliance Insert the appliance into the opening in the fitted unit and screw it to the fitted unit . Remove the grease filters. To avoid causing damage, do not bend the grease filters.
- Page 15 Installation instructions en Restore the control panel cabling and the cabling Connect the pipe to the opening on the fitted unit. for the lighting. Screw the air guide grille to the fitted unit. The plug can only be inserted into one position. Seal the joints.
- Page 16 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001604647* 9001604647 (030222)
