dimensions & Specifications
Model
Panel Size
Resolution
TV System
Channel coverage
Speaker
Antenna impedance
Power source
Standby power consumption
Video/Audio Terminals
Video/Audio Input
Video/Audio Output
Component Input
HDMI Terminals
VGA Terminals
Headphone
SPDIF Output
Size (W x H x D) (with base and
stand)(mm)
Size (W x H x D) (without base
and stand)(mm)
Weight
Wall mount size
Wall-Mount accessory
Operating Temperature
conditions Humidity
Altitude
Storage Temperature
condition Humidity
Altitude
Note:
_ Designs and specifications are subject to change without notice.
_ This model may not be compatible with features and/or specifications that may be added in the future.
LE22H138
546mm(21.5")
1920 x 1080
NTSC standard
PAL-M & PAL-N
Air: 2 through 69
Cable TV: 1 through 125
3W x 2
75Ω
100-240V ~ 50/60Hz, 2.0A
<1W
Side AV x1: Video/Audio
Input/Audio output.
VIDEO: 1 V(p-p), 75 ohm, negative
sync.
AUDIO: 500mv (rms)
VIDEO: 1 V(p-p), 75 ohm, negative
sync.
AUDIO: 500mv (rms)
Rear Component x1:
Y: 1V(p-p), 75 ohm, including sync.
Pr/Cr: ±0.35V(p-p), 75 ohm
Pb/Cb: ±0.35V(p-p), 75 ohm
AUDIO: 500mv (rms)
HDMI INPUT: Rear HDMI x1;
HDCP compliant
E-EDID compliant
VGA INPUT:
Rear VGA (D-SUB 15 Pin) Input x1
E-EDID compliant
Audio Input: Mini-jack for stereo
(3.5ø)
Audio Output: Mini-jack for stereo
(3.5 ø)
Coaxial Digital Audio Out jack
525 x 351 x 101.8
525 x 341.13 x 37.7
4.31Kg (with stand) /
3.31Kg(w/o stand and base)
100 x 100 mm (Wall mount kit is
not included)
Optional accessory and not
included in standard package
0 C to +40 C
o o
10%~85%
To 3,000m
-10 C to +50 C
o o
5%~85%
To 10,000m
31
LE24H138
609.7mm(24.0")
1920 x 1080
NTSC standard
PAL-M & PAL-N
Air: 2 through 69
Cable TV: 1 through 125
3W x 2
75Ω
100-240V ~ 50/60Hz, 2.0A
<1W
Side AV x1: Video/Audio
Input/Audio output.
VIDEO: 1 V(p-p), 75 ohm, negative
sync.
AUDIO: 500mv (rms)
VIDEO: 1 V(p-p), 75 ohm, negative
sync.
AUDIO: 500mv (rms)
Rear Component x1:
Y: 1V(p-p), 75 ohm, including sync.
Pr/Cr: ±0.35V(p-p), 75 ohm
Pb/Cb: ±0.35V(p-p), 75 ohm
AUDIO: 500mv (rms)
HDMI INPUT: Rear HDMI x1;
HDCP compliant
E-EDID compliant
VGA INPUT:
Rear VGA (D-SUB 15 Pin) Input x1
E-EDID compliant
Audio Input: Mini-jack for stereo
(3.5ø)
Audio Output: Mini-jack for stereo
(3.5 ø)
Coaxial Digital Audio Out jack
584.36 x 378.79 x 125.69
584.36 x 371.62 x 37.7
5.53kg(with stand) /
4.22Kg(w/o stand and base)
75 x 75 mm (Wall mount kit is
not included)
Optional accessory and not
included in standard package
0 C to +40 C
o o
10%~85%
To 3,000m
-10 C to +50 C
o o
5%~85%
To 10,000m
