Traynor DYNABASS 400 - MANUAL SERVICE Service Manual page 6

Block Diagram for DynaBass 400/T/H
D E S I G N E D A N D M A N U F A C T U R E D B Y Y O R K V I L L E S O U N D
Input
Preamp
Tube
Tube / Solid-State
Mono
Select Switch
1/4-inch
0 dB
Preamp
FET
Mono
1/4-inch
-6 dB
Tuner Out
Bal
Stereo
1/4-inch
Speaker Outputs
Amp
Footswitch
Front Panel
Distortion Enable
Distortion Switch
Circuit
Effects Enable
Circuit
Front Panel
Distortion Switch
Gain
Buffer
Off Full
Threshold
Adjust
Compressor
DynaBass 400 DynaBass 400T
15-inch 10-inch
Woofer Woofer
8-ohms 16-ohms
DynaBass 400T
10-inch
Woofer
16-ohms
Tw. Defeat
Tweeter
8-ohms
Tube
Gain
Drive
Mix
Distortion
Enable
Input
EQ EQ
Preamp
Solid
Low/Mid/Hi Hi Mid
State
Post-EQ / Pre-EQ
Line Out
Master
Mute
Scoop
Param.
Mid Freq.
Gain
Effects
Return
Effects Return
Enable
Limiter
Limiter
Buffer
Amp
AG
BLOCK-DIAG-DynaBass400-400T-400H-01-1v2
Effects Send
(balanaced)
Effects Return
Amp In
Bal D.I. Out
+
Speaker Output Jacks
1+
2-
1-
2+
