Summarization of Contents
General Safety Instructions
Read Instructions Carefully
Emphasizes reading instructions before first use and retaining them.
Guarantee Validity
States guarantee ceases if manual recommendations are not followed.
Mains Voltage and Earth Connection
Check mains voltage matches appliance and ensure earth connection.
Sufficient Home Power
Ensure home power is sufficient and circuit breaker capacity is not exceeded.
Suitable Room Environment
Do not use in rooms with flammable gases or products.
Prevent Overheating
Do not cover the device or use it to dry clothes to prevent overheating.
Cable and Surface Safety
Ensure power cable or other objects do not contact the hot radiator surface.
Damaged Cable Replacement
Damaged power cables must be replaced by manufacturer or qualified person.
Regular Device Inspection
Regularly check the device and supply cord; do not use if damaged.
Socket Placement
Do not place the device directly under a power socket.
High Temperature Caution
Some parts reach high temperatures; exercise caution with children or vulnerable people.
Child Supervision and Play
Children under three should not touch or play with the radiator; supervise at all times.
Child Usage and Supervision
Children 8+ can use if supervised and instructed; adult must clean.
Child Operation and Connection
Children 3-8 should not operate, connect, adjust, or clean the appliance without supervision.
Water Proximity Warning
Do not use near baths, showers, or pools; prohibited in bathroom zones 0 or 1.
Overheating Safety Device
Appliance has a device that interrupts operation in case of overheating.
Wall Mounting Requirement
Radiator is designed exclusively for wall fixing; consult installation section.
Approved Accessories Only
Use only manufacturer-recommended accessories to avoid risk and damage.
Packaging Safety for Children
Keep packaging elements out of reach of children due to potential danger.
Proper Disconnection
Disconnect transmitter by pulling the plug, never the supply cord.
Professional Servicing
Do not attempt to service yourself; contact a qualified technician.
Intended Use and Prohibitions
For domestic/light commercial use only; not for industrial, outdoor, or animal husbandry.
Specific Safety Instructions
Vertical Position Requirement
The appliance must always remain in a vertical position.
Secure Fixing Assurance
Always ensure the appliance remains fixed solidly at all times.
Adherence to Installation Distances
Please adhere to the installation distances indicated in this guide.
No Front or Top Obstructions
Do not hang any object in front or on top of the device.
Air Inlet/Outlet Clearance
Always ensure that the inlet and outlet air are not obstructed.
Combustible Material Clearance
Install away from combustible material like curtains or towels.
Cleaning Caution
Consult maintenance for cleaning; water entry could damage the device.
No Object Insertion
Do not insert any object through the grille or inside the device.
Electrical Connection and Fixing
Connect by plug and fix to the wall; follow installation instructions.
Guarantee Void Condition
The guarantee will not apply if these instructions have not been observed.
Installation
Initial Use Smells and Noise
Initial use may cause smells/noise due to part dilatation; ensure ventilation.
Sizing and Dealer Consultation
Calculate power/elements based on room size; consult dealer for calculation.
Wall Mounting and Levelling
Fix radiator to a firm, well-levelled wall, away from furniture.
Avoid Corner Installation
Avoid installing the appliance in corners.
Window Installation Advice
Advise against installing under windows to favor heat loss.
Minimum Clearance from Materials
Keep radiator at least 15 cm from combustible material, curtains, furniture, etc.
Front Obstacle Clearance
Allow minimum 1 m from the unit's front to any obstacles.
Side Wall Clearance
Keep minimum 15 cm between appliance and side walls or other obstacles.
Top and Floor Clearance
Keep minimum 35 cm on top and 15 cm from the floor free of obstacles.
Bathroom Installation Zones
In bathrooms, install only in Zones 2 or outside Zones (Zone3) per BS 7671.
Wall-Mounting Procedure
Instructions for securing the appliance to the wall using suspension supports.
Digital Programmable Thermostat
Operation Guide Overview
Introduces the programmable thermostat and its features for energy optimization.
Thermostat Presentation
Describes the thermostat's design for regulating electric radiators and optimizing energy.
Screen Layout and Indicators
Details the components and symbols displayed on the thermostat's screen.
Keypad Functions
Identifies the purpose of each button on the thermostat keypad.
First Use and Setup
Guides users through initial device operation and setup procedures.
Energy Supply Mode
Explains how to activate/deactivate the radiator and memory function.
Setting Time and Date
Step-by-step guide to correctly setting the current time and date.
Operation Modes
Timer Mode Configuration
Allows setting a specific temperature for a defined duration.
Manual Comfort Mode
Enables setting a constant temperature to be maintained throughout the day.
Automatic Operation Mode
Operates the appliance based on preset programmes like "P1".
ECO Mode Functionality
Maintains a reduced temperature throughout the day for energy saving.
Frost Protection Mode
Protects property from freezing by maintaining a minimum temperature.
Program Mode Selection
Allows choosing from nine preset programmes (P1 to P9).
User Programmable Modes
Enables creating and storing up to four personalized programmes (U1 to U4).
Consumption Control Mode
Allows checking and controlling the radiator's energy consumption.
Specials Functions
Keypad Lock Function
Prevents unintended changes to thermostat settings, useful in public areas.
Window Opening Detection
Automatically detects open windows and pauses heating to save energy.
System Settings Menu
Screen Display Units
Selects temperature display units between Celsius (°C) and Fahrenheit (°F).
Time Format Selection
Choose between 24-hour (24:00) or 12-hour AM/PM time formats.
Daylight Saving Time (DST)
Enables automatic or manual adjustment for daylight saving time.
Internal Probe Calibration
Calibrates the internal temperature probe for accurate room readings.
Minimum Temperature Setting
Sets the minimum temperature for the Frost Protection mode.
Smart Temperature Control (ITCS)
Calculates time to reach comfort temperature considering room factors.
Open Window Detection Activation
Activates or deactivates the automatic window opening detection function.
Radiator Power Adjustment
Adjusts the radiator's power for consumption calculation and display.
Reset to Default Settings
Resets the thermostat to its original factory default settings.
Software Version Information
Displays the current software version of the thermostat.
Exiting Settings Menu
Exits the system settings menu and returns to the main screen.
Miscellaneous
External Probe Reference Values
Provides reference resistance values for external probes at different temperatures.
Thermal Safety Mechanism
Explains the automatic safety device that cuts operation during overheating.
Maintenance Guidelines
Instructions for cleaning and maintaining the radiator for optimal performance.
