Dacor Distinctive DECT304 Planning Manual

Document # PG03-003
Product tolerances: ±1/16" (±1.6 mm) unless otherwise noted

ProDUCT DImENsIoNs - DECT304

Model No.
DECT304
DECT365
* For reference only, See the product data label on bottom of unit for exact specifications.
Notes:
1. The cooktop is supplied with a flexible, 48 inch long
power conduit consisting of two (2) insulated hot lead
conductors (L1 and L2) and one (1) insulated ground
conductor. There is no neutral connection. All leads are
copper. The conduit is connected to the right rear corner
of the cooktop. Do not cut or lengthen the conduit.
2. These cooktops are not approved for recessed
installation.
All specifications subject to change without notice.
DECT304, DECT365
Distinctive ™
Electric Cooktops
iMPORTANT: DECT series cooktops are not approved for installation with a raised vent.
Electrical Circuit Required
240 Vac, 60 Hz, 30 Amps.
240 Vac, 60 Hz, 40 Amps.

ELECTrICAL sUPPLy rEqUIrEmENTs

30" and 36" Wide,
• Observe all governing codes and ordinances during planning
and installation. Contact your local building department for
further information.
• This appliance must be installed in accordance with the
accompanying installation instructions.
2"
(5.18 cm)

ProDUCT DImENsIoNs - DECT365

Total Connected
Load* Line and Ground Connections
6.7 kW (28 Amps.)
9.4 kW (39 Amps.)
www.dacor.com
Revised 02/13/12 Page 1/2
PLANNING
GUIDE
WARNiNG
Minimum Supply Wire Size
No. 10 AWG
No. 8 AWG
Phone: (800) 793-0093
2"
(5.18 cm)
