HD61
STANDARD RESOLUTION DAY/NIGHT DOME CAMERA WITH
VARI-FOCAL MANUAL IRIS LENS AND INFRARED ILLUMINATORS
The Performance Series rounds out Honeywell's camera portfolio with a variety of
indoor, outdoor and low light cameras that lets end users pick the perfect camera for
virtually any installation. Ideal for a diverse range of applications, the Performance
Series includes a wide range of high performing IR bullet cameras and mini-domes
that are easy to install and even easier to use.
The HD61 is a day/night indoor mini-dome camera that switches from color to
black and white mode depending upon available light. The HD61 incorporates a
1/3" CCD that offers 380 TV lines of crisp, clear horizontal resolution. The camera
comes equipped with 20 integrated LEDs and a built-in 4-9 mm IR corrected
aspherical Vari-focal Manual Iris lens for increased optical versatility and no focus
shift when the camera switches from day to night mode. The 3-D axis gimbal allows
versatile positioning and instant centering of the video image. In addition, the lens is
separated from the LEDs by an IR boot mechanism which eliminates internal IR glare.
The HD61 installs quickly and easily. It comes standard with a two-conductor pigtail
that connects to the barrel connector so there is no need to cut wires during
installation. It also features a video out port for easy focus. The HD61 is designed
for use indoors, mounted directly to a ceiling or wall.
Market Opportunities
The HD61 is a cost effective surveillance solution for applications that experience
changing light conditions throughout the day. The HD61 offers a simple yet solid
design that provides optimum performance for all indoor applications including
schools, colleges, universities, hospitals and commercial sites.
Features
• Standard resolution color: 380
TVL - 1/3" Sony Super HAD CCD
• Day/night with 20 LEDs
• Photocell-controlled and powered
by an array of 20 high-efficiency
LEDs (850 nm)
• Photocell-controlled on/off switching
of infrared illumination
• Built-in 4-9 IR corrected aspherical
Vari-focal Manual Iris lens
• On screen display menu for easy
setup of camera
• Even distribution IR for optimal
image capture
• Total effectiveness in zero lux
environments
• IR LED visible range of ~65 ft. (20m)
• 3-D axis gimbal
• Video out port for setup
• Two-conductor pigtail is standard for
connection to barrel connector
www.honeywellvideo.com

Advertisement

   Related Manuals for Honeywell HD61

   Summary of Contents for Honeywell HD61

  • Page 1 It also features a video out port for easy focus. The HD61 is designed for use indoors, mounted directly to a ceiling or wall.
  • Page 2: Specifications

    4-9 mm VFMI Lens, 12 VDC NTSC 1/3" CCD Integrated Day/Night Standard Resolution IR Resistant Dome Camera, 380 TVL, 20 LEDs, HD61X 4-9 mm VFMI Lens, 12 VDC PAL Honeywell Security & Data Collection Honeywell 2700 Blankenbaker Pkwy, Suite 150 Louisville, KY 40299 L/HD61D/D 1.800.796.CCTV (2288)
