Power Systems
PCI adapter placement
for the 9119-FHB
IBM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9119-FHB and is the answer not in the manual?

Questions and answers

Related Manuals for IBM 9119-FHB

Summary of Contents for IBM 9119-FHB

  • Page 1 Power Systems PCI adapter placement for the 9119-FHB...
  • Page 3 Power Systems PCI adapter placement for the 9119-FHB...
  • Page 4 Before using this information and the product it supports, read the information in “Safety notices” on page v, “Notices” on page 27, the IBM Systems Safety Notices manual, G229-9054, and the IBM Environmental Notices and User Guide, Z125–5823. This edition applies to IBM Power Systems servers that contain the POWER7 processor and to all associated models.

  • Page 5: Table Of Contents

    Safety notices ....... . . v PCI adapter placement for the 9119-FHB..... . 1 Supported PCI adapters for the 9119-FHB I/O expansion units .
  • Page 6 Power Systems: PCI adapter placement for the 9119-FHB...

  • Page 7: Safety Notices

    You should also refer to the safety information documentation any time you do not clearly understand any safety information in the U.S. English publications. Replacement or additional copies of safety information documentation can be obtained by calling the IBM Hotline at 1-800-300-8751.
  • Page 8 Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the IBM provided power cord. Do not use the IBM provided power cord for any other product.
  • Page 9 Observe the following precautions when working on or around your IT rack system: v Heavy equipment–personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.
  • Page 10 Pack the rack cabinet in the original packaging material, or equivalent. Also lower the leveling pads to raise the casters off of the pallet and bolt the rack cabinet to the pallet. (R002) (L001) (L002) viii Power Systems: PCI adapter placement for the 9119-FHB...
  • Page 11 (L003) All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class 1 laser products. Outside the U.S., they are certified to be in compliance with IEC 60825 as a class 1 laser product.
  • Page 12 Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local regulations. In the United States, IBM has a process for the collection of this battery. For information, call 1-800-426-4333. Have the IBM part number for the battery unit available when you call. (C003)

  • Page 13: Pci Adapter Placement For The 9119-Fhb

    PCI, PCI-X, and PCIe adapters. The 9119-FHB system does not have any internal PCI slots. PCI adapters can be placed in I/O expansion units attached to the system. The following expansion units are supported for the 9119-FHB:...
  • Page 14 , IBM i, or Linux operating system Table 2 and Table 3 on page 5 list adapters supported on the IBM AIX, IBM i, or Linux operating systems. Not all adapters are supported on all operating systems. Exceptions are noted in the Description column.
  • Page 15 IBM Gigabit Ethernet-SX PCI-X Adapter (FC 5700; CCIN 5700) v One full-duplex 1000 Base-SX fiber connection to a gigabit Ethernet LAN v High bandwidth v OS support: AIX, IBM i, and Linux operating systems 5701 5701 IBM 10/100/1000 Base-TX Ethernet PCI-X Adapter (FC 5701; CCIN 5701)
  • Page 16 4764 4764 PCI-X Cryptographic Coprocessor (FC 4764; CCIN 4764) v Short, 64-bit, 3.3 V v OS support: AIX, IBM i, and Linux operating systems 5902 572B PCI-X DDR Ext Dual-x4 3 Gb SAS RAID Adapter (FC 5902; CCIN 572B) v Long, 64-bit, 3.3 V...
  • Page 17 Short, x1 v PCIe 1.1 v Two ports through RJ45 by using the DB9 connector v EIA-232 Compatible v OS support: AIX, IBM i, and Linux operating systems 5785 57D2 4 Port Async EIA-232 PCIe Adapter (FC 5785; CCIN 57D2)
  • Page 18 If both ports are planned to be active, the adapter must be treated as two extra-high bandwidth adapters. v OS support: AIX, IBM i, and Linux operating systems 5773 5773 4 Gb PCI Express Single Port Fibre Channel Adapter (FC 5773;...
  • Page 19 Extra-high bandwidth v PCIe 2.0 adapter with x8 generation 1 v Convergence enhanced Ethernet (CEE) supported v OS support: AIX, IBM i with VIOS, and Linux operating systems 5717 5717 4-port 10/100/1000 Base-TX PCI Express Adapter (FC 5717; CCIN 5717)
  • Page 20 Regular-height adapter v PCIe generation 1 or generation 2, x4 v High bandwidth v Four-port 1 Gb Ethernet v OS support: AIX, IBM i, and Linux operating systems EC28 EC27 PCIe2 2-port 10 GbE RoCE SFP+ adapter (FC EC28; CCIN EC27)

  • Page 21: I/O Expansion Units

    I/O expansion units Find information about the Peripheral Component Interconnect (PCI), PCI-X, and PCI Express (PCIe) ™ adapters supported in the I/O expansion units that are supported for the IBM Power Systems servers that contain the POWER7 processor. PCI adapter placement...

  • Page 22: Pci Slot Priorities For The 5797 And 5798 Expansion Units

    Ux-P1-C1 PCI-X DDR, 64-bit, 266 MHz Ux-P1-C2 Ux-P1-C3 Ux-P1-C4 Ux-P1-C5 Ux-P1-C6 Ux-P1-C7 Ux-P1-C8 PCI-X, 64-bit , 133 MHz Ux-P1-C9 Ux-P1-C10 Ux-P2-C1 PCI-X DDR, 64-bit, 266 MHz Ux-P2-C2 Ux-P2-C3 Ux-P2-C4 Ux-P2-C5 Ux-P2-C6 Ux-P2-C7 Power Systems: PCI adapter placement for the 9119-FHB...
  • Page 23 Table 4. Slot descriptions for the expansion unit (continued) Slot number Location code Description Ux-P2-C8 PCI-X, 64-bit , 133 MHz Ux-P2-C9 Ux-P2-C10 v All slots are compatible with PCI or PCI-X adapters. v All slots are long slots. Short adapters can go in long slots. v All slots support enhanced error handling (EEH).
  • Page 24 (FC 2849; CCIN 2849) 3, 13, 4, 14, 5, 15, 6, 16, 7, 17 v Short, 32 or 64-bit, 3.3 V v High bandwidth v Not hot-pluggable v OS support: AIX and Linux operating systems Power Systems: PCI adapter placement for the 9119-FHB...
  • Page 25 16, 7, 17, 8, 18, 9, 19, 10, 20 v One full-duplex 1000 Base-SX fiber connection to a gigabit Ethernet LAN v High bandwidth v OS support: AIX, IBM i, and Linux operating systems 5701 IBM 10/100/1000 Base-TX Ethernet PCI-X 1, 11, 2, 12, 3, 13, 4, 14, 5, 15, 6, Adapter (FC 5701;...
  • Page 26 1, 11, 2, 12, 3, 13, 4, 14, 5, 15, 6, 5721; CCIN 573A) 16, 7, 17, 8, 18, 9, 19, 10, 20 v High bandwidth v OS support: AIX, IBM i, and Linux operating system 5722 10 Gb Ethernet-LR PCI-X 2.0 DDR Adapter (FC 1, 11, 2, 12, 3, 13, 4, 14, 5, 15, 6, 5722;...
  • Page 27 – 572F is the CCIN on the SAS controller side of the double-wide adapter. – 575C is the CCIN on the write-cache side of the double-wide adapter. v OS support: AIX, IBM i, and Linux operating systems 5906 PCI-X DDR 1.5 GB cache SAS RAID Adapter 1, 11, 2, 12, 3, 13, 4, 14, 5, 15, 6, (FC 5906;...
  • Page 28 – 572F is the CCIN on the SAS controller side of the double-wide adapter. – 575C is the CCIN on the write-cache side of the double-wide adapter. v OS support: AIX, IBM i, and Linux operating systems 5912 PCI-X DDR Dual-x4 3 Gb SAS Adapter (FC 1, 11, 2, 12, 3, 13, 4, 14, 5, 15, 6, 5912;...
  • Page 29 8, 18, 9, 19, 10, 20, 1, 11, 2, 12, 3, 13, 4, 14, 5, 15, 6, 16, 7, 17 v Short, 32-bit, 66 MHz v No IOP v OS support: IBM i and Linux operating systems 6808 PCI Quad Modem IOA (FC 6808; CCIN 2805)

  • Page 30: Performance Notes

    12X links and this degrades the performance. PCI slot priorities for the 5803 and 5873 expansion units Learn about the PCI Express (PCIe) slots in the 5803 and 5873 expansion units. Power Systems: PCI adapter placement for the 9119-FHB...

  • Page 31: System Description

    System description The 5803 and 5873 expansion units are 24-inch, rack-mountable, I/O expansion drawers that are attached to the system by using 12X double data rate (DDR) cables. The expansion units can accommodate 20 PCIe, generation-3 cassettes. These cassettes can be installed and removed without removing the drawer from the rack.
  • Page 32 P2-C10 PHB20 Slot priority If the expansion unit is connected to a 9119-FHB system, place the adapters in the slots with the following slot priorities: 2 planar loop The following sequence is the slot priority for all adapters that use a two planar loop:...
  • Page 33 Short, x1 v PCIe 1.1 v Two ports through RJ45 by using the DB9 connector v EIA-232 Compatible v OS support: AIX, IBM i, and Linux operating systems 5723 2-port Asynchronous EIA-232 PCI Adapter (FC 5723; CCIN 5723) v PCI adapter...
  • Page 34 4 Gb PCI Express Dual-port Fibre Channel Adapter (FC 5774; CCIN 5774) v Short, x4 v Extra-high bandwidth v OS support: AIX, IBM i, and Linux operating systems 5748 POWER GXT145 PCI Express Graphics Accelerator (FC 5748; CCIN 5748) v Short, x1...
  • Page 35 Extra-high bandwidth v PCIe 2.0 adapter with x8 generation 1 v Convergence enhanced Ethernet (CEE) supported v OS support: AIX, IBM i with VIOS, and Linux operating systems 5717 4-port 10/100/1000 Base-TX PCI Express Adapter (FC 5717; CCIN 5717)
  • Page 36 PCIe Dual - x4 SAS Adapter (FC 5901; CCIN 57B3) v Short v Extra-high bandwidth v OS support: AIX, IBM i, and Linux operating systems 5903 PCIe 380 MB Cache Dual x4 3 Gb SAS RAID Adapter (FC 5903; CCIN 574E)
  • Page 37 Write cache backup of 1.8 GB v One PCIe x8 slot per adapter v Adapters are installed in pairs v OS support: AIX, IBM i, and Linux operating systems ESA1 PCIe2 RAID SAS Adapter Dual-port 6 Gb (FC ESA1; CCIN 57B4)
  • Page 38 Attach no more than two 1 Gb Ethernet ports per one processor in a system. More Ethernet adapters can be added for connectivity. v For best performance, connect each 5803 and 5873 half-drawer (10 slots) to a feature 1816, 12X DDR InfiniBand I/O hub controller, in the 9119-FHB system. Power Systems: PCI adapter placement for the 9119-FHB...
