Summarization of Contents
IMPORTANT SAFETY INSTRUCTIONS
How to Avoid Irritating Feedback
Guidance on microphone placement and speaker positioning to prevent audio feedback and distortion.
Setting Level Controls
Microphone Presentations
Steps for connecting and setting up microphones for optimal audio input levels.
Line Input
Instructions for connecting external audio sources via line-level inputs like XLR or 1/4" TRS.
Wireless Speaker Linking
Procedure for wirelessly connecting two TPA units for stereo sound via TWS.
Bluetooth Pairing
Guide to connecting Bluetooth-enabled devices for wireless audio streaming.
AUX Input
Connecting audio sources via RCA or 3.5mm auxiliary inputs for playback.
Line Out Balanced Connection
Details on using the MONITOR OUT XLR port to connect to other audio equipment.
Functions
MIC/LINE input section
Controls for microphone and line-level inputs, including gain, EQ, and selectors.
BT/AUX input section
Controls for Bluetooth and auxiliary inputs, including volume and selector switch.
POWER/ CLIP LED indicator
Explanation of the power status and clip indicator LED for monitoring signal levels.
REVERB level input control
Adjusting the reverb effect level for the audio inputs.
SUB volume control
Control for adjusting the volume level of the subwoofer.
MASTER VOLUME
The main volume control for the entire system output.
MONITOR STERO/MONO selector button
Selects the audio output format for the monitor connections.
Battery status LED indicators
Indicators showing the current charge level of the internal battery.
XLR monitor output
Output port for sending the main audio signal to external devices.
Power switch
The main switch for turning the unit on and off.
Voltage selector switch
Switch to select between 115V and 230V AC power input.
