Summarization of Contents
Features
High Efficient Cooling
"π"type air flux design makes high efficient cooling. Air flux from right front and side to left front and side.
Protection Circuits
Includes over heating, speaker, short, and over current protection systems to safeguard the amplifier.
Front Panel Controls
LED Indicators
Explains CLIP/LIM, SIGNAL, POWER, and TEMP LED indicators and their functions.
Channel Volume Controls
Adjusts the output level for each channel independently.
Power Switch Operation
Details how to safely turn the unit's power on and off, including recommended waiting times.
Rear Panel Controls and Connections
AC Power Connection
Instructions for connecting the power plug and replacing the fuse.
Signal Input Specifications
Details balanced input level, impedance, and connection types for channels 1 and 2.
Limiter Switches
Detects and reduces overdrive by flattening waveform peaks to minimize distortion.
Output Terminals and Speaker Cabling
Information on connecting speaker cables, including warnings and best practices for cabling.
Amplifier Operation Modes
Explains STEREO and BRIDGE MONO operation modes and their respective speaker impedance requirements.
System Connections
Stereo (2-Channel) Mode Connection
Steps to connect the amplifier in stereo mode, including setting the stereo-mono switch.
Bridge Mono Mode Connection
Instructions for connecting the amplifier in bridged mono mode for higher power output.
