Summarization of Contents
Optional Items and Safety Precautions
Optional Items for Order
List of items available for separate purchase, such as mounting kits and microphones.
Safety and Mounting Hardware Requirements
Ensures product support and installation by qualified personnel according to regulations.
Ventilation and Required Tools
Ventilation Requirements
Maintains proper airflow by ensuring a minimum clearance around the codec.
Tools for Setup
Lists common tools that may be needed for the installation process.
Decide Quad Camera Positioning
Mount Camera Below Screen
Mount camera below the screen when screen height exceeds 120 cm/47 inches.
Mount Camera Above Screen
Mount camera above screen when height is less than 120 cm/47 inches, recommending 80 cm screen height.
Mount Quad Camera Wall Bracket
Wall Bracket Mounting Dimensions
Specifies the required distances (8cm/3.2", 6mm/0.25") for wall bracket installation.
Camera Tilt Clearance Note
Ensures sufficient space for full camera tilt when mounted above the screen.
Attach and Adjust Quad Camera
Attach Camera to Bracket
Securely attach the Quad Camera to the wall bracket, confirmed by an audible click.
Determine Quad Camera Tilt Angle
Select the appropriate tilt angle based on the camera's mounting height.
Adjust Quad Camera Tilt Angle
Use sliders to adjust tilt from 0° to 15°, ensuring proper forward tilt clearance.
Connect Cables to Devices
Connect Codec Cables
Instructions for connecting power and other cables to the Cisco Webex Codec Plus.
Connect Quad Camera Cables
Instructions for connecting power and cables to the Cisco Quad Camera.
Final Setup and Cable Management
Return Camera to Normal Position
Return the Quad Camera to its upright position after adjustments or releases.
Cable Arrangement for Tilt
Arrange cables with sufficient slack to prevent disconnection during camera tilt.
Complete Software Setup
Power on the screen and follow on-screen prompts to finalize device configuration.
Device Port Identification
Cisco Webex Codec Plus Ports
Detailed labeling of all ports and connectors on the Codec Plus device.
Cisco Quad Camera Ports
Detailed labeling of all ports and connectors on the Quad Camera device.
Release Quad Camera from Bracket
Camera Release Steps
Step-by-step instructions to detach the Quad Camera from its wall mount.
Unlock Lever Warning
Caution against leaving the camera unlocked on the bracket to prevent accidental detachment.
