Traynor DG65D - MANUAL SERVICE Service Manual page 3

YS # Description
5906 RED 3MM LED 1V9 20MA .4SPCER T&R
5907 YEL 3MM LED 1V9 20MA .4SPCER T&R
5908 GRN 3MM LED 1V9 20MA .4SPCER T&R
6825 1N4148 75V 0A45 DIODE
6827 1N5402 200V 3A0 DIODE
6934 MR854 400V 3A0 DIODE FASREC
6733 BAT85 30V 0A2 DIODE SCHTKYT&R
6439 1N5225B 3V0 0W5 ZENER 5% T&R
6440 1N750ARL 4V7 0W5 ZENER 5% T&R
6437 1N5237B 8V2 0W5 ZENER 5% T&R
6461 1N5240BRL 10V0 0W5 ZENER 5% T&R
6450 1N5242B 12V0 0W5 ZENER 5% T&R
6871 MC7915CT TO220 N 15V0 REG
6872 MC7815CT TO220 P 15V0 REG
5101 BC550C TO92 NPN TRANSISTOR T&R
5102 BC560C TO92 PNP TRANSISTOR T&R TB
5103 MPSA06 TO92 NPN TRANSISTOR T&R TA
5104 MPSA56 TO92 PNP TRANSISTOR T&R
5107 2N5551 TO92 NPN TRNSISTR DARL T&RTA
5108 2N5401 T092 PNP TRNSISTR DARL T&RTA
5106 MPSA63 TO92 PNP TRNSISTR DARL T&RTA
5119 2N5638 TO92 NCH JFET T&R TC
6911 BDX54C TO220 PNP TRAN DARL TE
6912 BDX53C TO220 NPN TRAN DARL TE
6761 IRF9Z24N TO220 PCH MFET
6762 IRFZ34N TO220 NCH MFET
6882 TL072CP IC FET DUAL OP AMP
6884 NE5532N IC DUAL OP AMP
6745 LM13600N IC XCONDUCTANCE AMP
5404 _27P 100V 10%CAP T&R BEAD
5408 _47P 100V 10%CAP T&R BEAD
5199 100P 100V 2%CAP T&R RAD CER.2"NPO
5410 100P 100V 10%CAP T&R BEAD
5277 220P 200V 5%CAP T&R RAD CER.2"NPO
5412 220P 100V 10%CAP T&R BEAD
5417 330P 50V 10%CAP T&R BEAD
5416 470P 50V 10%CAP T&R BEAD
5420 680P 50V 10%CAP T&R BEAD
5815 680P 200V 5%CAP T&R RAD CER.2"NPO
5206 __1N 400V 5%CAP T&R RAD
5424 __1N5 50V 10%CAP T&R BEAD
5275 __3N3 100V 5%CAP T&R RAD
5209 __4N7 250V 5%CAP T&R RAD
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC
5210 _22N 100V 10%CAP T&R RAD
6435 _22N 275V 20%CAP BLK 'X2' 15MM AC
5222 _33N 100V 10%CAP T&R RAD
5224 _47N 100V 10%CAP T&R RAD
5226 _68N 100V 5%CAP T&R RAD
5227 _82N 100V 5%CAP T&R RAD
5212 100N 63V 5%CAP T&R RAD
5229 150N 63V 10%CAP T&R RAD
5231 220N 63V 10%CAP T&R RAD
5233 330N 63V 5%CAP T&R RAD
5234 470N 63V 10%CAP T&R RAD
5266 680N 250V 20%CAP BLK 'X2' 30MM AC
5254 __1U 63V 20%CAP T&R 4X7MM .2"EL
5256 __1U 63V 5%CAP T&R RAD
5258 __4U7 63V 20%CAP T&R 8X7MM .2"EL
5282 _10U 16V 20%CAP T&R 5X7MM .2"NP
5631 _22U 50V 20%CAP T&R 6X7MM .2"EL
5961 _33U 16V 20%CAP T&R RAD
5616 3300U 50V 20%CAP BLK 18X35MM EL
TFS-2B TRAYNOR DUAL FOOTSWCH 10' CORD-BULK
4423 _20K 15AAUDIO 9MM P32
4424 100K 1B LIN 9MM P32
4425 500K 15AAUDIO 9MM P32
4520 _10K TRIM POT
713 25 X 20 X 50 2 MIL PLASTIC BAG
3976 SNAP ON 0.843" INSULATING BUSHING
8522 RUBBER BUMPER WITH WASHER -SMALL-
8563 CORNER, 2 LEGS NOTCED BLK PLASTIC
3467 CLIP 205X032 14-16AWG DISC/INSUL
3478 CLIP 205/187X032 18-22AWG DISCO/INS
3489 CLIP 250X032 18-22AWG DISCO/INSL
3490 CLIP 250X032 14-16AWG DISCO/INSL
3491 CLIP 205/187X020 18-22AWG DISCO/INS
3682 250 MALE PCB TAB REEL
3498 1/4" JCK PCB MT HORZ
3528 1/4" JCK PCB MT HORZ GOLD TR_
DG65R Parts List 11/2/2005
Qty. YS # Description
1 3921 1/4" JCK PCB MT VERT STER RT SWT
1 3886 36" RCA DUAL RED-WHITE PREFAB CABLE
2 3914 RCA SNGL PCB MT HORZ
T&R 23 3451 EYELET SMALL 0.089 OD PLATED
8 2403 T2A
2 8451 10" STRAP HANDLE,BLACK METAL ENDCAP
3 8604 10-32 T NUT
5 3979 6POS XSISTOR TO220SPRING
6 8889 RUBBER GROMMET #2183-034-BLK
4 3438 IEC PWR SOC W/.205TAB &FUSE 10A250V
1 3552 NYLON SPRING CLAMP
4 3810 4" NYLON CABLE TIE
V2 1 8430 YCV40 CHICKEN-BEAK KNOB
V1 1 8431 YCS100 BUDGIE-BEAK KNOB
2 8632 ROUND PUSH BUTTON 1/4" GREY
10 8649 BUTTON KNOB FLAT BLACK
3 3428 8' 3/18 SJT AC LINE CORD REMOVABLE
3 8264 YBA200/YCV LOGO EMBOSSED ALUMINUM
1 8910 YORKVILLE PRODUCT MANUAL
1 8900 YORKVILLE WARRANTY CARD 2-YR UNLTD.
1 3676 8 CIR CABLE HOLDER .098
7 8800 6-32 KEPS NUT ZINC
1 8602 1/4-20 T NUT
1 8788 1/4-20 KEPS NUT ZINC
1 8898 1/4-20 CAGE NUT C79 98142027
1 4017 SARCON THERMAL GASKET 3.60"X0.75"
1 4597 22AWG STRAN TC WIR
8 4599 22AWG SOLID SC WIR
2 2005 1.0W 0R47 5%FLAME PROOF T&R RES
NPO 1 4748 2.0W 3R9 5%
NPO 1 4816 1/4W 33R
1 2041 1/4W 39R0 FUSIBLE
NPO 1 4817 1/4W 47R
2 4652 1/2W 100R
NPO 1 4852 1/4W 100R
NPO 1 4977 1/4W 220R
NPO 2 4855 1/4W 330R
NPO 1 4821 1/4W 470R
1 2028 1/8W 475R
.2"FLM 3 4891 1/4W 620R
Y5P 2 4873 1/4W 680R
.2"FLM 3 2050 1/4W 1K
.2"FLM 2 4823 1/4W 1K
1 4854 1/4W 1K2 5%
.2"FLM 4 4824 1/4W 1K5 5%
1 4825 1/4W 1K8 5%
.2"FLM 3 4847 1/4W 2K2 5%
.2"FLM 5 4864 1/4W 2K7 5%
.2"FLM 1 4826 1/4W 3K3 5%
.2"FLM 1 4982 1/4W 4K7 5%MINI
.2"FLM 16 4828 1/4W 6K8 5%
.2"FLM 6 4863 1/4W 8K2 5%
.2"FLM 4 4983 1/4W 10K
.2"FLM 1 4856 1/4W 12K
.2"FLM 3 4830 1/4W 15K
1 4831 1/4W 18K
5 4832 1/4W 22K
.2"FLM 1 4840 1/4W 33K
1 4853 1/4W 39K
1 4834 1/4W 47K
2 4848 1/4W 62K
.2"NP 10 4836 1/4W 68K
4 6120 1/4W 100K
1 4851 1/4W 120K
6 4839 1/4W 150K
3 4849 1/4W 180K
4 4841 1/4W 220K
1 4843 1/4W 470K
1 4880 1/4W 680K
1 4844 1/4W 1M
4 4845 1/4W 2M2 5%
8 4751 1/4W 22M
4 3665 _2" 8C-26AWG RIBBON CABLE
1 3537 ACC# 4EB3C1B LONG REVERB
1 8832 6-32 X 1/4 PAN PH TAPTITE JS500
2 8801 6-32 X 3/8 PAN PH TAPTITE JS500
2 8829 6-32 X 3/8 FLAT PH TAPTITE BO#4 HEA
10 8761 6-32 X 1/2 PAN PHIL MS ZINC CLEAR
3 8755 #6 X 5/8 PAN PH TYPE A JS500 BLACK
2 8828 6-32 X 3/4 PAN PH TAPTITE JS500
Qty.
5X20MM FUSE
JMP
T&R JMP
T&R
5% T&R RES
T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5%MINI T&R RES
5% T&R RES
5% T&R RES
1%FLAME PROOF T&R RES
5% T&R RES
5% T&R RES
FUSIBLE T&R RES
5% T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
5%MINI T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5%MINI T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
T&R RES
5% T&R RES
0.1"
YS # Description
3 8785 #8 X 3/4 OVAL PH TYPE A BLACK OXIDE
1 8722 #8 X 1" PAN QUAD TYPE AB B/O
2 8756 #10 X 3/4 PAN PH TYPE A BLACK OXIDE
14 8843 10-32 X 1 1/8 FLAT PH MS JS500
1 8786 10-32 X 1 1/4 PAN QD MS JS500 BLACK
1 8936 1/4-20 X 3/4 PAN PH MS BLACK OXIDE
6 8770 1/4-20 X 1 5/16 TRUSS PH MS JS500
1 8907 1/4-20 X 2 1/4 HEX BOLT GR 2 FUL TD
4 8905 YORKVILLE PRODUCT SCHEMATIC
1 3744 SNAP IN .375 SPACER RICHCO
3 3833 8 X 3/8 (250 OD,.171 ID)NY SPACER
7 3741 .5 SPACER ID-.171 OD-.25 #912-500
5 3865 1/2 PLASTIC HEX SPACER #6
8 8657 6-32 X 3/8" HEX SPACER ALUMINUM
3 7452 12" 8R 75WPG SPEAKER
1 8482 3/8 1D FLAT WASHER
1 8488 3/8 INT TOOTH LOCKWASHE ZINC
1 8818 3/4 OD X 3/8 ID X .080 THICK WASHER
1 8820 #8 FLAT WASHER JS500
1 8817 #10 FLAT WASHER FOR 3/16" BOLT
4 3436 DPDT PUSH SW PCMT H BREAK B4 MAKE
8 3522 DPDT MINI PC VERT SNP ALT
2 3698 SPST ROKR SW QUIK 180" AC PWR BL/BL
1 CH1340 DG65 120V 60HZ T'RD
2
1
3
67
8
1
2
2
2
2
4
7
1
2
8
2
3
1
9
3
2
1
16
1
4
16
2
1
29
1
9
2
13
1
1
3
1
3
10
1
2
1
6
4
1
3
1
4
2
1
12
4
13
4
2
6
Qty.
18
4
3
2
4
2
2
1
1
4
3
4
22
1
1
3
3
2
4
2
1
3
1
1
