Rolls PA202 Specifications

Bridgeable amp with limiter circuit

Advertisement

WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER.
NO USER SERVICABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
LEFT
- +
The new PA202 is a compact class
D amplifier. It has 20 watts per
channel stereo @ 4 Ohms, and 40
watts when in bridge/mono
mode @ 8 Ohms. The class D low
heat design gives the PA202 the
ability to be mounted in very
tight applications. It will work
great in ceilings by projectors, or
anywhere small and heat free
amplification is required. The
PA202 is in an all metal chassis
and weighs 1 pound. Overall
dimension are 6" X 3.5" X 1.5".
Bottom mounts are provided for
permanent installations. The
PA202 has an included 24 VDC
IEC laptop type external power
supply.

SPECIFICATIONS

Line Input Impedance:
20 watts X 2 @ 4 Ohms.
Power Output:
40 watts bridge @ 8 Ohms.
Voltage Gain:
Maximum Supply Voltage:
THD:
EIN:
Effi ciency:
Input Sensitivity:
Bandwidth:
Size:
Weight:
PA202
RISQUE DE CHOC - NE PAS ENLEVER
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
INPUTS
BRIDGE INPUTS
RIGHT
- +
RIGHT
LEFT
PWR
ROLLS
ROLLS
MINI AMP
MINI AMP
20 + 20
20 + 20

INSTALLATION MINI AMPLIFIER

WITH LIMITER
ROLLS
47K Ohms
5968 SOUTH 350 WEST S.L.C.,UT 84107
32 dB
30 VDC
PHONE: 801-263-9053
.05% typical
3 mV
FAX: 801-236-9068
85%
28 mV
20Hz - 25 kHz
6" x 3.5" x 1.5"
1 lb.
DATA SHEET FOR PA202
BRIDGEABLE AMP WITH LIMITER CIRCUIT
OUTPUTS:
PA202
Mini Two Channel Amp
20 X 20 watts
CONFIGURATION
BIRDGE:
STEREO:
CHANNEL VOLUME
LEFT
RIGHT
BRIDGE
www.rolls.com
LEFT
RIGHT
BRIDGE
LIMITER
off
on
MADE IN USA
Included 24
VDC IEC laptop
type external
power supply
75889 02020
