Summary of Contents for AOC 2212PH

  • Page 1 2212Ph User Manual...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS FOR YOUR SAFETY -------------------------------------------------- 1 SAFETY PRECAUTIONS -------------------------------------- 2 SPECIAL NOTES ON LCD MONITORS ------------------- 3 BEFORE YOU OPERATE THE MONITOR --------------------- 3 FEATURES -------------------------------------------------------- 3 PACKING LIST --------------------------------------------------- 3 INSTALLATION INSTRUCTIONS --------------------------- 4 CONTROLS AND CONNECTORS -------------------------- 5 ADJUSTING THE VIEWING ANGLE ----------------------- 6 OPERATING INSTRUCTIONS ------------------------------------- 7 GENERAL INSTRUCTIONS ---------------------------------- 7...
  • Page 3: For Your Safety

    Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 4: Safety Precautions

    PRECAUTIONS Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the monitor.
  • Page 5: Special Notes On Lcd Monitors

    SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. NOTES • Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears.
  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS SWIVEL BASE Install Remove Figure 1 Installing and Removing the Swivel Base POWER CORD Power Source: 1. Make sure that the power cord is the correct type required in your area. 2. This LCD monitor has an External universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area (No user adjustment is required.) 3.
  • Page 7: Controls And Connectors

    CONTROLS AND CONNECTORS SIGNAL CABLE Connecting the Signal Cable: Plug the Signal Cable one end to LCD monitor’s “DSUB-Input” socket, the other end to the computer's VGA port and tighten the two screws on the cable connector. Connecting the Power Cord: Plug the AC-power cord into the External Adapter.
  • Page 8: Adjusting The Viewing Angle

    ADJUSTING THE VIEWING ANGLE • For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. • Hold the stand so you do not topple the monitor when you change the monitor’s angle.
  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located on the side of the monitor (See Figure 4). By changing these settings, the picture can be adjusted to your personal preferences. •...
  • Page 10 FRONT PANEL CONTROL • Power Button Press this button to switch ON/OFF of monitor’s power. • MENU / ENTER : Active OSD menu or function adjust confirm or Exit OSD menu when in Contrast /Brightness OSD status. • < / Volume- , > / Volume+ : Activates the volume control when the OSD is OFF or navigate through adjustment icons when OSD is ON or adjust a function when function is activated.
  • Page 11: How To Adjust A Setting

    HOW TO ADJUST A SETTING Press the MENU-button to activate the OSD window (Figure 5). Press < or > to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it. If the function selected has a sub-menu, press <...
  • Page 12: Adjusting The Picture

    ADJUSTING THE PICTURE The descriptions for function control LEDS Main Main Sub Menu Menu Description Menu Item Item Menu Icon Brightness Backlight Adjustment Contrast Contrast from Digital-register. Standard Standard Mode Text Text Mode Internet Internet Mode Game Game Mode Luminance Movie Movie Mode Sports Sports Mode...
  • Page 13 Main Main Sub Menu Menu Description Menu Item Item Menu Icon Volume Adjust volume. Balance Adjust balance. Audiu Control Bass Adjust bass. Treble Adjust treble. Adjust picture Clock reduce Clock Vertical-Line noise. Adjust Picture Phase to reduce Focus Horizontal-Line noise Image Setup Adjust the verticalposition of the...
  • Page 14 Main Main Sub Menu Menu Description Menu Item Item Menu Icon Disable or Enable Full Enhance Full Enhance on or off Mode Disable or Enable Nature Skin on or off Nature Skin Mode Disable or Enable Green Field Green Field on or off Color Mode...
  • Page 15 Main Main Sub Menu Menu Description Menu Item Item Menu Icon Adjust the verticalposition of H.Position Adjust the horizontal position of V.Position OSD Setup Timeout Adjust the OSD Timeout Language Select the OSD language Select HDMI Sigal Source as HDMI Input Select Ypbpr Sigal Source as Ypbpr...
  • Page 16: Plug And Play

    PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
  • Page 17: Technical Support(Faq)

    TECHNICAL SUPPORT (FAQ) Problem & Question Possible Solution *Check if the Power Switch is in the ON Power LED is not on position *Power Cord should be connected *Check if the PC system is Plug & Play compatible *Check if the Video Card is Plug & Play No Plug &...
  • Page 18 CLOCK (pixel frequency) controls the number of pixels scanned by one horizontal sweep. If the frequency is not correct, the screen shows vertical stripes and the picture has not correct width. FOCUS adjusts the phase of the pixel clock signal. With a wrong phase adjustment the picture has horizontal disturbances in light picture.
  • Page 19: Error Message & Possible Solution

    ERROR MESSAGE & POSSIBLE SOLUTION NO SIGNAL Check that the signal-cable is properly connected , If the connector is loose, tighten the connector’s screws. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT Your computer has been set to unsuitable display mode ,set the computer to display mode given in the following table.
  • Page 20: Appendix

    APPENDIX SPECIFICATIONS Driving system TFT Color LCD LCD Panel Size 55.8cm(22") Pixel Pitch 0.282mm(H) × 0.282mm(V) R,G,B Analog Interface Video Digital Interface Input Separate Sync. H/V TTL H-Frequency 30kHz – 83kHz V-Frequency 55-75Hz Display Colors 16.7M Colors Dot Clock 165MHz Max.
  • Page 21 • Auto Adjust Button • Volume • Input Select Switch • Power Button • MENU • Contrast • Brightness • Audiu Control • Focus • Clock • Input Select • H. Position External Controls: • V. Position • OSD Setup Functions •...
  • Page 22: Factory Preset Timing Table

    FACTORY PRESET TIMING TABLE HORIZONTAL VERTICAL STANDARD RESOLUTION FREQUENCY FREQUENCY PC MODES 640x480 31.469kHz 60 Hz 640x480 37.861kHz 72 Hz 640x480 37.500kHz 75 Hz 800x600 35.156kHz 56 Hz 800x600 37.879kHz 60 Hz SVGA 800x600 48.077kHz 72 Hz 800x600 46.875kHz 75 Hz 1024x768 48.363kHz 60 Hz...
  • Page 24 FACTORY PRESET TIMING TABLE HORIZONTAL VERTICAL STANDARD RESOLUTION FREQUENCY FREQUENCY HDMI & YPbPr MODES 480i 720x480 i 15.75 kHz 60 Hz 480P 720x480P 31.47 kHz 60 Hz 720P 1280x720P* 45.00 kHz 60 Hz 1080i 1920x1080i* 33.75 kHz 60 Hz 1080P 1920x1080P 67.5 0kHz 60 Hz...
  • Page 25: Connector Pin Assignment

    CONNECTOR PIN ASSIGNMENT 15 - Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO. DESCRIPTION Green Detect Cable Blue Ground Ground DDC-Serial Data Ground H-Sync R-Ground V-Sync G-Ground DDC-Serial Clock B-Ground 24 - Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO.
