- Page 1 Operator's Manual Beauvais AGCO S.A.S. - 41 avenue Blaise Pascal - 60000 Beauvais - France - RC B562 104 539 February 2016 ACT001586A © AGCO 2016 Original Operator's Manual English...
- Page 2 Find manuals at https://best-manuals.com...
- Page 3 Foreword GUID-2AC6B9E1-4D9D-4D81-BE03-6CDCD396726A We would like to welcome you to the ever-growing number of people who own a Massey Ferguson tractor; people who appreciate quality. We are proud of every tractor that leaves our factories, each being technically advanced and of a high quality.
- Page 4 ACT001586A Find manuals at https://best-manuals.com...
-
Page 5: Table Of Contents
Table of contents 1 Tractor identification ............11 1.1 Locating serial numbers . - Page 6 Table of contents 2.10.4 Passenger seat ..........50 2.11 Warranty .
- Page 7 Table of contents 3.7.3.1 Control locations ......... . 104 3.7.3.2 Operation .
- Page 8 Table of contents 3.11 Wheels and tires ..........156 3.11.1 Wheel studs .
- Page 9 5.1.1 Model MF 4708 ........
- Page 10 ............273 5.4.1 Forward speed at 2200 rpm for models: MF 4708, MF 4709, MF 4710 with 12x12 gearbox and 16.9x34 tires.
- Page 11 Table of contents 1. Tractor identification 1.1 Locating serial numbers ..........13 1.1.1 Locating serial numbers .
- Page 12 Table of contents ACT001586A...
-
Page 13: Tractor Identification
1. Tractor identification 1.1 Locating serial numbers GUID-4DAD119B-821E-44EA-859B-1DFDB76B1CE3 1.1.1 Locating serial numbers IMPORTANT: Tell your dealer or agent the tractor serial number. GUID-94C602DB-DF23-4BC6-82ED-CDBFB2BC46F2-high.jpg Fig. 1 ROPS serial number Chassis serial number Name plate Front axle serial number Engine serial number ACT001586A... -
Page 14: Tractor Identification
1. Tractor identification 1.2 Tractor identification GUID-57220CEF-4B8D-4FEC-833A-AF9A48C690AB 1.2.1 Your tractor identification details Model: Serial number: Engine serial number: Owner's name: Street: Postcode: Town: County: Country: Dealer code: Tractor received from (tick one of the following): Factory Other dealer (transfer) Notes: ACT001586A... -
Page 15: Safety Instructions And Safety Points - Warranty
Table of contents 2. Safety instructions and safety points - Warranty 2.1 Introduction ............. 17 2.1.1 Introduction - Safety instructions . - Page 16 Table of contents 2.11.3 Warranty procedure ........... 51 2.11.4 Procedure to follow if changing region .
-
Page 17: Introduction
Ferguson dealers supply these genuine parts. Contact your dealer if you require any advice on their installation and use. Massey Ferguson cannot be held responsible if the owner uses parts other than the genuine parts sold by Massey Ferguson dealers. Similarly, only accessories specifically adapted to the tractor should be used. - Page 18 2. Safety instructions and safety points - Warranty Always consult a Massey Ferguson dealer: • For any advice regarding the conditions of use, servicing and repair for the tractor • If there is any doubt regarding the safety instructions to be observed when using the tractor •...
-
Page 19: Safety - Symbols And Terms
2. Safety instructions and safety points - Warranty 2.2 Safety — Symbols and terms GUID-4C8E61C0-0783-4677-8F19-34694CB23997 2.2.1 Safety — Symbols and terms Signal This safety alert symbol means CAUTION! BE ALERT! YOUR SAFETY DEPENDS ON IT! The safety alert symbol identifies important safety notices on machines, safety signs, in instruction books or elsewhere. -
Page 20: Safety Decals And Instructions
2. Safety instructions and safety points - Warranty 2.3 Safety decals and instructions GUID-C745940D-B900-4385-8FC2-3C5F997BD585 2.3.1 Checking and replacing the safety decals and instructions WARNING: Never remove or obscure the safety decals and instructions. Replace any safety decals and instructions that are illegible or missing. Replacement decals are available from the dealer in the event of loss or damage. -
Page 21: Presentation And Location Of The Safety Decals And Instructions
2. Safety instructions and safety points - Warranty GUID-A18CBB1F-8452-4146-99D0-C4944D842F0F 2.3.2 Presentation and location of the safety decals and instructions Fig. 1 GUID-8B24E9A5-6E3E-402D-8DC1-86EEFCC5964A-high.jpg ACT001586A... - Page 22 2. Safety instructions and safety points - Warranty • 4392020M1 ((A)) • WARNING: Crushing hazard between tractor and implement. Stand outside of tractor tire when using external controls for 3-point linkage. Do not stand between tractor and implement. • 4296960M1 ((B)) •...
- Page 23 2. Safety instructions and safety points - Warranty • 4296946M1 ((E)) • WARNING: Runaway machine and runover hazards Shut off engine and remove key before performing maintenance or repair work. • 4296962M1 ((F)) • DANGER: Falling and crushing hazard. Do not sit on the tractor fenders. •...
- Page 24 2. Safety instructions and safety points - Warranty • 4375856M1 ((I)) • DANGER: Entanglement hazard PTO shaft. Stand clear of rotating shafts. Keep all driveline, tractor and equipment guards in place during operation. • 4297148M1 ((J)) • WARNING: Falling hazard Do not step on PTO shield.
- Page 25 2. Safety instructions and safety points - Warranty • 4296944M1 ((N)) • WARNING: Entanglement hazard in belt drives Keep hands clear of rotating parts and belts while engine is running. Shut off engine and remove key before performing maintenance or repair work. Refer to the instructions in the technical manual when removing and reconditioning.
- Page 26 2. Safety instructions and safety points - Warranty • 4296967M1 ((P)) • WARNING: Burn hazard – hot surfaces. Keep away from hot engine components when engine has been running. Wait for system to cool before performing maintenance or repair work. •...
-
Page 27: General Safety Instructions
2. Safety instructions and safety points - Warranty 2.4 General safety instructions GUID-B2119D22-526A-439D-B20B-2019D150815C 2.4.1 Awareness of the safety instructions and symbols The operator must observe the safety instructions in order to ensure his/her own safety and the safety of other persons. Before using the tractor, familiarize yourself with: •... -
Page 28: Filling The Fuel Tank
2. Safety instructions and safety points - Warranty GUID-3AD514D9-0C9A-4D89-9D6B-F05188AC2270 2.4.3 Filling the fuel tank WARNING: • Always switch off the engine before filling up. • Do not smoke while refueling the tractor. Keep away from naked flames. • Proceed with care to prevent any splashes. -
Page 29: Mandatory Procedure Before Dismounting The Tractor
2. Safety instructions and safety points - Warranty • Never attempt to mount or dismount a moving tractor. • Never jump off a tractor when it is running except in an emergency. GUID-22785A2A-23E0-4154-8367-12A1175C69E2 2.4.5 Mandatory procedure before dismounting the tractor Before getting out of the operator's seat, observe this procedure: Procedure Immobilize the tractor by applying the parking brake. -
Page 30: Special Instructions
2. Safety instructions and safety points - Warranty 2.5 Special instructions GUID-FEE32571-9BA1-4DCC-B62A-845763F08475 2.5.1 Specific recommendations for agricultural and forestry tractors Hot surfaces Be careful of surfaces which may be hot, in particular engine and hydraulics components, during operation and services. FOPS (Falling Object Protection Structure) •... - Page 31 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
