3
6
8
*NOTE: Replacement grilles are 'Special-Order'
and are only available while the model is in production.
SERVICE-QuickGuide-DB200-00-1v2.xls
1
2
4
5
7
10
9
11
15
13
14
ftp.yorkville.com
#
Part#
Description
Labeled Components
1
7417
_8R 30W TWEETER PIEZO TLC 1
2
7347
15" 4R 200WPGM SPEAKER BASS
3
Z891*
DB200 GRILLE
4
TRAYNOR LOGO PLASTIC NICKEL PLA
8268
5
8504
CORNER, 2 LEGS NOTCED LIP NICKE
6
8599
2" CASTOR AND SOCKET
7
3428 /
8' 3/18 SJT AC LINE CORD REMOVA
8
8600
HANDLE,RECESSED,PULL,BLACK META
9
8734
#10 X 1/2 PAN PH TYP A BRITE NI
10
3645
AC SOCKET RECEPTACLE WITH 0.250
11
8522
RUBBER BUMPER WITH WASHER -SMAL
12
8770/8817
1/4-20 X 1 5/16 TRUSS PH MS JS5 / WASHER
13
3450
1/4 ALL GOLD PC MNT JK SKT
14
5994
YEL
3MM LED 1V9 20MA.12SPCR T&R
15
8636
BUTTON KNOB FLAT BLACK
16
8401
TRAYNOR
3923
XLR MALE PCB MT HORZ MTHOLE-V SNAP
17
6405
RED 3MM LED 1V7 5MA BRT
18
3702
DPST ROKR SW 187" AC PWR
19
8533
RUBBER BUMPER TAPERED 1.375 X 1
20
21
8906
#14X2 ALLEN FLAT HD WOOD SCRW J
22
9925
TINNERMAN CLIP 1/8" STUD SIZE R
11
6
12
16
15
17
KNOB, NICKEL PLATED
S
20
21
22
19
18
Combo Amplifier
