- Page 1 High Definition Multimedia Hard Disk User Manual...
-
Page 2: Table Of Contents
Feature Specification PRODUCT DETAILS Packing List Front View Back View Remote Control BASIC OPERATION Connection And Usage Of The So Speaky Black Diamond CONNECTION GUIDE OPERATION OF PRODUCT USAGE Picture Playing Music Playing Movies Playing MPEG4 Dvd Playing SYSTEM SETUP... -
Page 3: Brief Introduction
BRIEF INTRODUCTION Feature The So Speaky Black Diamond is a new kind of multimedia player product. The So Speaky Black Diamond can provide good watching. Meanwhile, it can also store and play many kinds of video files. The product, which is facilitated with many ports, can show you pictures and videos with high definition. It is really your desirable entertainment product. -
Page 4: Product Details
PRODUCT DETAILS Packing List Check the accessories after receive the So Speaky Black Diamond. If there are some missing, please contact immediately with your supplier to insure your consumer’s right. Name Quantity So Speaky Black Diamond 1 pcs Power Adapter... -
Page 5: Front View
PRODUCT DETAILS Front view Port Defi nition Instruction Blue light when switch on, Power Power LED red light when stand-by Infrared receiver Receiving IR signals from the window remote control Back view Port Defi nition Instruction Press shortly to switch on/ POWER Power button off the power... -
Page 6: Remote Control
PRODUCT DETAILS Remote control BUTTON FUNCTION POWER Turn on or turn off in the stand by mode Turn on or shut audio output MUTE Press to return to previous fi le Press to go to next fi le Pause/play. Press to fast rewind from current play and again to select the speed Press to fast forward from current play and again to select the speed... -
Page 7: Basic Operation
BASIC OPERATION Connection and usage of the product This So Speaky Black Diamond is of USB interface, so it can support hot plug & play. It is able to connect and use in the follow system. In Microsoft operation system : A. - Page 8 Please don’t draw out the So Speaky Black Diamond from the PC when the So Speaky Black Diamond is under reading or writing status. Otherwise, it may cause damage to the hard disk or loss of data Exit and disconnect the So Speaky Black Diamond As a USB interface, it supports hot swap.
-
Page 9: Connection Guide
Composite output connection First plug the yellow connector into the AV output of So Speaky Black Diamond and AV input of TV, and plug the red and white connector into the audio input of TV or HIFI. Then, plug the power supply cable and push power button on on the back of the device. - Page 10 TV. Because the cable is only for video signal, another AV cable is necessary. First, plug the red and white connector of AV cable into the audio output of So Speaky Black Diamond and audio input of TV or HIFI. Turn on TV and select YPbPr mode. Then, plug the power supply cable and push power button on on the back of the device..
-
Page 11: Operation Of Product Usage
OPERATION OF PRODUCT USAGE Power on the HDD Player, the system shows the main menu of storage equipment after a few seconds. There are two or more partitions in Media player inside HDD. Then you could press the up and down key to choose the equipment or the partition, and press the ENTER key to enter menu.Then press the left and right key to choose which you like. -
Page 12: Music Playing
Music playing If press direction key on remote controller, you can move highlight line to select navigation function, then the navigation menu will be display on the TV screen.Press direction key to select music, and press ENTER Key to begin playing. The media player can display song word and be output sound signal at the same time under playing the song files of MP3 and WMA format. -
Page 13: Mpeg4
MPEG4 Subtitle Operation Put Subtitle fi le and video fi le in the same folder, in fi le library, First press SUB-T key to choose fi le Subtitle, than choose video fi le, press enter key playing. DVD playing To play a DVD : First, on your computer : - Create a folder with th DVD structure - AUDIO_TS... -
Page 14: System Setup
SYSTEM SETUP Press SETUP key to access system setup menu System setup options SETUP Project set Detailed settings menu French, English, Spanish, Italian, German, Dutch, Danish, Portuguese, OSD Language Polish, Turkish, Russian, Czech, Hungarian Screen Saver ON or OFF Multi.System,NTSC,PAL. TV Type a. -
Page 15: Firmware Update
First, go on www.danedigital.com to download the fi rmware, download, unzip it and copy on a USB drive. Then, plug your usb drive on the So Speaky Black Diamond in the USB host : Choose USB device on the fi rst screen :... - Page 16 Choose the fi rmware fi le (.ROM) and press "OK" : Press "OK" to update : Wait during the operation : When this operation is fi nished, the So Speaky Black Diamond turns off automatically.
-
Page 17: Copy Function ( Available With The Futur Firmware)
Warning : The following functions will be available with the future firmware. To download this firmware please visit www.danedigital.com. Copy When you want to copy files, select EDIT or OTB on the remote control .It is very easy to copy files between various devices. -
Page 18: Maintenance Notice
MAINTENANCE NOTICE - To protect the normal use of all accessories, please kindly make sure understand and pay attention to following points. - Power input is 100V~240V,output 12V/3A. - Under normal working status, power adapter will keep warming, but body temperature of 60 degree or under is normal. - Page 19 www.dane-elec.com...
