YORKVILLE YCV40T Parts List

1
2
3
5
7
9
11
5
15
*NOTE: Replacement grilles are 'Special-Order' and are only available while the model is in production.
Parts-Serv-YCV40t-1v10.xls
4
6
8
10
12
13
16
ftp.yorkville.com
# Part# Description
Labeled Components
1 8260 TRAYNOR LOGO
2 TUBE10 10" 8R 30WPGM SPEAKER CELESTION
3 8461 TRIM CLIP (PLATED BLK ZINC)
4 YCV40 GRILL*
Z357*
5
3438 AC RECEPTACLE / FUSE HOLDER
6 8456 10.0" STRAP HANDLE, NICKEL COVERS
7
TFS-2B TRAYNOR DUAL FOOTSWCH 10' CORD
8
3537 ACC# 4EB3C1B LONG REVERB
9
8504 CORNER, 2 LEGS NOTCED LIP NICKEL PLATED
10
8770 1/4-20 X 1 5/16 TRUSS PH MS JS5
11
6397 JEWELED PILOT LAMP AMBER REG
12 8430 CHICKEN-BEAK KNOB
13
8638 PUSH SW BUTTON GREY
14 1/4" JCK PCB MT VERT STER RT SWT
3921
3698 SPST ROKR SW QUIK 180" AC PWR
15
1/4" ALL GOLD PC MNT JK SKT
3450 & 3450NUT
16
17 8543 RECESSED RUBBER BUMPER WITH WASHER
18 3426 AC LINE CORD - #3474(EURO)
3886 & 3890 36" PREFAB. CABLE (RED/BLACK)
19
7025A 7025B
OR
20 12AX7 DUAL TRIODE PREAMP TUBE
21 6L6B 6L6GB OUTPUT POWER TUBE
22
23
9
17
13
18
19
REVERB CABLE
20/21
TUBES
14
Speaker Enclosure
