- Page 1 User's Manual LCD TV L15X421 L20S421 L20W421 Q41T2001673 3A...
-
Page 2: Table Of Contents
USER’S MANUAL TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ------------------------------------- 2 PREPARATION ---------------------------------------------------------------------- MOUNTING THE TV BASE································································ 5 OPERATING INSTRUCTIONS -------------------------------------------------- Use of the remote control --------------------------------------------------- To use the menus ------------------------------------------------------------- Main menu ---------------------------------------------------------------------- CONNECT PERIPHERAL EQUIPMENT -------------------------------------- Front Panel Control Knobs -------------------------------------------------- Preparation --------------------------------------------------------------------- Video recorder ----------------------------------------------------------------- DVD player ----------------------------------------------------------------------... - Page 3 Thank you very much for choosing the LCD TV. We recommend that you take a few minutes to read carefully through this manual before installing and switching on the TV. Please keep this manual in a safe place for your future reference. SAFETY: Lamp Disposal LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR...
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions. - Page 5 13. The TV should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. 14. Unplug this apparatus during lightning storms or when unused for long periods of time.
- Page 6 EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE Note to the CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
-
Page 7: Preparation
PREPARATION Place the TV on a solid surface. Ensure that the TV is placed in a position to allow free flow of air. Do not cover the ventilation openings on the back cover. To prevent any unsafe situations, no naked flame sources, such as lighted candles, should be placed on or in the vicinity. -
Page 8: Mounting The Tv Base
MOUNTING THE TV BASE The TV base will be separated with the TV unit. You should Install the base before you use the TV unit. Place the TV on its face on a soft blanket. Install the base stand with three screws. ... -
Page 9: Operating Instructions
Remove the cover of the battery compartment. Insert the 2 batteries supplied (Type AAA 1.5V). 4. Power: Insert the power cord in the wall socket having an AC power supply. 5. Turn the TV on: Turn the main power switch on the right side of TV to ON. Press the secondary power button in front of the TV to turn it on. -
Page 10: Use Of The Remote Control
POWER Press to turn on/off the TV. The TV is never completely powered off unless it is physically unplugged. 0~9/100 Digit buttons To select a TV channel. Press or ( or ) to browse through the TV channels,which are not erased. -
Page 11: To Use The Menus
TO USE THE MENUS Press the MENU button to display or close main menu. Use the cursor up/down to select a menu item. Use the cursor left/right to enter a submenu or enable/disable the function. Press the MENU button to exit the menu. MAIN MENU Press the MENU button to enter the main OSD (On Screen Display). - Page 12 Lock Setup, Function Setup and TV Setup can be selected; shown in the figure below: Sound Setup (Same as in PC, TV, AV1, S-Video and Components modes) The range of adjusting volume, bass and treble is from 0~100. Select “ON” or “OFF” in sound selection to control the sound output. The range of adjusting Balance is -50~+50;...
- Page 13 When the input source is in PC mode, you can select Brightness, Contrast, Position, Video noise, Sharpness, Auto Adjust, Info, Colour Temp., Red, Green, Blue and Reset to default; shown in the figure below: Brightness and Contrast: The range can be adjusted from 0~100. Position: There are two options, Horizontal and Vertical, which can be adjusted from -50 to +50.
- Page 14 Brightness, Contrast, Colour, Sharpness, Tint, Dyn. skin tone, Colour Temp., Public, Zoom and Reset to default respectively; shown in the figure below: When the input source is in Component mode, you can select Brightness, Contrast, Colour, Sharpness, Tint, White tone, Size and Reset to default respectively;...
- Page 15 the colour of picture. Dyn. Skin tone: When the Dynamic skin tone is ON, the skin tone of person in the picture becomes more vivid. Colour Temp.: There are three options of colour temperature provided for users - warm, normal and Size: There are various functions provided for zoom in/zoom out.
-
Page 16: Child Lock
Sleep Timer: Set the sleeping timer and the alert function which indicates the time left. Closed Caption (CC) setting: Select CC1~CC4, TXT1~TXT4 or OFF. Reset: It is used to reset the OSD settings. When the input source is in PC or Component mode, you can select Source OSD, Language, Timers and Reset to default;... - Page 17 enter the correct password: Age: it may be set to Child, Teenager, Youth, Adult, Custom or OFF; when you select Custom, it can be set according to you preference. MPAA Rating: Select the movie ratings from low to high (alert) - G, PG, PG-13, R, NC-17, X and F.
- Page 18 Channel nr: Shows the current channel number. Tuning mode: Select the mode of TV signal - Cable\HRC Cable\IRC Cable\ Broadcast. System standard: NTSC-M, Auto. Auto search: Select "Auto Search" to search all signaled channel; when the searching is complete, it stays at the first channel with signal and all channels that have been located are stored.
-
Page 19: Connect Peripheral Equipment
CONNECT PERIPHERAL EQUIPMENT FRONT PANEL CONTROL KNOBS Power Key? : Press to turn on or off the TV. MENU Key? : Press to show the OSD menu and exit OSD menu at the TV. Down / Up Key? ? : Select the intended function by pressing these two keys, or switch the channels in the TV mode. -
Page 20: Preparation
PREPARATION Remove the back plate at the back of the TV as shown on the illustration opposite. Lay the LCD TV with the screen down on a table, as it will be easier to connect your peripheral equipment. Please take precaution not to damage the screen. -
Page 21: Video Recorder
VIDEO RECORDER How to connect 1. Connect the supplied antenna cable to the RF IN port of your VCR. 2. Connect another FR cable from the port of your VCR to the antenna port of you TV set. If you have connected the video/audio cable to the video AV port, you may have better sound and picture when playing the VCR . -
Page 22: Dvd Player
DVD PLAYER How to connect 1. Connect 3 separate components signal cables to the Y, Pb and Pr ports of the component signal of the DVD player, and the Y, Pb and Pr ports of the component signal of theTV set. 2. -
Page 23: Headphone
DIGITAL SET TOP BOX Connect the top box to the input port of the component signal. How to connect Connect 3 separate component signal cables to the Y, Pb and Pr ports of the component signal of the Digital TV/ Top Box, and the Y, Pb and Pr ports of the component signal of theTV set. -
Page 24: Tips
TIPS Care of the screen Do not rub or strike the screen with anything hard as this may scratch, mar, or damage the screen permanently. Unplug the power socket before cleaning the screen. Dust the TV by wiping the screen and the cabinet with a soft, clean cloth. If the screen requires additional cleaning, use a clean, damp cloth. -
Page 25: Product Specification
Product Specification Function 15" Screen (L15X421) Item Screen Size Aspect Ratio Resolution Display Area (opening) H x V LCD Panel Pixel Pitch Display Clors Lamp Type/Life Color Temperature Input support definition 1024*768 /60Hz VGA Function Audio input TV Standard TV Function Sound System Colour systems Video Input... - Page 26 Audio Audio output: L / R output English. French. German. Spanish. Portuguese. Traditional Chinese Language Table Stand Yes Wall Mount VESA 100 x 100 mm Power Power Power Consumption Forwards/Backwards/ Panel Tilt Rotation Temperature Environment storage operating Dimension W x H x D (with stand) Net weight Without accessory Remote controller, Batteriesx2, Power cord, Signal Cable, Accessory...
- Page 27 Function 20" Screen（L20S421） Item Screen Size Aspect Ratio Resolution Display Area (opening) H x V LCD Panel Pixel Pitch Display Colors Lamp Type/Life Color Temperature Input support definition 640*480 /60Hz VGA Function Audio input TV Standard TV Function Sound System Colour systems Video Input S-VIDEO...
- Page 28 Audio Audio output: L / R output English. French. German. Spanish. Portuguese. Traditional Chinese Language Table Stand Yes Wall Mount VESA 100 x 100 mm Power Power Power Consumption Forwards/Backwards/ Panel Tilt Rotation Temperature Environment storage operating Dimension W x H x D (with stand) Net weight Without accessory Remote controller, Batteriesx2, Power cord, Signal Cable, Accessory...
- Page 29 Function 20" Screen（L20W421） Item Screen Size Aspect Ratio Resolution Display Area (opening) H x V LCD Panel Pixel Pitch Display Clors Lamp Type/Life Color Temperature Input support definition VGA Function Audio input TV Standard Sound System TV Function Colour systems Video Input S-VIDEO Component...
-
Page 30: Before Calling Service
Audio Audio output: L / R output English. French. German. Spanish. Portuguese. Traditional Chinese Language Table Stand Yes Wall Mount VESA 100 x 100 mm Power Power Power Consumption Forwards/Backwards/ Panel Tilt Rotation Temperature Environment storage operating Dimension W x H x D (with stand) Net weight Without accessory Remote controller, Batteriesx2, Power cord, Signal Cable, Accessory... - Page 31 Using a highly directional antenna may inprove the picture. No power *Check that the TV’s AC power cord is plugged into the mains socket. *Unplug the TV, wait for 60 seconds. Then re- insert plug into the mains socket and turn on the TV again.
- Page 32 GLOSSARY Audio / Video Inputs Located on the rear and the front of the receiver these connectors (RCA phono type plug) are used for the input of audio and video signals. Designed for use with VCRs (or other accessories) in order to receive higher picture resolution and offer sound connection options.
