MANUAL DEL USUARIO
USER MANUAL
MANUEL D'ENTRETIEN
LIBRETTO D´USO
BETRIEBSANLEITUNG
50
4 STROKE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K2 QUAD 50 and is the answer not in the manual?

Questions and answers

Summary of Contents for GAS GAS K2 QUAD 50

  • Page 1 4 STROKE MANUAL DEL USUARIO USER MANUAL MANUEL D’ENTRETIEN LIBRETTO D´USO BETRIEBSANLEITUNG...
  • Page 3 4 STROKE SERVICE MANUAL SERVICE MANUAL...
  • Page 5 INTRODUCTION Congratulations on your purchase of QUAD 50 - 4 STROKE it represents the result of many years of our experience in the production of fine machines. You can now appreciate our craftsmanship and reliability of the master piece. This manual will provide you with a good basic understanding of the features and operation of this machine. This manual includes important safety information.
  • Page 7: Table Of Contents

    CONTENTS 1. LOCATION OF THE “WARNING AND Turning ..............18 SPECIFICATION LABELS” ........5 Climbing uphill ............19 2. NOTES FOR SAFEY.......... 7 Crossing through shallow water......19 3. DESCRIPTION ..........9 4. MAINTENANCE ..........20 Parts location ............9 Maintenance schedule ...........
  • Page 9: 1. Location Of The Warning And Specification Labels

    1. LOCATION OF THE WARNING AND SPECIFICATION LABELS Read and understand all of the labels on your machine. They contain important information for safe and proper operation. Never remove any labels from your machine. If a label becomes difficult to read or comes off, a replacement lable is available from your dealer.
  • Page 11: Notes For Safey

    N0TES FOR SAFETY – Read this owner's manual carefully before riding. – Don't allow your child to ride without supervision. – This vehicle is designed for the riders age 6 and older – Don't take alcohol or drugs when riding.They can for 50cc displacement.
  • Page 12 – Always be careful when skidding or sliding. Learn to – Always use the size and type of tires specified in this safely control skidding or sliding by practicing at low manual. Always maintain proper tire pressure as speeds and on level,smooth terrain.On extremely described in this manual.
  • Page 13: Description

    3. DESCRIPTION PARTS LOCATIONS 1. Fuel tank. 2. Fuel valve. 3. Throttle lever. 4. Rear brake lever. 5. Engine stop switch. 6. Starter. 7. Lights switch.
  • Page 14: Identification Number Record

    IDENTIFICATION NUMBER RECORD (2) Engine number For ordering spare parts from our dealer or for reference in case the vehicle is stolen, record vehicle identification number and engine number in the spaces provided for assistance. (1) vehicle identification number. The vehicle identification number is stamped on vehicle frame.
  • Page 15: Parts Function

    PARTS FUNCTION b. Throttle lever a. Engine stop switch The throttle lever is beside the right handlebar grip to The engine stop switch is on the left handlebar. When be activated by the right hand thumb. To accelerate the the switch is in the “OFF” position, the engine will not vehicle, simply press lever forward.
  • Page 16 c. Parking brake Always keep the disc plate clean, refrain from grease. When parking, squeeze the left hand brake lever. And at this moment press the parking brake button on the left handlebar brake set. Make sure that the brake lever is locked for more safety.
  • Page 17: Fuel

    • e. Safety switch OFF Switch mark “ ” There is a rider safety device with this vehicle. The If the lever is in this position. fuel will not flow, Alaways turn the lever to this position when the engine is not safety switch is located behind the body.
  • Page 18: Engine Oil

    Res Switch mark “ ” b. Fuel tank After refueling return the fuel cock lever to the "ON" Fuel tank capacity is 3.2liter (0.87gal). gasoline with position. octane number of 91 or higher may be used. when your QUAD run out of fuel while riding, Turn the After refueling,be sure to tighten the tank cap firmly.
  • Page 19: Tires

    The pressure should be checked when the tires are "cold" before running the vehicle. Tire wear limit When the tire groove decreases to 3mm (0.1" ) due to wear. replace the tire. Oil hole Light switch The light swith is on the left handbar. when the switch •...
  • Page 20 Check brake operation. If any problem cannot be corrected by the adjustment, have the QUAD inspected by leader. Check tires condition and pressure as recommended. Check throttle for smooth opening and closing. lt must return back to idle position when released. Check engine stop switch for good function.
  • Page 21: Starting Procedure

    STARTING PROCEDURE RIDING 1. Parking the vehicle on a level surface and lock the Begin by finding a safe area free of obstacles with a parking brake. level surface. Always keep your feet on the footrest 2. Turn the fuel valve to “ON”. during operation.
  • Page 22: Parking

    TURNING It is essential that this skill shall be learned at first at low speed. The rider must learn to move his weight and control the throttle to allow the rear tires to get the turn. When turning, the wheel on the outside of the turn must travel a wider radius and thus a greater distance than the inside wheel.
  • Page 23: Climbing Uphill

    Crossing through shallow water. Climbing uphill QUAD 50 can be used to cross slow moving, shallow Practice riding at first on gentle slopes. Try more difficult water of up to a maximum of 16 cm (6.3") in depth. climbs only after you have developed your skill. Avoid Entering the water where there is no sharp drop off, excessive steep hills or slopes.
  • Page 24: Maintenance

    4. MAINTENANCE MAINTENANCE SCHEDULE The maintenance intervals in the following table are based upon average riding and conditions. Riding in unusual dusty areas require more frequent servicing. Item INITIAL SERVICE REGULAR SERVICE EVERY YEAR (First week) (every 30 operating days) Fuel line Throttle opertion Air cleaner...
  • Page 25: Spark Plug

    SPARK PLUG Standard spark plug; TORCH LDE6T 1. Disconnect the spark plug cap. 2. Clean up dirt from around the spark plug base. 3. Remove the spark plug. 4. Inspect the plug electrodes for wear.lf the electrodes and insulator tip appear unusually fouled or burned. change a new one.
  • Page 26: Carburetor And Idle Speed Adjustment

    4. Let the filter element dry and reinstall it. BRAKE Air cleaner Check the brake cable for kinks or signs of wear that could cause sticking or failure. Lubricate the brake CARBURETOR AND IDLE SPEED ADJUSTMENT cable with a available cable lubricant to prevent pre- The carburetor is a vital part of the engine and requires mature wear or corrosion.
  • Page 27: Drive Chain

    3) Tighten those bolts and nuts. Rear axle housing DRIVE CHAIN THROTTLE CABLE Inspect throttle cable condition and operation. Replace Sometimes,it needs to lubricate the chain. The SAE the cable if it has become worn or kinked. 80 or 90 gear oil is recommended. The chain will loosen with use, how to adjust chain.
  • Page 28: Battery

    The free play should be maintained at 5-10mm (0.197- Check the level of battery fluid and see if the terminals are tight. 0.254). Add distilled water if the fluid level is low. The level should be between the upper and lower level marks. BATTERY When reinstalling the battery, be sure to connect the red cable to the positive (+) lead and the black cable...
  • Page 29: Specifications

    Power max 3.8KW/8000 rpm Fuel RON 90 # Unlead Torque max 4.5N-m/6000 rpm Engine oil SAE20 Dimension Gear oil API GL-5 Wheelbase 828 mm Length 1335 mm SPECIFICATIONS Seat Height 542 mm Engine Quad 50 Width 730 mm Displacement 49CC Height 780 mm Cylinder...
  • Page 30: Warranty Terms And Conditions

    Warranty terms of the manufacturer GASGAS Motos, S.A. The company GAS GAS MOTOS, S.A. (hereafter referred to as “GG”), with this present document guarantees the consumer, the purchaser of a vehicle manufactured by GG, that both the materials and the manufacturing are free of defects in accordance with the highest standards of quality.
  • Page 31 Obligation of the purchaser GG will have the right to reject any claims under Warranty in the event that: a) The purchaser has failed to submit the vehicle to any of the inspections and/or maintenance work required in the Users’ Manual, or has exceeded the date set for such inspections or maintenance work.
  • Page 32 e) Any damages caused as a result of the defects, as well as any expenses incurred either directly or indirectly as a consequence of the defects (for example, communication costs, accommodation expenses, car hire costs, public transport costs, breakdown truck fees,, courier costs, etc.), as well as other financial losses (for example, those caused by the loss of the use of the vehicle, loss of income, time lost, etc.) f) Any acoustic or aesthetic phenomenon that does not significantly affect the condition or use of the motorcycle (for example, small or hidden imperfections, noise or vibrations that are normal in use, etc.)
  • Page 36 RECOMIENDA EL USO DE ACEITE: RECOMMENDS THE USE OF OIL: RECOMMANDE L’USAGE DE L’HUILE: CONSIGLIA L’USO D’OLIO: EMPFIEHLT DEN GEBRAUCH VON ÖL: JUNIO / JUNE / JUIN / GIUGNO / JUNI 2006 C/ UNICEF nº 17 · Poligon Industrial Torremirona · 17190 Salt (Girona) SPAIN · Tel: +34 902 47 62 54 Fax: +34 902 47 61 60 E-mail: officegg @ gasgasmotos.es / partsgg @ gasgasmotos.es...

This manual is also suitable for:

K2 quad 50 4 stroke
