Bosch WZ20NXV550‑0 Technical Specifications

CCTV | WZ20 Integrated Day/Night High-res Bullet Camera
WZ20 Integrated Day/Night High-res
Bullet Camera
The WZ20 brings together high resolution LXR imaging,
the latest advances in mechanical filter lensing technology
and ruthlessly efficient dealer-friendly design. The camera
delivers 45 m (150 ft) of high performance night vision.
The WZ20 incorporates 30 LEDs which are powerful
enough to drive infrared to a maximum range of 91 m
(300 ft). For the purposes of CCTV surveillance imaging,
the resulting infrared illumination delivers high
performance night vision imaging up to a distance of 45 m
(150 ft).
The WZ20 uses proprietary LXR 1/3 in CCD technology,
delivering 550 TVL images. LXR technology is field-proven
for outstanding IR spectral response, as well as video
images characterized by low-smear, low-streak and
excellent anti-blooming characteristics.
Using a dual window IR-Cut and IR-Pass filter, the WZ20
delivers vivid color during day and outstanding sensitivity
to infrared at night. Photocell-control increases energy
efficiency and ensures accurate day-night switching for
outstanding 24/7 performance.
The WZ20 also features a versatile 5 to 50 mm IR-
corrected lens for outstanding performance under both
visible light and infrared illumination. Combined with the
mechanical filter technology, the WZ20 optical core
virtually eliminates focus shift between color and infrared
modes, allowing sharp focus during day or at night.
▶ 550 TVL high resolution 1/3 in LXR CCD
▶ Mechanical filter for vivid daytime color
▶ 46 m (150 ft) of high performance night vision
▶ 5 to 50 mm varifocal auto-iris IR-corrected lens
▶ IP66 with external zom and focus adjustments
Focus and zoom are controlled externally by hand,
requiring no tools and making the 5 to 50 mm IR-
corrected lens effortless to adjust. A 90º pan / 360º tilt
bracket and sunshield are both included as standard.
Functions
Applications
•
Commercial
•
Schools and colleges
•
Industrial sites
•
Residential
•
Warehouses
•
Parking lots
•
Retail
•
Hotels and nightclubs
•
Transportation hubs
•
Perimeters
Certifications and Approvals
Region Certification
Europe CE
