- Page 1 Entryphone ® DOOR ENTRY SYSTEMS 500 Series Video Schematics, connection diagrams and installer's notes For the system installed at:...
- Page 2 There are no individual call lines for the 500 series systems, instead each phone has a switch setting that should be set when the telephone is installed.
- Page 3 12v D C Max 300mA Key: line function 1 Video - 2 Video + 3 Data 4 24V- 5 24V+ 6 Lock Data + 7 Lock Data - GRN/ WHT/ BLU/ WHT/ ORG/ BRN/ WHT/ Entryphone ® page 4 Entryphone ® page 5...
- Page 4 Key: line function 1 Video - 2 Video + 3 Data 4 24V- 5 24V+ 6 Lock Data + 7 Lock Data - GRN/ WHT/ BLU/ WHT/ ORG/ BRN/ WHT/ Entryphone ® page 6 Entryphone ® page 7...
- Page 5 Key: line function 1 Video - 2 Video + 3 Data 4 24V- 5 24V+ 6 Lock Data + 7 Lock Data - GRN/ WHT/ BLU/ WHT/ ORG/ BRN/ WHT/ Entryphone ® page 8 Entryphone ® page 9...
- Page 6 6 Lock Data + 7 Lock Data - line apparatus - note the power supply in this example is mid-line GRN/ WHT/ BLU/ WHT/ ORG/ BRN/ WHT/ Entryphone ® page 10 Entryphone ® page 11 and the jumper is removed.
- Page 7 (see fig.3) (see fig.4) 2nd Camera input (see fig.7) 500 series entrance panels are supplied with the 500LSV loud- speaking amplifier assembly fitted and the call buttons are Fig.1 inter-equipment Matrix connection to buttons pre-wired. It is not necessary...
- Page 8 This example shows switches 2 (binary value 2), 4 (binary value 8) & 5 (binary value 16) down. 8 4 2 1 Therefore 2+8+16 = 26. Binary Value Entryphone ® page 14 Entryphone ® page 15...
- Page 9 The Entryphone Company Limited, 23 Granville Road, London, SW18 5SD 020 8870 8635 020 8874 0066 enquiries@entryphone.co.uk www.entryphone.co.uk ® ENTRYPHONE is a trade mark registered in Britain No. B1037141.
