Summarization of Contents
Before You Begin
Safety Warnings and Precautions
Understand caution icons, avoid using racks as shelves, and practice safe lifting.
Tools for Rack Installation
Identify required tools, specifically a flat-blade screwdriver for rack installation.
Inventory
Completing External Parts Inventory
Locate and verify the kitting report and all ordered parts received with the system.
Required Parts for Installation
List of parts needed for server setup: rack-mounting hardware kit, slide rail assemblies, and cable-management arm.
Prepare the Rack for Installation
Rack Preparation Steps
Ensure rack unpacking is complete, place rack, level it using feet, and install the stabilizer bracket.
Install Slide Rail Assemblies
Positioning and Initial Rail Installation
Determine server location in the rack, remove filler panels, and start installing slide rails.
Attaching Rails to Rack and Securing
Complete rail attachment to rack, ensure levelness, and optionally secure with screws.
Install Server onto Slide Rail Assembly
Server Placement and Alignment
Extend slide rails, lift server safely, and align chassis slots with rail tabs for proper seating.
Securing the Server in the Rack
Engage safety latches, push server into rack, and tighten retaining screws to secure the installation.
Install Cable-Management Arm
Cable Arm Attachment Procedures
Locate arm and pins, attach to rack frame and sliding rail assembly, considering space limitations.
Cable the HMC and the Server
Initial Cabling and Connections
Connect optional adapter cables, route power cords, and connect mouse, keyboard, and monitor.
Network and Power Connections
Connect Ethernet, telephone (if applicable), and power cords; avoid connecting to power source prematurely.
HMC Configuration and Server Power-On
Configure HMC, connect server to power, wait for display, and press the Power On button.
Cable the Server and Access IVM
Serial and Ethernet Connections
Connect serial cable to server and PC, and Ethernet cable from PC to server's HMC port.
IP Configuration and Login
Configure PC's Ethernet interface, access server via web browser, and log in with default credentials.
System Firmware Configuration
Change default password and set system server firmware to standby mode via Power/Restart Control.
Advanced System Setup and IVM
Virtualization Engine Activation
Enter activation code for Virtualization Engine technologies in the system's firmware.
Partition Mode and Boot Settings
Change partition mode to SMS menu, then to system server firmware boot, and later to operating system.
Virtual I/O Server Installation
Insert the Virtual I/O Server CD, select console and language, and start installation.
Finish Your System Setup
Accessing IBM Systems Hardware Information Center
Navigate to the IBM Systems Hardware Information Center via web browser or HMC.
Creating a Customized Checklist
Follow steps to create a customized checklist for server configuration and software installation.
