Specifications - Honeywell HCC334E Specifications

HCC334E

SPECIFICATIONS

Operational
Video Standard
Scanning System
Image Sensor
Number of Pixels
(H x V)
Minimum
Illumination
Horizontal
Resolution
Video Output
Sync System
S/N Ratio
Auto Gain Control High/low
ALC
Automatic
Electronic Shutter
Line Lock Phase
Adjust
BLC
Electrical
Input Voltage
Input Range
Power
Consumption
Mechanical
Dimensions
(W x H x D)
Weight
Construction
Camera Mount
Lens Mount
Connector
Power Indicator
Ordering
HCC334E
HCC334EX
HCC335EX
NOTE: Honeywell reserves the right, without notification, to make changes in product design or specifications.
Honeywell Security
Honeywell Video Systems
2700 Blankenbaker Pkwy, Suite 150
Louisville, KY 40299
1.800.796.CCTV
www.honeywell.com
NTSC, PAL
525/60 lines (NTSC)
625/50 lines (PAL)
1/3" Interline Transfer CCD
510 x 492 (NTSC)
500 x 582 (PAL)
0.75 lux @ F1.2 (50 IRE)
330 TVL
1.0 Vp-p @ 75 Ohms
12 VDC: Internal
24 VAC: Line lock, Internal
50 dB typical
Adjusted (with direct drive Auto Iris lenses)
1/60 – 1/100,000 sec (NTSC)
1/50 – 1/100,000 sec (PAL)
Adjustable line lock vertical phase
On/off
12 VDC/24 VAC
10 - 14 VDC, 20 - 28 VAC
4.5 W (max)
2.27" x 2.57" x 5.56"
(57.9 mm x 65.2 mm x 141.2 mm)
1.5 lb (0.68 Kg) camera only
Housing: Aluminum
Finish: Cool gray powder coat
1/4 – 20 UNC (top and bottom)
C/CS adjustable mounting ring
Video Output: BNC connector
Lens: 4-pin connector
Power Input: Push terminals
with ground
LED
1/3" Standard-Resolution Color Camera with DSP, 330 TVL, 12 VDC/24 VAC, NTSC
1/3" Standard-Resolution Color Camera with DSP, 330 TVL, 12 VDC/24 VAC, PAL
1/3" Standard-Resolution Color Camera with DSP, 330 TVL, 230 V, PAL
HV05262
L/HCC334E/D
August 2006
© 2006 Honeywell International Inc.
www.honeywellvideo.com
Environmental
Operating: 14°F to 122°F (-10°C to 50°C)
Temperature
Storage: -4°F to 140°F (-20°C to 60°C)
Relative
20% to 80%, non-condensing
Humidity
Regulatory
Emissions FCC, CE (EN55013)
Immunity CE (EN50130-4)
Safety EU: 73/23/EEC LVD
Accessories
Recommended Lens Options
HLD25V6F12L 2.5 – 6 mm, F1.2, DC Auto Iris lens
HLD28V8F95L 2.8 – 8 mm, F0.95, DC Auto Iris lens
2.7 – 13.5 mm, F1.3, Aspherical
HLD27V13DNL
Vari-focal lens
HLD5V50F13L 5.0 – 50 mm, F1.3, DC Auto Iris lens
Housing and Mounts
HBC5WT Wall/Ceiling Mount Bracket
HHC12 Series Environmental Housing
Transformers
24 VAC, 20 VA Class 2 plug-in with thermal
HPT2420
cut-out
12 VDC, 500 mA plug-in regulated 2.1 mm
HPT12DC500
coaxial plug UL Listed/CSA Certified
Power Supplies
UL Listed Fused Smart Fused
HPTV2404UL HPTV2404 HPTV2404CB
HPTV2408UL HPTV2408 HPTV2408CB
HPTV2416UL HPTV2416 HPTV2416CB
Front View
Side View
2.57"
(65.2 mm)
5.56" (141.2 mm)
Description
4 A, 4 Output
4 A, 8 Output
8 A, 16 Output
Rear View
OFF
