Traynor DYNABASS 400 - MANUAL SERVICE Service Manual page 5

YS # Description
3747 BLK SPACER LED CUSTOM 0.5
6400 YEL 3MM LED 1V9 6MA HIGHEFF
6405 RED 3MM LED 2V0 20MA BRT
6408 GRN 3MM LED 1V9 5MA FROSTED
6554 BLUE 3MM LED 3V9 20MA
6421 MR752 200V 6A0 DIODE
6425 BAV21 200V 0A25 DIODE T&R
6438 1N4007 1000V 1A0 DIODE T&R
6471 MBR160 60V 1A0 DIODE SCHTKY
6825 1N4148 75V 0A45 DIODE T&R
6934 MR854 400V 3A0 DIODE FASREC
6439 1N5225B 3V0 0W5 ZENER 5% T&R
6440 1N750ARL 4V7 0W5 ZENER 5% T&R
6463 1N5251BRL 22V0 0W5 ZENER 5% T&R
6822 1N4745A 16V0 1W0 ZENER 5% T&R
6871 MC7915CT TO220 N 15V0 REG V2
6872 MC7815CT TO220 P 15V0 REG V1
5101 BC550C TO92 NPN TRAN T&R TB
5102 BC560C TO92 PNP TRAN T&R TB
5103 MPSA06 TO92 NPN TRAN T&R TA
5107 2N5551 TO92 NPN TRAN T&R TA
5108 2N5401 TO92 PNP TRAN T&R TA
5119 2N5638 TO92 NCH JFET T&R TC
5122 J109 TO92 NCH JFET T&R TC
6810 MJF15030 T221D NPN TRAN TJ
6811 MJF15031 T221D PNP TRAN TJ
6953 IRF4905 TO220 PCH MFET
6966 IRL2910 NCH MFET 100V TN
6909 MJ21196 TO3 NPN TRAN TH
6910 MJ21195 TO3 PNP TRANSISTOR TH
6745 LM13600N IC XCONDUCTANCE AMP
6804 MC33079P IC QUAD OP AMP
6840 MC33078P IC DUAL OP AMP
6882 TL072CP IC FET DUAL OP AMP
6884 NE5532N IC DUAL OP AMP
6889 TL074CN IC QUAD O/A T.I ONLY
6936 4007 IC COMPLIMENTARY PAIRS
6999 THAT 2180LB IC VCA SIP
5190 MBS4992 TO92 8V5 DIAC T&R
6517 STM-BTB-600BRG TO220 ??A TRIAC 600V
6880 4N35 OPTO-COUPLER
5404 _27P 100V 10%CAP T&R BEAD NPO
5410 100P 100V 10%CAP T&R BEAD NPO
5417 330P 50V 10%CAP T&R BEAD NPO
5201 470P 100V 5%CAP T&R RAD CER.2"NPO
5420 680P 50V 10%CAP T&R BEAD NPO
5422 __1N 50V 10%CAP T&R BEAD NPO
5428 __3N3 50V 10%CAP T&R BEAD Y5R
5204 _10N 100V 10%CAP T&R RAD .2"FLM
5205 _15N 100V 10%CAP T&R RAD .2"FLM
5207 _18N 100V 5%CAP T&R RAD .2"FLM
5210 _22N 100V 10%CAP T&R RAD .2"FLM
5222 _33N 100V 10%CAP T&R RAD .2"FLM
5223 _39N 100V 10%CAP T&R RAD .2"FLM
5224 _47N 100V 10%CAP T&R RAD .2"FLM
5301 _12N 50V 10%CAP T&R BEAD X7R
5302 _15N 50V 10%CAP T&R BEAD X7R
5304 _22N 50V 10%CAP T&R BEAD X7R
5306 _33N 50V 10%CAP T&R BEAD X7R
5308 _47N 50V 10%CAP T&R BEAD X7R
5432 __4N7 50V 10%CAP T&R BEAD Y5R
6435 _22N 275V 20%CAP BLK 'X2' 15MM AC
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC
5212 100N 63V 5%CAP T&R RAD .2"FLM
5228 100N 100V 5%CAP T&R RAD .2"FLM
5231 220N 63V 10%CAP T&R RAD .2"FLM
5233 330N 63V 5%CAP T&R RAD .2"FLM
5242 100N 250V 20%CAP BLK 'X2' 15MM AC
5312 _82N 50V 10%CAP T&R BEAD X7R
5314 100N 50V 10%CAP T&R BEAD X7R
5318 220N 50V 10%CAP T&R BEAD X7R
5322 470N 50V 10%CAP T&R BEAD Z5U
5600 220N 100VDC 10%CAP BLKRAD POLYE FLM
5254 __1U 63V 20%CAP T&R 4X7MM .2"EL
5255 __1U 63V 20%CAP T&R RAD .2"EL
5256 __1U 63V 5%CAP T&R RAD .2"FLM
5257 __2U2 63V 20%CAP T&R RAD .2"EL
5258 __4U7 63V 20%CAP T&R 8X7MM .2"EL
5282 _10U 16V 20%CAP T&R 5X7MM .2"NP
5629 _10U 160V 20%CAP BLK 10X13MM EL
DynaBass 400h Parts List 11/10/2009
Qty. YS # Description
5 5631 _22U 50V 20%CAP T&R 6X7MM .2"EL
1 5852 _10U 35V 20%CAP T&R 05X05MM EL
1 5621 470U 63V 20%CAP BLK 12X25MM EL
1 5859 4700U 50V 20%CAP BLK 25X36MM ELS
1 5890 5600U 100V 20%CAP RAD 35X50MM ELS
8 4467 _10K B LIN 12MM KNRLSHFT P36
6 4472 _10K B LIN 9MM P35
4 4470 _20K 5C R/A 9MM P35
2 4471 _50K B LIN 9MM P35
22 4469 100K B LIN 9MM P35
4 4474 100K B LIN 12MM KNRLSHFT P36
1 4475 100K 5C R/A 12MM KNRL ST P37
1 4520 _10K TRIM POT
1 714 1.5 MIL X 36" CLEAR POLY SHEETING
8 3819 ___5UH COIL 18AWG R000 AIR CORE
1 8521 RUBBER BUMPER WITH WASHER VERYSMALL
1 3485 CLIP 250X032 18-22AWG RIGHT ANGL
5 3489 CLIP 250X032 18-22AWG DISCO/INSL
8 3490 CLIP 250X032 14-16AWG DISCO/INSL
2 3601 RING TERMINAL 16AWG WIRE & #8 SCREW
4 3795 #8 GROUND LUG ZIERICK 505-169
1 3450 1/4" JCK PCB MT ALL-GOLD SKT
1 3449 NEUTRIK JACK NUT RED
1 3498 1/4" JCK PCB MT HORZ
1 3918 1/4" JCK PCB MT HORZ SLIM W/SCREW
1 6956 SPKON 4C PCB MT HORZ GRY #4
1 3417 6-32 SCREW TERMINAL PC MNT SNAP-IN
1 3923 XLR MALE PCB MT HORZ MTHOLE-V SNAP
2 3451 EYELET SMALL 0.089 OD PLATED
2 3414 INTERNATIONAL PC MOUNT FUSEHOLDER
1 2427 _5.0 AMP SLO-BLO .25X1.25 FUSE
2 8696 AP-SERIES HANDLE- BARE 6061-T6 ALUM
1 6583 BRDLK TO220 H/S W/TAB B.O.
8 3501 B52200F006 COMP WASH #4 SMALL
1 8609 VINYL CAP 0.250" X 1/2" BLK.
3 8889 RUBBER GROMMET #2183-034-BLK
1 3645 AC SOCKET RECEPTACLE WITH 0.250 TAB
1 3803 NYLON SECUR-A-TACH MINI PLASTIC TIE
1 3810 4" NYLON CABLE TIE
1 3558 TERM HOUSING 4 CIR .156/RAMP
1 3672 6 CIR CABLE HOLDER .098
1 3674 9 CIR CABLE HOLDER .098
5 3676 8 CIR CABLE HOLDER .098
1 4000 10 CIR CABLE HOLDER .098 PRLX
1 5989 4 CIR CABLE HOLDER .098
3 4002 10 CIR WAFER W/LCK VT 0.1"
2 3538 24 PIN BREAKAWAY LOCK .156
1 3549 TRIFURCON TERM .156
3 8402 TRAYNOR KNOB, CHROME W/STOPPER
1 8633 KNOB ROUND PUSHBUTTON 1/4" BLACK
1 8636 BUTTON 230X465 RND FLAT BLK (3425)
4 3426 8' 3/16 SJT AC LINE CORD REMOVB-CSA
1 8701 4-40 KEPS NUT ZINC
1 9984 6-32 NYLON MALE-FEMALE STANDOFF
1 8760 6-32 KEPS NUT TIN PLATED
1 8800 6-32 KEPS NUT ZINC
2 8898 1/4-20 CAGE NUT C79 98142027
2 8797 5/16-18 KEPS NUT JS500
1 3846 TO220 THERMO PAD LARGE HOLE 56359B
1 3916 TO3 SIL-PAD REPLACES MICA
3 4597 22AWG STRAN TC WIR JMP
1 4599 22AWG SOLID SC WIR T&R JMP
1 5299 24AWG SOLID SC WIR RAD JMP
21 4719 5.0W 0R18 5% BLK RES
7 4677 1/2W 1R 5% T&R RES
4 4748 2.0W 3R9 5% T&R
2 2009 1/4W 10R 2%FLAME PROOF T&R RES
1 2037 1/4W 10R FUSIBLE T&R RES
1 4875 1/4W 10R 5% T&R RES
2 4612 1/2W 18R 5% T&R RES
1 4618 1/2W 22R 5% T&R RES
1 4882 1/4W 27R 5% T&R RES
2 2015 1/4W 33R2 1%FLAME PROOF T&R RES
1 4811 1/4W 68R 5% T&R RES
2 4692 5.0W 100R 5% BLK RES
6 4852 1/4W 100R 5% T&R RES
8 4819 1/4W 180R 5% T&R RES
4 4909 1/4W 200R 5% T&R RES
6 4857 1/4W 220R 5% T&R RES
1 4770 1/4W 249R 1% T&R RES
Qty. YS # Description
5 2047 1/4W 270R FUSIBLE T&R RES
1 4667 1/2W 270R 5% T&R RES
2 5033 3.0W 330R 5% T&R
2 4736 5.0W 390R 5% BLK RES
2 4713 1.0W 470R 5% T&R RES
1 4821 1/4W 470R 5% T&R RES
2 4980 1/4W 470R 5%MINI T&R RES
2 2049 1/4W 680R FUSIBLE T&R RES
4 4743 1/4W 681R0 0.1% *** T&R RES
2 4873 1/4W 680R 5% T&R RES
1 4823 1/4W 1K 5% T&R RES
1 4854 1/4W 1K2 5% T&R RES
1 4824 1/4W 1K5 5% T&R RES
3 4825 1/4W 1K8 5% T&R RES
1 4808 1/4W 2K 5% T&R RES
4 4847 1/4W 2K2 5% T&R RES
3 4714 1/4W 2K21 1% T&R RES
11 4883 1/4W 2K49 1% T&R RES
8 4764 1/4W 2K740 0.1% *** T&R RES
3 4805 1/4W 2K87 1% T&R RES
1 4804 1/4W 3K 5% T&R RES
6 4826 1/4W 3K3 5% T&R RES
2 4827 1/4W 4K7 5% T&R RES
1 4639 1/4W 4K99 1% T&R RES
2 6128 1/4W 4K99 1%MINI MF T&R RES
1 4893 1/4W 5K1 5% T&R RES
3 4862 1/4W 5K6 5% T&R RES
1 4628 1/2W 6K8 5% T&R RES
20 4828 1/4W 6K8 5% T&R RES
2 4863 1/4W 8K2 5% T&R RES
1 4800 1/4W 10K0 1% T&R RES
2 4829 1/4W 10K 5% T&R RES
2 4983 1/4W 10K 5%MINI T&R RES
5 4775 1/4W 14K0 1% T&R RES
2 4830 1/4W 15K 5% T&R RES
1 4771 1/4W 17K8 1% T&R RES
1 4885 1/4W 20K 5% T&R RES
1 6123 1/4W 20K0 1%MINI MF T&R RES
11 4832 1/4W 22K 5% T&R RES
1 4902 1/4W 24K 5% T&R RES
2 4633 1/2W 27K 5% T&R RES
2 4890 1/4W 30K 5% T&R RES
6 4917 1/4W 31K6 1% T&R RES
1 4840 1/4W 33K 5% T&R RES
8 4853 1/4W 39K 5% T&R RES
1 4834 1/4W 47K 5% T&R RES
0.167 4803 1/4W 49K9 1% T&R RES
3 4895 1/4W 51K 5% T&R RES
10 4763 1/4W 82K50 0.1% *** T&R RES
5 4838 1/4W 100K 5% T&R RES
2 4776 1/4W 113K 1% T&R RES
1 4839 1/4W 150K 5% T&R RES
5 4886 1/4W 200K 5% T&R RES
3 4842 1/4W 330K 5% T&R RES
8 4843 1/4W 470K 5% T&R RES
15 4844 1/4W 1M 5% T&R RES
4 4845 1/4W 2M2 5% T&R RES
1 3666 _2.0" 4C-26AWG RIBBON CABLE 0.1"
2 4040 5.0" 6C-26AWG RIBBON CABLE 0.1IN
4 3640 _3" 8C-26AWG RIB 1/4" S&R 0.1"
7 4008 16" 9C-26AWG RIBBON .098"
170 4003 _8.5"10C-26AWG RIB 1 W/LCK HDR 098"
2 8842 #4 X 5/16 PAN QUAD TYPE A JS500 BLK
4 8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK
2 8871 4-40 X 5/8 PAN PH MS JS500
1 8799 #6 X 1/4 PAN PH TYPE B JS500
1 8832 6-32 X 1/4 PAN PH TAPTITE JS500
2 8801 6-32 X 3/8 PAN PH TAPTITE JS500
1 8829 6-32 X 3/8 FLAT PH TAPTITE BO#C HEA
2 8747 6-32 X 1/2 HEX ND MS ZINC
2 8761 6-32 X 1/2 PAN PHIL MS ZINC CLEAR
1 8825 6-32 X 1/2 FLAT PHIL TRILOB NICKEL
2 8624 10-32 X 1/2 HEX HD MS JS500 BLK
1 8736 5/16-18X2-3/4 GRD 5 HEX BOLT JS500
1 8663 11/64 NYLON SPACER (MICRO PLASTIC)
6 3865 1/2 PLASTIC HEX SPACER #6
2 8657 6-32 X 3/8" HEX SPACER ALUMINUM
1 8652 SHOULDER WASHER .483" X .125" BLACK
2 8667 SHOULDER WASHER SWS-229 LENGTH 1/8
2 8818 3/4 OD X 3/8 ID X .080 THICK WASHER
Qty. YS # Description
3 3425 DPDT PUSH SW PCMT BREAK B4 MAKE
10 3522 DPDT MINI PC VERT SNP ALT
2 3587 DPDT ROKR SW QUIK 250"AC/PWR ON-OFF
4 3682 250 MALE PCB TAB REEL
17 3399 THERMO/BRKR:N/CLOSED OPEN@96C
2 3732 9 PIN PC MOUNT TUBE SOCKET BE
2 12AX7BLK 12AX7 DUAL TRIODE PREAMP TUBE
1 CH1207 XS400/H 120VAC 60HZ T'RD
