- Page 1 USER’S MANUAL...
- Page 2 Thank you very much for choosing the LCD TV. We suggest that you spend several minutes to read carefully this manual before you install and turn on the TV. Note: Since this product is being continuously improved, changes may be made to this manual without notice. *In case of discrepancy between the graphics attached herein and the ones shown on the physical screen, the latter shall prevail.
-
Page 3: Table Of Contents
USER’S MANUAL Table Of Contents ....... Important safety instructions ......Read before operating equipment ......Connection and preparation of the TV set ........Packing list ........Attaching the base ......... Removing the base .. - Page 4 ........Function setting .......... Tuning ........PC images ..........Tips ........Product specification........Supported resolution........Before calling service ..........Glossary...
-
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment 1. Read these instructions。 2. Keep these instructions。 3. Heed all warnings. 4. Follow all instructions. 5. Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. In case the unit accidently becomes wet, pull out the power plug immediately and then contact the authorized dealer. - Page 6 IMPORTANT SAFETY INSTRUCTIONS 19. Tilt/Stability – All televisions must comply with recommended international global safety standards for tilt and stability properties of its cabinets design. Do not compromise these design standards by applying excessive pull force to the front, or top, of the cabinet, which could ultimately overturn the product.
-
Page 7: Connection And Preparation Of The Tv Set
Connection and preparation of TV set Packing Contents... -
Page 8: Attaching The Base
Connection and preparation of TV set Attaching the Base Take the TV set and the base out of the carton and assemble them with the screws in the accessory box as shown in the following picture: 1. Place the TV set on a piece of soft cloth or cushion on the desk with the front side facing down. -
Page 9: Place The Tv On A Solid Surface
Connection and preparation of TV set Place the TV on a solid surface Ensure that the TV is placed in a position to allow free flow of air. Do not cover the ventilation openings on the back cover. Leave at least 15cm around the TV set. Otherwise, air-circulation may be inadequate and cause overheating, which may cause a fire or damage to the TV set. -
Page 10: Mounting The Tv Set To A Wall
Connection and preparation of TV set Mounting the TV set to a wall This unit conforms to VESA standards for wall mounting. Please refer to the specification page for the wall hanging dimensions. In case of wall mounting, use the OEM wall hanging bracket and have specialized personnel carry out mounting in order to ensure your safety and to prevent damage to the TV set. -
Page 11: Turn On/Off The Lcd
Turn On/Off the LCD 1. Turn on the LCD： Switch on the AC power supply on the back of the TV set and press the Power key on the remote controller or press the Power key on the panel. The indicator will turn blue and the LCD TV will enter normal operating mode several seconds later. -
Page 12: Searching
Searching Press the “TV” key on the remote controller to switch to the TV signal source, then press the “Menu” key on the remote controller or the “Menu” key on the right side of the panel to enter the main menu page. Press the Searching key or enter the searching page to search channels automatically. -
Page 13: About The Control Panel And Interface
About the control panel and interface PANNEL CONTROL KNOBS Input: Press this button to change input source. Menu: Press this button to display or exit the OSD menu. CH▲/ When the OSD menu appears, press these two buttons to select the item you want to execute;... -
Page 14: Source Interface
SOURCE INTERFACE Several signal source devices can be connected to your TV set. The following diagram shows how to connect them. Tips: If you want to hang the TV set on the wall, all connecting wires must be inserted into the interfaces of the TV set first. Whenever a peripheral device is connected to the TV set, ensure that the TV set is turned off. -
Page 15: Antenna Input
SOURCE INTERFACE Antenna Input: Insert the antenna connector into the antenna jack of the TV. The interface is a 75 Ω coaxial cable input. ： Video/S-terminal input Connect the video signal source or S-terminal cable to a device such as a DVD, laser disc player, video recorder or camera. -
Page 16: Component Input
SOURCE INTERFACE Component Input： Connect the sound and picture of the component signal source (DVD, laser disc player, video recorder or camera, etc.) to the component signal input port. ： HDMI HDMI (High-Definition Multimedia Interface) can be used to connect the HDMI signal cable to the DVD player and other devices. -
Page 17: Computer Signal And Computer Audio Input
SOURCE INTERFACE Computer signal and computer audio input: Connect the host signal to the computer input port at the back of the TV via the VGA signal cable. Connect one end of the PC audio cable to the PC audio input port of the TV, and connect the other end to the audio cable port of the PC host. -
Page 18: Operating Instructions
OPERATING INSTRUCTIONS TO USE THE REMOTE CONTROL POWER Press power Press to change TV ON/OFF (standby) TV. channel up or down (Note:TV never completely power off “∧”,“∨”,“＜”,“＞”, unless physically Press to adjust the unplugged.) various function items on the menu. Press to choose TV source mode directly. -
Page 19: To Install The Remote Control Batteries
OPERATING INSTRUCTIONS To install the remote control batteries 1. Remove the battery cover. Insert two AAA batteries into the battery compartment. Make sure that you match the + and – symbols on the batteries with the + and – symbols in the battery compartment. 2. -
Page 20: To Use The Menu
TO USE THE MENU Press the Menu button to display Main Menu. Use the or V+ to select the function to be adjusted. Use the P- or P+ to enter into the submenu, or to enable or adjust the selected function. Press the Menu button to exit the Main Menu. -
Page 21: Picture Setting
TO USE THE MENU Picture Setting Brightness Adjustable between 0-100, set the backlight brightness of the picture. Contrast Adjustable between 0-100, set the contrast of the picture. Saturation Adjustable between 0-100, adjust the color concentration of the picture. (unavailable for PC and Component Signal modes) Sharpness Adjustable between 0-100, set the sharpness of the... -
Page 22: Sound Setting (The Same For All Modes)
TO USE THE MENU Sound Setting (the same for all modes) Sound Mode Switch between the five preset sound modes Bass Adjust the intensity of the bass Treble Adjust the intensity of the treble Balance Adjustable between 0-60. While adjusting in the range of 30-0, the sound of the right channel fades out to zero. -
Page 23: Function Setting
TO USE THE MENU Function Setting Select the OSD language between English/Simplified MENU language Chinese/Russina/Portuguese/French/Spanish. Image Ratio 16:9 Movie (unavailable for PC mode) Panorama (unavailable for PC mode) Sleep Timer Set the time for the TV set to enter the standby state (unavailable for PC mode) OSD Position Change the display position of the OSD menu. -
Page 24: Tuning
TO USE THE MENU Tuning (the following menus appear only in TV mode) Channel Nr. Display the number of the current TV channel. Frequency Display the frequency of the current TV channel. Color Display the color system of the current TV signal. (displayed as System Auto after automatic saving) Sound... -
Page 25: Pc Images
TO USE THE MENU PC Setting (the following menus appear only in the PC mode) Auto Config Automatically config the optimal position of the picture to the optimal time sequence position. H. Position Adjust the horizontal position of the picture V. -
Page 26: Tips
Tips Care of the screen Do not rub or strike the screen with anything hard as this may scratch, mar, or damage the screen permanently. Unplug the screen before cleaning the screen. Dust the TV by wiping the screen and the cabinet with a soft, clean cloth. -
Page 27: Product Specification
Product Specification Model V22t V24t Display area 546mm (21.5”) 598mm (23.6”) Recommend frequency 1920 x1080 1920 x1080 Visual angle Horizontal:170° Horizontal:170° Vertical:160°(Typ.) Vertical:160°(Typ.) Brightness 250cd/m² 300cd/m² Contrast 60000:1 60000:1 Sound output 2Wx2 2Wx2 Color systems PAL/NTSC PAL/NTSC Sound Systems (D/K,B/G,I)/(D/K,B/G,I... -
Page 28: Supported Resolution
SUPPORTED RESOLUTION PRRESET PC MODE HORIZONTAL VERTICAL FREQUENCY STANDARD RESOLUTION FREQUENCY (kHz) (kHz) 640×480 @60Hz DMT 31.469 59.940 640×480 @67Hz MAC 35.000 66.667 640×480 @72Hz DMT 37.861 72.809 640×480 @75Hz DMT 37.500 75.000 Dos-mode 720×400 @70Hz DOS 31.469 70.087 SVGA 800×600 @56Hz DMT 35.156 56.250... - Page 29 SUPPORTED RESOLUTION WSXGA 1680X1050 @60Hz CVT16:10 65.290 59.954 WSXGA 1680X1050 @60Hz RB CVT16:10 64.674 59.883 1920×1080@60Hz 67.500 60.000 480P@60Hz for SDTV Digital only 31.469 59.94 576P@50Hz for SDTV Digital only 31.250 50.000 720P@60Hz for HDTV Digital only 45.000 60.000 720P@50Hz for HDTV Digital only 37.500 50.000 1080i@60Hz for HDTV Digital only...
-
Page 30: Before Calling Service
Before Calling Service Please make these simple checks before calling service. These tips may save you time and money since charges for receiver installation and adjustments of customer controls are not covered under your warranty. Symptoms Items to Check and Actions to follow “Ghost”... - Page 31 Before Calling Service Snowy picture *Check the antenna connection noise Horizontal dotted line *This may be caused by electrical interference (e.g. hairdryer, nearby neon lights, etc.) *Turn off the equipment. Television *Check whether the batteries are working. Replace responding to remote if necessary control *Clean the remote control sensor lens on the TV.
-
Page 32: Glossary
GLOSSARY Audio / Video Inputs Located on the rear and the front of the receiver these connectors (RCA phono type plug) are used for the input of audio and video signals. Designed for use with VCRs (or other accessories) in order to receive higher picture resolution and offer sound connection options.
