Kohler ALEUTIAN 45758T-4 Installation Instructions

如何取出限流器
当供水水压低于0.15MPa(1.5bar)时，建
议取出限流器(46)以确保手持花洒的切
48
换功能正常使用。
先用六角扳手(47)旋松把手(49)内部的螺
钉(48)。依次取出把手，弹簧(50)，摩擦
球(51)，摩擦槽(52)，滑盖(53)，轴承
(54)，带垫片的装饰盖(55)，阀帽(56)，
阀芯(57)，移除限流器。将阀芯装回，
并锁紧阀帽，再依次将其它零件重新装
回阀座(58)中，用六角扳手锁紧螺钉。
安装结果检查
检查并确保所有衔接处都已拧紧，确保
手柄在关的位置。打开主水源和排水系
统，检查并修理有漏水的接口。
将花洒(43)拆下,用工具(60)将起泡器(59)
拆下。打开水龙头，让水流出约一分钟
以清除杂质。冲洗花洒的滤网垫片及起
泡器。关闭水龙头，重新装回起泡器和
花洒。
清洗说明
适用于所有加工处理过的表面：以中性肥皂水清洗镀层
的表面，再以干净的软布彻底擦干整个表面，许多清洁
剂，比如氨水、去污粉及洁厕灵等，会对电镀表面造成
伤害，切忌使用。
有磨损性的清洁用具或清洁剂也不可使用于科勒牌的水
龙头及其配件上。
1186493-2-C
How To Remove The Flow
Restrictor
47
If the water working pressure is below
49
0.15MPa(1.5bar), please remove the flow
restrictor (46) to ensure the spray's
50
functions work well.
51
Loosen the screw (48) of the handle
52
by hex wrench (47) . Take out the handle,
spring (50) , friction ball (51) , friction cup
53
(52) , sliding disk (53) , bearing
54
escutcheon (55) with washer, valve nut
(56) , valve (57) , remove the flow
55
restrictor. Reinstall the valve and tighten
56
the valve nut. Reinstall the other parts to
(58)
valve body in sequence, tighten the
57
screw by hex wrench.
46
58
INSTALLATION CHECKOUT
Ensure that all coupling nuts are tight.
Ensure that the lever handle is in the off
position. Turn on the main water supply
43
and drain, and check for leaks. Repair as
59
needed.
60
Remove the spray(43). Remove the
aerator(59) with the key(60). Turn on the
faucet. Run hot and cold water for about
one minute to remove any debris.
Remove any debris from the filter washer
and aerator. Shut off the faucet. Reinstall
the aerator and spray.
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as
ammonia, chlorine, toilet cleaner etc, which could
adversely affect the finish and are not recommended for
cleaning.
Do not use abrasive cleaners or solvents on Kohler
faucets and fittings.
INSTALLATION INSTRUCTIONS
安装说明书
(49)
安装之前
(54) ,
所有的资料是按最新出版的产品资料编写而成。科勒公
司保留任何时候不经通知即可改变产品特性、包装或产
品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，请把
这些资料交给用户阅读。
注意事项：
1. 一定要先彻底冲洗供水管以清除管道中的杂质。
2. 如果是安装新的脸盆，可将水龙头先装到脸盆上。
3. 推荐工作压力：2~5bar.
4. 花洒最高工作压力：0.5MPa(5bar)。水压超过0.5
MPa(5bar)须安装减压阀。花洒最高工作温度及环境温
度：60°C。请特别注意花洒须远离加热器，否则可能损
坏花洒及密封件，甚至对使用者造成伤害。
使用说明
面对水龙头，轻轻向使用者方向扳动把手，顺时针旋
转为热水，逆时针旋转为冷水。
安装尺寸
66
Ø31
Ø51
Ø28~Ø40
Ø67
4 1186493-2-C
45758T-4
梳洗脸盆龙头
BEFORE YOU BEGIN
All information is based on the latest product information
available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics,
packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They
contain important information.
NOTE:
1. Flush the water supply pipes thoroughly to remove
debris.
2. For new installations, assemble the faucet to lavatory
before installing.
3. Recommended working pressure: 2 to 5bar。
4. The highest working pressure for spray is 0.5MPa (5
bar). If it exceeds 0.5MPa(5 bar), a pressure reducer is
needed. The highest water and environment temperature
is 60°C. Please keep spray away from heater, or it may
become damaged and cause to injury to the user.
HANDLE OPERATION
In front of the user, pull the handle towards user gently,
turn clockwise for cold water, and counter-clockwise for
hot water.
ROUGH-IN DIMENSIONS
102~203
45
178
Ø60
Ø60
Ø32~Ø50
Ø32~Ø40
G1/2˝
希尔维
ALEUTIAN
Grooming Lavatory Faucet
25°
Ø60
Ø42
Ø31.75
1
