Instruction manual

Advertisement

24116
Universal Remote
Instruction Manual

Advertisement

Table of Contents
loading

Summary of Contents for GE 24116 - 4 - Device Universal Remote

  • Page 1 24116 Universal Remote Instruction Manual...
  • Page 2: Table Of Contents

    Table of Contents Introduction..............3 Button.Functions............4 Initial.Setup..............6 . Battery.Installation..........6 . Battery.Saver............6 . Code.Saver.............. 6 . Power-On.default..........6 . Code.Setup.............. 6 Direct.Code.Entry............7 Code.Search..............8 Code.Identification.Feature........9 Setup................10 . Programming.Combo.Device.Codes..10 .
  • Page 3: Introduction

    Introduction Congratulations.on.your.purchase.of.the. 24116.Universal.Remote.Control..It.is.one. of.the.most.unique.looking,.and.easy.to.use. remote.controls.available.today..With.the. 24116.Universal.Remote,.juggling.multiple. remote.controls.is.a.thing.of.the.past.. Your.24116.Universal.Remote.controls.up. to.4.devices,.including.the.most.popular. brands.of.TV,.DVR,.DVD,.SAT,.CBL,.and.audio. equipment.. Note:.Some.functions.from.your.original. remote.may.not.be.controlled.by.the.24116. Universal.Remote..Use.the.original.remote,. if.available,.to.control.such.functions.. Sometimes.buttons.other.than.described. in.these.instructions.may.actually.perform. the.function..For.example,.the.CHAN.and. VOL.buttons.might.be.used.to.navigate. through.menu.choices..We.recommend.you. experiment.with.the.remote.to.identify.if. such.situations.pertain.to.your.equipment.. The.24116.Universal.Remote.is.easy.to. use,.easy.to.program,.and.it.gives.you.total. control—at.the.touch.of.your.fingertips!
  • Page 4: Button.functions

    Button Functions Note:.The.Record.button.must.be.pressed.TWICE.to.record.. For.some.brands.of.VCRs,.you.might.need.to.press.the. Record.button.once,.then.press.it.again.for.three.seconds.. Some.buttons.on.the.remote.might.have.functions.that. are.referred.to.by.different.names.on.the.device.you.are. controlling..E.g.,..LAST.may.be.called.RECALL,.or.ENTER may.be.called.DISPLAY..These.differences.depend.on.the. brand.and.model.of.your.product..Also,.this.remote.can. only.operate.features.that.exist.on.your.product..E.g.,.your. product.must.have.LAST.ability.for.the.LAST.button.to. operate.this.feature.
  • Page 5 Button Functions, cont. 1. ON-OFF: Turns.device.On.or.Off. 2. Red Indicator:.Lights.when.any.button.is.pressed. 3. TV, DVD, CBL/SAT, DVR/AUX:.Selects.product.to. be.operated.. 4. MUTE: Turns.off.the.TV.sound.while.the.picture. remains.. 5. VOLUME UP/DOWN: Changes.the.volume.level.of. the.product,.normally.the.TV. 6. UP,.DOWN,.LEFT &.RIGHT: Navigation.buttons. 7. MENU: brings.up.the.DVD.disc.Menu.screen..Use. with.the.UP,.DOWN,.LEFT &.RIGHT navigation. buttons. 8. ENTER:.Used.after.direct.channel.number.entry.to. immediately.change.to.the.selected.channel. 9. NUMBERS:.Enter.numbers.for.direct.channel. selection..Some.products.require.Enter.to.be. pressed.after.channel.selection. •...
  • Page 6: Initial.setup

    Initial Setup Battery Installation 1.. On.the.back.of.the.remote,.push.down.on.the.tab. and.lift.the.cover.off. 2.. Match.the.batteries.to.the.+.and.-.marks.inside.the. battery.case,.then.insert.2.AAA.alkaline.batteries. 3.. Press.the.battery.cover.back.into.place. Battery Saver Your.remote.automatically.turns.off.if.the.buttons. are.depressed.more.than.30.seconds..This.will.save. your.batteries.should.your.remote.get.stuck.in.a.place. where.the.buttons.remain.depressed.(e.g.,.between. the.sofa.cushions). Code Saver You.have.up.to.10.minutes.to.change.the.batteries. in.your.remote.without.losing.codes.you.have. programmed..However,.do.not.press.any.buttons.until. batteries.are.installed.in.the.remote..If.buttons.are. pressed.without.batteries.in.the.remote,.all.the.codes. will.be.lost.. Power-On Default The.remote.powers.on.in.TV.mode. Code Setup The.SETUP.button.is.used.to.setup.the.remote..You. can.either.setup.the.remote.using.the.code.for.your. brand.of.product,.from.the.code.tables.(on.separate. sheet),.or.you.can.search.through.the.library.of.codes. until.you.find.a.code.that.works.for.your.product. Please.refer.to.“Code.Search”.on.page.8.for.more. information.on.using.the.code.search.feature.to.learn. how.to.search.through.the.library.of.codes.for.your. products. NOTE:.You.can.store.any.kind.of.code.under.any.
  • Page 7: Direct.code.entry

    Direct Code Entry 1..Press.and.hold.the.SETUP.button.until.the.red. indicator.stays.on,.then.release.the SETUP.button. 2..Press.and.release.the.desired.mode.button.(TV, DVD,.etc.)..The.red.indicator.blinks,.then.stays.lit... 3.. Enter.the.4-digit.code.from.the.code.tables.(on. separate.sheet)..Note:.After.a.valid.code.entry,.the. red.indicator.turns.off...For.an.invalid.code,.the.red. indicator.flashes. 4.. With.your.device.on,.press CHAN UP..If.the.device. responds,.no.further.programming.is.required.. Note:.If.some.buttons.do.not.operate.your. equipment,.try.one.of.the.other.codes.for.your. brand. Write.your.codes.down.here.for.easy.reference.later. Device. Device.stored. Code TV. . DVD. CBL/SAT DVR/AUX...
  • Page 8: Code.search

    Code Search If.your.product.does.not.respond.after.you.have.tried. all.the.codes.for.your.brand,.or.if.your.brand.is.not. listed,.try.searching.for.your.code.by.following.these. steps. 1.. Manually.turn.on.the.device.(TV,.DVD,.etc.).to.be. controlled. 2.. Press.and.hold.the.SETUP.button.until.the.red. indicator.stays.on,.then.release.the.SETUP button. 3... Press.and.quickly.release.the.desired.mode.button. (TV,.DVD,.etc.)..The.red.indicator.blinks.off.once. 4.. Press.the.CHAN UP.button.repeatedly.(up.to.300. times).until.the.device.to.be.controlled.changes. channel..The.red.indicator.blinks.off.with.each. button.press...If.you.accidentally.overshoot.the. code.required,.press.the.CHAN DOWN button. to.backtrack.through.the.library.until.the.device. changes.channel..Pressing.CHAN UP.changes. direction.to.forward.again.. .. Press.and.release.ENTER to.install.the.code.. Most.users.store.DVD.codes.under.the.DVD button,. Cable.codes.under.CABLE,.etc..If.(for.example).you. want.to.store.a.DVD.code.under.CABLE,.first.follow. the.procedure.for.Direct.Code.Entry.(previous.page). and.press.CABLE in.step.2.of.Direct.Code.Entry,.then. enter.ANY.DVD.code.in.step.3.of.Direct.Code.Entry.. Then.follow.the.steps.for.Code.Search.on.the.previ- ous.page..Note:..If.the.device.does.not.have.a CHAN UP.button,.use.PLAY (DVD.only).or.ON-OFF instead..
  • Page 9: Code.identification.feature

    Code Identification Feature The.Code.Identification.Feature.allows.you.to.identify. the.four.digit.library.code.stored.under.your.device. key..For.example,.if.you.want.to.find.out.what.4-digit. code.is.stored.under.your.TV.device.key,.follow.the.six. steps.below: 1.. Press.and.hold.the.SETUP.button.until.the.red. indicator.stays.on..Release.the SETUP.button. 2.. Press.and.release.the.desired.mode.button.(TV,. DVD,.etc.)..The.red.indicator.blinks,.then.stays.lit... 3.. Press.and.release.the.SETUP.button..The.red. indicator.blinks.off. 4.. To.find.the.first.digit.for.the.code.stored.under.the. mode.key.pressed.in.step.2,.press.each.numeric. key.from.0-9.in.turn..When.the.red.indicator.blinks. off.the.number.you.pressed.is.the.first.digit.for.the. code.you.are.searching.for. .. To.find.the.second.digit,.repeat.step.4,.this.time. when.the.red.indicator.blinks.off.this.is.the.second. digit. 6.. Repeat.step.4.again.to.find.the.third.and.fourth. digits..This.time.the.red.indicator.turns.off.and. stays.off.
  • Page 10: Setup

    Setup Programming Combo Device Codes Some.Combo.devices.(e.g.,.TV/VCR,.TV/DVD,.DVD/ DVR,.etc.).will.require.you.to.set.up.two.different.Mode. buttons.to.control.both.parts.of.the.Combo.device.. For.example,.if.you.have.a.TV/DVD.Combo,.you.might. need.to.set.up.one.code.under.the.TV button.to. control.the.TV.part.AND.a.separate.code.(under.any. other.Mode.button).to.control.the.DVD.part. Controlling Combo Devices Some.Combo.devices.(e.g.,.TV/VCR,.TV/DVD,.DVD/ DVR,.etc.).have.separate.buttons.on.the.original. remote.to.select.the.part.of.the.Combo.device.to. be.controlled..For.example,.if.your.Combo.device. is.a.DVD/DVR.then.its.original.remote.might.have. separate.DVD.and.DVR.buttons.for.selection.of.the. Combo.part.you.would.control..The.equivalent.button. functions.can.be.found.on.your.new.remote.by.using. the.device.Mode.and.SETUP buttons... Referring.to.“Code.Search”.on.page.8,.setup.a.device. Mode.(e.g.,.DVD).with.the.correct.code.for.your. Combo.device..Assuming.the.DVD/DVR.Combo.device. is.the.example.and.its.code.is.programmed.under. DVD Mode,.press.and.hold.the.DVD.Mode.button. for.more.than.one.second.to.send.the.DVD.button. command..To.send.the.DVR.button.command,.quickly. press.and.release.the.SETUP button.followed.by. pressing.and.releasing.the.DVD.Mode.button..This. method.can.be.applied.similarly.to.all.Combo.devices. (e.g.,.TV/VCR,.TV/DVD,.DVD/DVR,.etc.).and.is.available. for.all.Modes..Note.this.feature.is.not.supported.by.all. codes..
  • Page 11: Dvd/Dvr.punch-Through.feature

    Setup, cont. Controlling Devices Requiring Separate Power On and Off Buttons, cont. To.turn.the.TV.off,.press.and.release.the.ON-OFF. button.to.transmit.the.Power.Off.button.command.. This.method.can.be.applied.similarly.to.any.device. and.is.available.for.all.Modes..Note.this.feature.is.not. supported.by.all.codes.. DVD/DVR Punch-Through Feature This.remote.allows.the.6.DVR.transport.buttons.(i.e.,. PLAY,.PAUSE,.STOP,.FF,.REWIND,.and.REC).to.Punch- Through.control.from.any.Mode.programmed.with. TV,.SAT.or.Cable.codes.to.the.last.DVD,.DVR or VCR. programmed.Mode.you.used...Normally.other.types. of.remotes.only.punch-through.(from.another.Mode). on.the.6.DVR.buttons.to.the.device.programmed. under.the.DVR Mode.button..This.is.not.much.use. if.you.are.using.a.DVD.programmed.under.a.Mode. other.than.DVR..For.example,.if.you.have.2.DVD,.or. DVR.devices.programmed.into.this.remote,.the.last. one.you.accessed.on.the.remote.will.be.the.one.that. has.control.of.the.6.DVR.transport.buttons.when.in. any.other.Mode...This.feature.will.not.operate.if.the. programmed.TV,.SAT.or.Cable.code.has.its.own.DVR. transport.button.control.e.g.,.a.TV.Combo,.SAT/PVR,. etc. Volume/Mute Control and Punch-Through Feature This.remote.lets.you.select.which.device.Mode.
  • Page 12: Volume/Mute.control.feature

    Setup, cont. Any Mode chosen for Volume/Mute control MUST have its own Volume/Mute function or the Volume/ Mute buttons will do nothing. Setting ALL Volume/Mute Control to any one Mode This.routine.can.set.all.Modes.to.“punch-through”. to.any.one.chosen.Mode.for.Volume/Mute.button. control.without.the.needing.to.change.to.that.Mode. 1... Press.and.hold.the.SETUP button.until.the.red. indicator.turns.on,.then.release.the.button. 2... Press.and.hold.the.MUTE.button.until.the.red. indicator.blinks.off,.then.release.the.button. 3... Press.and.release.the.desired.Mode.button.(TV,. DVD,.etc.)..For.Volume/Mute.control,.the.red.
  • Page 13: Troubleshooting

    Troubleshooting Remote does not operate your product. •.. Press.the.mode.button.of.the.product.you.want.to. control. •.. Program.the.remote.with.a.new.code. •.. Install.new.batteries..(You.might.have.to. reprogram.your.remote.after.installing.new. batteries.) •.. Remote.may.not.be.compatible.with.your.product. Remote does not operate some features of your product. •.. Program.remote.with.a.new.code. •.. Remote.may.not.be.able.to.operate.all.features.of. your.product.or.button.names.might.be.different. than.your.product. Red Indicator blinks after you program a product code.
  • Page 14 90 Day Limited Warranty Jasco.Products.Company.warrants.this.product.to. be.free.from.manufacturing.defects.for.a.period. of.ninety.days.from.the.original.date.of.consumer. purchase...This.warranty.is.limited.to.the.repair. or.replacement.of.this.product.only.and.does.not. extend.to.consequential.or.incidental.damage.to. other.products.that.may.be.used.with.this.unit...This. warranty.is.in.lieu.of.all.other.warranties.express.or. implied...Some.states.do.not.allow.limitations.on.how. long.an.implied.warranty.lasts.or.permit.the.exclusion. or.limitation.of.incidental.or.consequential.damages,. so.the.above.limitations.may.not.apply.to.you...This. warranty.gives.you.specific.rights,.and.you.may.also. have.other.rights.which.vary.from.state.to.state..If. the.unit.should.prove.defective.within.the.warranty. period,.return.prepaid.with.dated.proof.of.purchase. Jasco.Products.Company 10.E..Memorial.Road Oklahoma.City,.OK..73114-220...
  • Page 16 Jasco.Products.Company 10.E..Memorial.Road Oklahoma.City,.OK..73114-220 Made.in.China....... 24116-1.-.1/09...
