Honeywell HD60 Series Operation Manual

Hd60 series.
Hide thumbs


Advertisement

You must be fully aware of all the distinctive
features and precautions related to this
COMPOSITION:
camera before installing it.
Service Monitor Cable
Operation Manual
Mounting Screw
INSTALLATION:
Ceiling
1
Stick the guide pattern on the
wall or ceiling.
2
Drill four holes according to
the guide pattern then insert
anchors into the drilled holes.
Draw out power / video wires
3
to the connecting places.
Fixed the camera to a celling
4
using four screws.
Adjust desired focus and scene
5
by turning and moving the
3-axis camera bracket by hand.
6
Put the dome cover over the
base.
7
Fix the dome cover on the base
by covering.
Insert coin to the side
hole and remove the
dome cover by twist coin.
PRECAUTIONS:
!
Do not install the camera in
extreme temperature conditions.
Do use the camera under conditions where
temperatures are within -10¡ÆC to 45¡ÆC.
Be especially careful with ventilation
under high temperatures.
!
Do not install or use the camera
in an environment where the
humidity is high.
It can cause the image quality to be poor.
!
Do not disassemble the camera.
There are no user-serviceable parts
inside it.
!
Do not drop the camera or
subject them to physical shocks.
It can cause malfunctions to occur.
!
Note
When this camera is installed near
wireless communication devices
that emits strong electromagnetic
field, irregularity such as noise on
the monitor may appear.
CONNECTION:
#1
Connecting to
Monitor and Power
12VDC Power Type
#2
DIMENSIONS(mm):
100.0
Guide Pattern
130.6
SPECIFICATIONS:
Guide Pattern
Model
Signal System
Scanning System
Scanning Frequency ( H )
Dome Base
Scanning Frequency ( V )
Image Sensor
Total / Effective Pixels No.
S / N Ratio
Resolution
Mounting
Video Output Level
Screw
Lens
Focus
Sync. System
Sensitivity
Electronic Shutter
White Balance
AGC
Dome Cover
BLC
Flickerless
Input / Output Connector
NO TE
Power Consumption
Dome Size ( Ø )
Weight
Call 1.800.796.CCTV for sales, service and customer support.
NAME AND FUNCTION:
Fixed Lens & IR LED Type
1
2
Tilt rotation: Adjusting the vertical angle.
1
Pan rotation: Adjusting the horizontal angle.
2
3
Horizontal rotation: Adjusting the horizontal
position of the screen.
• Power Consumption: 5W
IR LED (4mm Fixed Lens)
• IR LED Specification: 850nm / 30¡Æ(24EA)
• The wire is polarized. • Use 12VDC
Video Output
Video
(Yellow)
No.
Function
#1
Video Output
GND
#2
Power Input
Power - 12VDC
(Red)
NTSC
PAL
NTSC : 525 Lines
PAL : 625 Lines
2 : 1 Interlace
15.734kHz
15.625kHz
59.94Hz
50Hz
1/3" SONY Super HAD CCD
270K / 250K
320K / 290K
More than 48dB (AGC Off)
380 TV Lines
1.0 Vp-p (75 Ohms, composite)
Fixed Lens : f=4.0mm, 81º
Manual
Internal
0 Lux, IR LED
1/60 ~ 100,000 Sec.
1 /50 ~ 100,000 Sec.
Auto
On / Off
On / Off (with Slide Switch)
On / Off (with Slide Switch)
Power, Video
12VDC (10.8V~15V), 0.4A / 5W (Max)
100mm
Approx. 366g
Need Help?
www.honeywellvideo.com
Design and specifications are
subject to change without notice.
5
4
3
IR LED: 850nm / 30¡Æ(24EA)
4
Sensor
5
Camera Lay-out
power source.
Terminal Color
Remark
Yellow
1.0 Vp-p
Red
12VDC(10.8V~15V), 0.4A/5W(Max)
HD60
Series
Operation
Manual
• 1/3" Sony Super HAD CCD
• 380 TV Lines Resolution
• 4mm Fixed Lens
• Color Day/Night with 24 LEDs
• Auto White Balance
• AGC, BLC, Flickerless On/Off
• Extra Video Output for Installer
• 3-Axis Camera Construction
• Diameter of Bubble : 100mm
3-axis
Built-in
camera
bracket makes it much
360º
easier to rotate in any
direction.
CAMERA SET-UP:
Fixed Lens & IR LED Type
a
Function Selection Switch:
J504
•FL(Flickerless) ON/OFF
AC24V
•AGC(Auto Gain Control) ON/OFF
b
•BLC(Back Light Compensation)
ON/OFF
Service Monitor Connecter:
b
Use service monitor connector
to set camera angle & focus
AC 24V
when installing.
J503
BLC
ON
AGC
OFF
CAUTION : When AGC is off,
FL
ON
D/N does not work because the
a
D/N switching function is
dependent on the AGC level.
TROUBLESHOOTING:
If you have trouble operating your camera, refer to the following.
If the guidelines do not enable you to solve the problem, contact an authorized technician.
Check the power source for the monitor and camera
The image does not
and ensure that the voltage and polarity are properly
appear on the screen.
connected and being supplied correctly.
Check if the lens is stained. If dirty, clean the lens with
The image on the
a soft, clean cloth.
screen is dim.
Adjust the Back Focus of the lens again.
Check if you have connected the camera to a proper
The camera does not work
properly, the surface of the
power source and If there is no problem with the power,
camera case is hot, and a black
turn the unit off immediately and seek assistance from
line appears on the screen.
our Customer Service department.
Check if the camera is pointed toward the sun or a
The screen blinks a lot.
fluorescent lamp.
Adjust the angle or location of the camera if too much
light is coming into the screen.
READ AND KEEP THIS
OPERATION MANUAL
90º
360º
