Page 1: User Manual
ENMUV-2 External USB Video Adapter (DVI/VGA) User Manual... -
Page 2: Important Notice
Manual updates are represented by the third digit in the manual revision number. Copyright © 2010 ENCORE ELECTRONICS, INC. All Rights Reserved. -
Page 3: Table Of Contents
1.4 Requirements ..................6 1.5 Specifications ..................7 Chapter 2: Installation ..............9 2.1 Installation ..................9 2.2 Connected to the ENMUV-2 and monitor ......... 11 Chapter 3: Getting Started ............13 3.1 Display Modes .................. 13 3.1.1 Extend Mode (Default) ..............14 3.1.2 Mirror Mode ................... -
Page 4: Chapter 1: Introduction
No more stacking windows within the confines of a single display. Or you may span an application, e.g. spreadsheets, across two sides of displays. What’s more, ENMUV-2 is hot pluggable. If you are not using the extra monitor, just unplug the ENMUV-2 at any time; no reboot needed. -
Page 5: Applications
ENMUV-2 – User’s Manual 1.1 Applications • Office workstation 1. View your large spreadsheets across two screens with display continuity 2. Multitask more effectively without overlapping windows 3. Edit on one screen while surfing the Internet information on the other •... -
Page 6: Package Contents
(SP1). • Super VGA (800 x 600) or higher resolution monitor To play DVD on the ENMUV-2-connected monitor, in addition to the requirements above, the following requirements should also be met: • With dual core CPU at 2.0 GHz or faster •... -
Page 7: Specifications
ENMUV-2 – User’s Manual For 3 monitors, where 1 could run DVD video while also targeting productivity and business applications. Supports only 1 video of DVD resolution at full screen：. 1.8 GHz CPU 1 GB RAM For 6 screen where 1 screen can run full screen DVD video：... - Page 8 ENMUV-2 – User’s Manual Resolutions, Refresh rate and color depth Color Refresh rates Refresh rates Depth Name at 16 bit color at 32 bit color Resolution quality quality 60 72 75 85 60 72 75 85 640x480 SVGA 56 60 72 75 85...
-
Page 9: Chapter 2: Installation
ENMUV-2 – User’s Manual Chapter2: Installation 2.1 Installation Do not connect the ENMUV-2 to the USB port at this point. You will be asked to do so later on in this installation procedure. 1. Insert the provided CD into the CD-ROM drive. - Page 10 ENMUV-2 – User’s Manual 3. Please read the License Agreement and click “ I Accept ” button. 4. Please wait while Windows configures DisplayLink Core Software. Your screens may temporarily go black or flash during this process. 5. Click Yes to restart the computer. We recommend you to reboot the computer after driver installation.
-
Page 11: Connected To The Enmuv-2 And Monitor
ENMUV-2 – User’s Manual 2.2 Connected to the ENMUV-2 and monitor Connect the ENMUV-2 to your computer and monitor. Then power on your monitor. For VGA model: Use a VGA cable (not provided) to connect the VGA jack to a monitor equipped with VGA input jack. - Page 12 ENMUV-2 – User’s Manual If the add-on monitor is blank, please reboot your system again. If required, you can connect and disconnect the add-on monitor any time without disconnecting the ENMUV-2 from the USB port on your computer.
-
Page 13: Chapter3: Getting Started
DisplayLink Device icon to select Advanced. 3.1 Display Modes There is several ways you can utilize the monitor attached on ENMUV-2. The add-on monitor can be configured to use either “mirror mode”, “extended mode” or be the... -
Page 14: Extend Mode (Default)
ENMUV-2 – User’s Manual 3.1.1 Extend Mode (Default) Extended mode is the default setting. The add-on monitor can be configured to use either “mirror mode”, “extended mode” or be the primary display. This mode allows you to perform multiple tasks more effectively without overlapping windows. - Page 15 4. Drag the icons in the window at the top of the screen to match the physical arrangement of your primary monitor and add-on monitor. The add-on monitor connected to the ENMUV-2 may be identified as either "2" or “3”, depending on your computer, although there may not be a total of 3 screens connected.
- Page 16 To solve the problem in such a case, connect the add-on monitor to the ENMUV-2 or keep moving your mouse to try or unplug the ENMUV-2 first to restore the cursor.
-
Page 17: Mirror Mode
ENMUV-2 – User’s Manual 3.1.2 Mirror Mode In this mode, your original screen (the primary display) will be mirrored to the add-on monitor. • Easy Setting Click on the DisplayLink Device icon and select Mirror. Windows 7: 1. Click the arrow sign and right click the DisplayLink Device icon to select Advanced. - Page 18 Duplicate. • Manual Setting In mirror mode, the ENMUV-2 will automatically select the settings (screen resolution, color quality and refresh rate) for the add-on monitor. You can manually adjust the settings as required. However, the settings of the add-on monitor are limited by that of the primary monitor.
-
Page 19: To Be The Primary Display Monitor
ENMUV-2 – User’s Manual 3.1.3 To Be The Primary Display Monitor You can change the add-on monitor to be the primary display monitor: 1. Position the mouse anywhere on your computer desktop, right-click and select Windows 7: Choose Screen Resolution Windows Vista: Personalize =>... -
Page 20: Adjusting Resolution, Color Depth And Refresh Rate
Some monitors advertise they supported modes through the video connector. If this is the case, the ENMUV-2 identifies the supported modes from the monitor. If not, ENMUV-2 will choose a set of common screen modes for the monitor. - Page 21 ENMUV-2 – User’s Manual See the software supports the modes below. Color Depth Refresh rates Refresh rates Name available at 16 bit available at 32 bit Resolution color quality color quality 60 72 75 85 60 72 75 85 640x480...
- Page 22 ENMUV-2 – User’s Manual Screen Rotation：There are four kinds of screen rotation, the Normal, Rotated Left, Rotated Right and Upside-Down Screen Resolution：The resolution will be depends on your computer setting, resolution support of monitor and else… • Manually Setting 1. Position the mouse anywhere on your computer desktop, right-click and select Win 7: Choose Screen Resolution Vista: Personalize =>...
- Page 23 ENMUV-2 – User’s Manual Step3: Step4: Step3: Step4: 4. To change the refresh rate, click Advanced… and then click Monitor. 5. Select a refresh rate from the Screen refresh rate drop-down list and then click Apply. 6. Click OK to close the settings screen.
-
Page 24: Standby And Hibernate, Shut Down And Restart
ENMUV-2 – User’s Manual 3.3 Standby and Hibernate, Shut Down and Restart After the ENMUV-2 was connected with a computer and an external monitor, the display of external monitor will be blank when the computer goes into standby or hibernate mode. - Page 25 Both of them support extended and mirror modes. The only exception is on Windows Vista XDDM mode. In XDDM mode, only the first connected ENMUV-2 can be configured to use extended mode. The second ENMUV-2 is forced to use mirror mode. In the display settings dialog box, you will only find that “…DisplayLink Graphics Adapter”...
-
Page 26: Verifying The Driver Installation
ENMUV-2 – User’s Manual 3.6 Verifying the Driver Installation To verify your ENMUV-2 driver installation, please launch Device Manager by the steps below: 1. Open the Control Panel. 2. Then Win 7: Double-click Uninstall a Program Vista: Double-click Programs and Features XP/2000: Double-click Add or Remove Programs 3. -
Page 27: Uninstall The Enmuv-2 And Driver
2. Select DisplayLink Graphics or DispalyLink Core Software and then click Uninstall or Remove. 3. Click Yes to confirm the removal. 4. During the removal process a couple of DOS windows will pop up. 5. Click Yes to restart your computer and then unplug the ENMUV-2 now. -
Page 28: Chapter 4: Q&A
If the monitor power LED is red, check if the connection is properly made. If problem still exists, uninstall the driver, unplug the ENMUV-2 and reinstall the driver to try again. Q2: The add-on monitor is flickering. - Page 29 • Use the ENMUV-2 in extended mode. • Terminate any other CPU intensive applications running on the computer. If you still have issues playing media content on the ENMUV-2, try the following steps: • As some media players require DirectX hardware support to correctly operate, try a different media player which requires less DirectX support.
-
Page 30: Chapter5: Regulatory Compliance
ENMUV-2 – User’s Manual Chapter5: Regulatory Compliance FCC Conditions This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference 2.
