Summarization of Contents
Faucet Installation
Faucet Install Steps (Part 1)
Steps 1-3: Apply putty, install nut, and tighten for faucet assembly.
Faucet Installation Continued
Connect Supply Tee and Hoses
Steps 4-7: Insert gasket, thread supply tee, and connect hoses to valves.
Pop-Up Drain Installation
Pop-Up Drain Assembly Steps
Steps 1-4: Disassemble stopper, apply putty, attach flange, and secure drain body.
Pop-Up Drain Installation Continued
Pop-Up Drain Rod and Stopper Installation
Steps 5-8: Remove rod nut, insert rod, tighten nut, connect clip, and insert stopper.
Faucet Installation Final Steps
Connect Hoses, Flush Lines, and Check Leaks
Steps 9-11: Connect supply hoses, flush lines, and reinstall aerator.
Service Parts Identification
Faucet Service Parts
Diagram and list of parts for the faucet spout, lift rod, aerator, and valve body.
Handle and Trim Parts
Parts breakdown for handles, setscrews, bonnets, escutcheons, and adapters.
Drain Assembly Parts
Components for the pop-up drain, including stopper, link, body, and tailpiece.
